Smart Combustible Gas Sensor (LPG)

SKU: HEIEHS1CG-P

Quickstart

This is a Alarm Sensor for Europe. To run this device please connect it to your mains power supply. Press the Network Button 3 times within 1.5s, Green

LED is Blinking 3 times within 1 second.

If add Process is successful, Green LED will turn on.

Important safety information

Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law. The manufacturer, importer,

distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material. Use this

equipment only for its intended purpose. Follow the disposal instructions. Do not dispose of electronic equipment or batteries in a fire or near open heat sources.

What is Z-Wave?

Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section.

Table of Contents

Need help?

Do you have a question about the HEIEHS1CG-P and is the answer not in the manual?

Questions and answers

Summary of Contents for Heiman HEIEHS1CG-P

Page 1 Heiman Smart Combustible Gas Sensor (LPG) SKU: HEIEHS1CG-P Quickstart This is a Alarm Sensor for Europe. To run this device please connect it to your mains power supply. Press the Network Button 3 times within 1.5s, Green LED is Blinking 3 times within 1 second.
Page 2 Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and every mains powered node can act as a repeater for other nodes (meshed network) in case the receiver is not in direct wireless range of the transmitter. This device and every other certified Z-Wave device can be used together with any other certified Z- Wave device regardless of brand and origin as long as both are suited for the same frequency range.
Page 3 Should be installed at 0.3-1m below from the ceiling, semi-diameter to gas source less than 1.5m. Inclusion/Exclusion On factory default the device does not belong to any Z-Wave network. The device needs to be added to an existing wireless network to communicate with the devices of this network.
Page 4 Product Usage 1. Shell surface will be slightly hot while working, which is normal phenomenon 2. Please dismantle sensor while decorating house 3. Avoid spraying aerosol around sensor 4. Oil adhesion around gas convection holes may effect the sensitivity of gas sensor after a long time of use. It‘s suggested to clear gas convention holes every 3 months (with a little detergent, but with care so it doesn‘t enter the body of the sensor).
Page 5 LIGHT STATE & PRODUCT TEST STATE COLOR LIGHT ALARM SOUND Power Green Normally on Alarm Flashing gas alarm Malfunction Yellow Normally on Long buzz Test button of this sensor is used for testing wheater LED indicator and buzzer can work properly. Red LED and yellow LED flash alternatively with buzzer alarm when the test button is pressed.
Page 6 Maximum Group Number Description Nodes Lifeline association group Include command classes: Notification Report and Device Reset Locally notification. Root Device group(Notification). Notification reports status of gas detected or no gas detected via Lifeline. When the sensor detects status change of gas detected and no gas detected, the device will be triggered.
Page 7 Dimensions 78 x 78 x 68 mm Weight 91 gr Hardware Platform ZM5202 4251295701769 IP Class IP 20 Voltage 230V Device Type Notification Sensor Network Operation Always On Slave Z-Wave Version 6.51.09 Certification ID ZC10-16125343 Z-Wave Product Id 0x0260.0x8003.0x1000 Communications Protocol Z-Wave Serial API Color White...
Page 8 Supported Command Classes Association Grp Info Association V2 Device Reset Locally Manufacturer Specific V2 Notification V7 Powerlevel Version V2 Zwaveplus Info V2 Explanation of Z-Wave specific terms Controller — is a Z-Wave device with capabilities to manage the network. Controllers are typically Gateways,Remote Controls or battery operated wall controllers.
