Rotek 2360 Operating Instructions

1. Product Ratings:
Style Inlet Size
2360 1" (25 mm)
2361 1" (25 mm)
2365 1-1/2" (38 mm)
2366 1-1/2" (38 mm)
2366E 1-1/2" (38 mm)
2368 2-1/2" (65 mm)
2. Product Warnings:
2.1 Read instruction manual before use. Operation of this nozzle without understanding the manual and
receiving proper training can be dangerous and is a misuse of this equipment.
2.2 Nozzle must be mated to a hose line with matched threads. Mismatched or damaged threads may
cause nozzle to leak or uncouple from hose under pressure and could cause injury.
2.3 An inadequate supply of nozzle pressure and/or flow will cause an ineffective stream and can result in
injury, death or loss of property.
2.4 Failure to restrain nozzle reaction can cause firefighter injury from loss of footing and/or stream
protection. Nozzle reaction will vary as supply conditions change: such as opening or closing other
nozzles, hose line kinks, changes in pump settings, etc. Changes in spray pattern or flushing will also
affect nozzle reaction. The nozzle operator must always be positioned to restrain the nozzle reaction in
the event of those changes.
2.5 Injury from whipping can occur. If nozzle gets out of control or away from operator, retreat from
nozzle immediately. Do not attempt to regain control of nozzle while flowing water.
2.6 Fire streams are capable of injury and damage. Do not direct water stream to cause injury or damage
to persons or property.
2.7 There are a wide variety of foam concentrates. Each user is responsible for verifying that any foam
concentrate chosen to be used with this unit has been tested to assure that the foam obtained is
suitable for the purpose intended.
2.8 Use of compressed air foam (CAF) with hand held nozzles can cause sudden surges in nozzle reaction
force resulting in risk of injury or death from loss of footing or hose whipping.
2360MED2310R0UG 27/10/2023
SELECTABLE GALLONAGE NOZZLES
OPERATING INSTRUCTIONS
Length Weight
19 cm 1.1 kg
19 cm 1.1 kg
23 cm 1.8 kg
23 cm 1.8 kg
23-28.8 cm 2.1 kg
31 cm 3.4 kg
Protek Manufacturing Corp. is a ISO 9001 Registered Company
PROTEK MANUFACTURING CORP.
No 226, Sec 4, Changping Rd, Daya Dist
Taichung City 42850, Taiwan R.O.C.
Phone: +886-4-2567-2111
Fax: + 886-4-2567-0098
Email: technical@protekfire.com.tw
www.protekfire.com.tw
Flow Settings (LPM)
20-40-100-150
50-100-150-230
70-130-230-400
100-250-350-500
100-250-350-500
285-500-600-800-950
