Marco POUR'D RTD HANDS-FREE Manual

Font to Beverage Pump
2
3
4
DC
Power
Pump
Wiring
5
7
11
1
ITEM NO
1
2
UNLESS OTHERWISE SPECIFIED:
3
DIMENSIONS ARE IN MILLIMETERS
TOLERANCES: LINEAR: +/-0.2mm
ANGULAR: +/-0.5°
4
5
6
7
8
9
10
11
Instruction Manual: 1900025
Assembly P/n: 1000949
PART NO. DESCRIPTION
- - Kegerator
1000857 Font Hands Free Marco 305mm
1000859 Una Font
DESCRIPTION:
1402397 Washer POUR'D RTD
DWG NO.:
MATERIAL:
1700325 Spacer Foam POUR'D RTD
1501549 Pump Xylem 24V DC
1400942 Connector LFP to 1/4" (John Guest)
1800521 Hose 3/8" ID PVC clear
1800637 Hose LDPE 1/4"
1502013 Terminal Block 2Pos Pluggable
- - Font to Beverage Control Box
- - Beverage in Box
Font to Beverage Pump Connection Kit
1000949
mm
ITEM
PART NUMBE
NO.
1 - -
1000857
2
1000859
3 1402397
4 1700325
5 1501549
6 1400942
7 1800521
Font
8 1800637
Wiring
9 1502013
10 - -
11 - -
10
8
9
6
QTY
1
1
1
1
1
1
2
1m
1m
2
1
1
1
