Outdoor Essentials BRIDGEPORT Assembly Instructions

PREPARATION:
Check local ordinances and regulations before building your fence.
Before construction, contact your local utility companies to mark any
underground cables and pipelines. In addition, it is a good idea to
discuss plans with any neighbors along your proposed fence line.
DIGGING POST HOLES:
Dig post holes 18" to 24" in diameter and 36" to 48" deep
(depending on local ordinance or expected frost depth in winter).
Backfill the holes with 6" of gravel.
The gate can be set up left swing or right swing. Consider swing
direction when determining which post will be your hinge post.
Mix concrete in the hole for the hinge post per the instructions on
the bag. Install the post into the hole and tap the post to the proper
depth. We recommend inserting a piece of 4x4 to support the gate
hinge post. Using a level, ensure post is plumb. Brace the post with
temporary supports as the concrete sets (per the instructions).
Repeat with second hole.
STEP 1
Lay out all four pickets so they face
the same way. Slide each picket into
the next, snapping into place.
©2022 UFP Retail Solutions, LLC. All rights reserved. Outdoor Essentials is a registered trademark of UFP Industries, Inc.
PicketLock is a trademark of UFP Industries, Inc. | 2801 East Beltline NE, Grand Rapids, MI 49525 | (844) 529-5882
BRIDGEPORT 6'X42" PRIVACY GATE
ASSEMBLY INSTRUCTIONS
ACTUAL SIZE: 68.625 in. H x 42.75 in. W
Preparation and Digging Post Holes
Assembling and Hanging the Gate
OutdoorEssentialProducts.com
KIT CONTENTS:
• 2 – Top/Bottom Rails
• 2 – Gate Jambs with covers
ITEMS YOU MAY NEED:
• Power drill with 1/8" and 1/4" drill bits
• 7/16" wrench
• Tape measure
• Pencil
44" Gate
Opening
Hinge Post
4x4 Wood
Insert
18" to 24" Dia. Hole
Filled with Concrete
• 4 – Pickets
• Hardware Kit
• Safety glasses
• 4x4 treated wood post
• Blocks or clamp
Latch Post
36" to 48"
In-Ground
Patent-pending technology
14516_10/22
PG. 1
