Summary of Contents for Vornado ALCHEMY LUCERNA 1
- Page 3 W E E X P E C T T H I S P R O D U C T T O B E I F I T I S N O T W I L L M A K E v o r n a d o .
-
Page 5: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..........4 GETTING STARTED ................9 FEATURES ..................10 FILLING WATER TANK..............11 CONTROLS..................14 HOW TO USE .................15 CLEANING ..................16 STORAGE ..................17 TROUBLESHOOTING ..............18 WARRANTY ...................19 English... -
Page 6: Important Safety Instructions
Please keep all documents for future reference and pass these documents on, together with the product, to any future owner. See vornado.com to view, download and print the most current version of this owner’s guide. INTENDED USE: This product is intended to humidify and circulate the air in indoor living spaces only in the United States and Canada. - Page 7 Use only the Vornado detachable external power supply and cord that comes with your product.
- Page 8 information on the rating label, including voltage, is compatible with your outlet’s power supply. • Never use the cord as a handle or otherwise yank, strain or stretch the power cord. • While the product is plugged in, do not insert or allow foreign objects to enter any input or output opening as this may cause risk of electric shock or fire, or damage the product.
- Page 9 • Do not open appliance housing while product is plugged in. To avoid risk of shock, all service and/or repairs must be done by a Vornado Authorized Service Center. • Protect against the growth of mold, mildew and other microorganisms by emptying the water tank immediately after each use.
- Page 10 Supplier’s FCC Declaration of Conformity Unique Identifier: Vornado Models Lucerna 1, Lucerna 2, Lucerna 3 Responsible Party: Vornado Air LLC Mailing Address : 415 E. 13th St., Andover, KS 67002 Contact: www.vornado.com...
-
Page 11: Getting Started
GETTING STARTED Before use, check appliance for visible damage. DO NOT USE if there is evidence of damage. If any damage is found, contact Vornado Air, LLC at 1-800-234-0604. CHECK FOR LEAKS Damage due to shipping may cause leaks in Base or Water Tank. A visual inspection may not reveal hairline fractures. - Page 12 FEATURES INTEGRATED HANDLE For easy lifting and carrying. MIST OUTLET Moist air is dispersed through the Mist Outlet and projected into the room. WATER TANK & CAP This Water Tank is easy to carry, fill, install, clean and view water level. Includes easy-to-remove Cap for convenient refilling.
- Page 13 FILLING WATER TANK If Tank is used, empty water and refill with fresh water prior to use. Note: Spills can occur during cleaning, moving or refilling the Water Tank, so be careful to avoid spills when doing these activities. 1. Unplug humidifier and place on a level surface. 2.
- Page 14 FILLING WATER TANK If you have hard water or water with excessive minerals, we recommend using distilled water to help reduce white dust and mineral buildup. 5. Replace the Cap by turning clockwise until tightened. Turn the Water Tank rightside up to empty water that may have spilled into the underside chambers. WARNING - Take care to not pinch your fingers or hand when replacing water tank into unit.
- Page 15 FILLING WATER TANK WATER TANK English...
-
Page 16: Controls
CONTROLS Controls can be found at the base of the unit. Illumination Press to activate optional ambient lighting. Press to cycle through brightness levels: 100% | 50% | 25% | OFF. Illumination can operate without humidification. Power Press to turn unit ON or OFF. Humidification Press to control humidity level, cycle through LOW | HIGH | OFF. -
Page 17: How To Use
HOW TO USE 1. Position humidifier to not blow directly on objects or plants. Do not allow Mist Outlet to be obstructed. Plug power cord into the unit’s power jack in the Base, and then plug the power cord into a standard wall outlet. Remove label from top of Mist Outlet prior to turning humidifier on. -
Page 18: Cleaning
CLEANING Proper cleaning is essential to the air quality and performance of your humidifier. The frequency in which your humidifier will need to be cleaned will vary depending on use, water hardness and outside environmental factors. It is recommended, assuming average use, to thoroughly clean the unit several times throughout the season, when not turned back on with water still in Base for 8 hours or more, or when algae, mineral deposits or other particles begin to form. -
Page 19: Storage
STORAGE During the off-season or after extended periods of non-use, you may choose to store your humidifier. To ensure long life of the product, it is recommended to store your humidifier by following these instructions: CLEANING is recommended before storage. 1. -
Page 20: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE & SOLUTION Unit fails to power on. Unit is not plugged in. Ensure the power cord is secure in the unit’s power jack, and plug power cord into electrical outlet. Household circuit breaker/ground fault circuit interrupter has tripped or blown fuse. - Page 21 Or to file a contactless warranty claim, visit vornado.com/contact-us. AFTER RECEIVING THE RA FORM, SHIP YOUR PRODUCT TO: Vornado Air LLC Attn: Warranty & Repair 415 East 13th Street, Andover, KS 67002. For your convenience, please have your model number and serial number when contacting Vornado with service inquiries.
-
Page 22: Warranty
Vornado product to a country not intended for use will void all warranties. Any unauthorized product modification, repair by unauthorized repair center or use of non-approved replacement parts is not recommended and any consequences will not be covered by support services or product warranties.
