TRAMPOLINE MANUAL
ASSEMBLY, INSTALLATION, CARE,
MAINTENANCE, AND USE INSTRUCTIONS.
8' X 11' RECTANGULAR
WARNING!
Read these materials prior to assembling and using this trampoline and trampoline
enclosure. Keep this manual so you can refer to it later.
Not recommended for children under six years of age.
Version 3.0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Kahuna RECTANGULAR
- Page 1 TRAMPOLINE MANUAL ASSEMBLY, INSTALLATION, CARE, MAINTENANCE, AND USE INSTRUCTIONS. 8’ X 11’ RECTANGULAR WARNING! Read these materials prior to assembling and using this trampoline and trampoline enclosure. Keep this manual so you can refer to it later. Not recommended for children under six years of age.
- Page 2 18. Control bounce by keeping your head straight and eye level directly in front of you. 19. Avoid bouncing when tired. Keep turns short. Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual...
- Page 3 Be sure of overhead wires, objects onto the trampoline. Small children may need tree limbs, etc. assistance to get on or off the trampoline. Do not step onto the suspension system. Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual...
- Page 4 Jumpers need to understand that control is key to successful jump. Contact a certified trampoline instructor for more information. 1e. Weight Limit Do not exceed the weight limit of 150 kg for the trampoline Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual...
- Page 5 Inspect all areas of trampoline prior to each use Use soft scrubs or material to clean trampoline mat We recommend 4 adults to move the trampoline Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual...
-
Page 6: Installation
Check the trampoline bed and frame padding for holes, tears, fraying, cracks or deterioration due to UV exposure. Check the springs are securely attached Check metal parts (frame, poles, bolts, legs) for rusting and breakage Check the safety-net for holes, tears and stretching Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual... -
Page 7: Recommended Installation
(do not set-up on concrete and other hard surfaces) Keep your trampoline stable during the set up process by using heavy objects such as weights or sandbags Ensure area is clutter free and away from overhead hazards Recommended Installation Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual... - Page 8 Please refer to the table for part descriptions and numbers. The assembly instruction use these descriptions and numbers as reference. It is best to use gloves to protect your hands from pinch points during assembly. Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual...
-
Page 9: Parts Checklist
Corner Rail Type B Top Rail Small Top Rail Large Leg Base A Leg Base B Leg Extension Springs Type A Frame Pad Trampoline Mat Spring Tool Bolt & Nut (M6x50mm) Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual... - Page 10 Upper Net Pole Type A Upper Net Pole Type B Pole Sleeves Bolts, Nuts & Washers (M6x85mm) Safety Net Fiberglass Rods Storage Compartment Caps Ladder Anchor Kit (Optional) Basketball Set (Optional) Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual...
-
Page 11: Assembling The Main Frame
Rail type B (B) with Top Rail Small (C) by using Bolt M. Step Attach previously connected Top Rail Small (C) with Corner Rail Sets (Step 1 above), to Top Rail Large (D) using Bolt M, to form a rectangle frame. Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual... - Page 12 Type A and Type B (E & F)by using Bolt M Step Connect the Leg Base Type A and Type B (E & F) to the assembled rectangle frame as shown in the picture. Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual...
- Page 13 D ring on the mat and the rail side of the spring is attached to the rail. Step Attach the Spring (H) on other corner D rings on the Trampoline Mat (K), as highlighted in red on the diagram. Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual...
- Page 14 Trampoline Mat (K). Step Once you have completed the installation of the mat, check that the springs are connected into the rail and mat correctly. Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual...
-
Page 15: Frame Pad Assembly
Do not tie the safety pad black straps to the springs. Step Pull the side cover of the Frame Pad (J) over the edge, ensuring the frame and springs are covered. Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual... -
Page 16: Assembling The Safety Net
Bolt (R) between net pole and trampoline frame. Step Install Upper Net Pole Type B (P) with basketball attachment where you would like to position the basketball ring on top for the Lower Net Poles (N) Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual... - Page 17 O) onto the Lower Net Pole (N) Check all the poles are attached properly and all the bolts are tight Step Slide the net Pole Sleeve (Q) onto the net poles Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual...
- Page 18 Only the smooth fiberglass surfac- es should be visible in the openings of the top sleeves of the Safety Net. Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual...
- Page 19 Clip the upper parts of the Cap (V) with the fiber- glass rod circle inserted through them to the top of the Upper Net Poles, locking the fiberglass rod circle to the Upper Net Poles. Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual...
- Page 20 Locate the net clips attached to the Safety Net (S) and looping them underneath the frame of the trampoline connect them to the D rings on the Trampoline Mat (K) to which the Springs are connected. Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual...
-
Page 21: Assembling The Basketball Kit (If Available)
(Part Y4) Place the bracket (Part Y5) over the lower part of the ring and screw in the 4 bolts (Part Y10). Step 3 Wrap the Net around the ring (Part Y3) Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual... - Page 22 Then tighten the bolts to secure the basketball set to the trampoline Basketball Pole for Basketball Step 7 using the basketball air pump (Part Y1) pump up the basketball (Part Y7) Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual...
- Page 23 YOUR NEW KAHUNA TRAMPOLINE IS NOW COMPLETE! Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual...
-
Page 24: Troubleshooting
Make sure the rope around the bottom of the trampoline String around to many springs is around every 3rd spring and not every spring Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual... - Page 25 Leg extension for the 8ft The 8ft trampoline do not include the leg extensions trampoline Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual...
-
Page 26: Warranty
Kahuna Assembly, Installation, Care, Maintenance & Usage Instruction Manual...
