Page 1 CL-J1708 sensor v2 ™ User’s manual...
Page 2 User’s manual Inventure CL-J1708 sensor v2 ™...
Page 3 Copyright Notice © Copyright 2019, Inventure, Inc. Revision D01-032-02-04-05EN Contact INVENTURE Automotive Electronics R&D, Inc. Fürj street 2. Building B, 1. floor H-1124 Budapest HUNGARY Phone: (+36) 1 381-0970 E-mail: support@inventure-automotive.com URL: www.inventure-automotive.com © Inventure Automotive Electronics R&D, Inc. Page 3...
Page 4: Table Of Contents
....................7 NSTALLATION STEPS CHECKING THE PROPER OPERATION ................ 8 OPERATING STATES ..................... 9 ..................9 ESCRIPTION OF THE STATES SYSTEM CHARACTERISTICS ..................10 WARRANTY ........................11 HOW TO CONTACT INVENTURE? ................12 © Inventure Automotive Electronics R&D, Inc. Page 4...
Page 5: Introduction
CL-J1708™ v2 1 Introduction Thank you for purchasing an Inventure product. Your new Inventure CL-J1708 device is a carefully engineered, high quality durable product with modern features. It is designed to give you the quality and convenience you expect from an automotive measuring instrument.
Page 6: Notices
J1708 communication. Inadequate connection to vehicle J1708 wires may affect vehicle operation and may cause safety issues. • Fix Inventure CL-J1708 device properly to avoid hitting to vehicle elements, or rattling! • Device should be installed away from direct heat and moisture. Installation in cabin is recommended.
Page 7: Installation
For other telematic device: use the appropriate connector 6. Turn on ignition (optional) 7. Place cover of CL-J1708 device under vehicle J1708 wires! Ensure vehicle J1708 wires not to be strained and/or bended sharply, but run straight in the indicated High and Low...
Page 8: Checking The Proper Operation
CL-J1708™ v2 Figure 3. Intended wire paths below the cover 8. Place the cover to match the CL-J1708 device. The hole on the cover must be aligned with the status LED. 9. (Optional) Check status LED (section 6)! If ignition is on the red light changes to green indicating proper vehicle J1708 polarity 10.
Page 9: Operating States
User’s manual CL-J1708™ v2 6 Operating states The Inventure CL-J1708 has a status LED on the back of the enclosure which indicates the current operational mode. Table 1. The states of the status LED: Status Status LED Standby (in case no J1708 communication for at least 2 seconds)
Page 10: System Characteristics
Storage temperature T_storage ºC Operating temperature T_op Humidity Other characteristics: • protected against incorrect polarity • protected against transient overvoltage • ESD protection up to at least 8 kV (HBM) on any port © Inventure Automotive Electronics R&D, Inc. Page 10...
Page 11: Warranty
CL-J1708™ v2 8 Warranty There is a one-year warranty on the Inventure CL-J1708 device from the date of the original purchase. The warranty covers any defect in materials or workmanship. The warranty is valid only if the device was operated under normal circumstances in regular use. The warranty does not include damage from misuse or neglect.
Page 12: How To Contact Inventure
Your comments are also welcome under the following address: Inventure Automotive Electronics R&D, Inc. H-1124 Budapest Fürj Street 2. HUNGARY Phone: (+36) 1 381-0970 © Inventure Automotive Electronics R&D, Inc. Page 12...
