  • Page 1 Chameleon 100 Installation and Operation Manual MNL108 Rev 1.1...
  • Page 2 Chameleon 100 PDU with Auto-Transformer...
  • Page 3 READ THIS MANUAL CAREFULLY SAVE ALL INSTRUCTIONS This manual contains important information that you will need to operate the Chameleon™ safely and efficiently. Please read all instructions carefully before installing or operating equipment. Keep this manual handy for easy reference. Safety Certification This devise has been safety tested by TUV Rheinland and certified to UL 60950-1.
  • Page 4 This page intentionally left blank.
  • Page 5: Table Of Contents

    Revision 10/1/18 MNL108-1.1 Table of Contents 1— Introduction ................................1 1.1— Product Overview ............................... 1 1.1.1— Key Product Features ..........................1 1.1.2— Key Product Specs for Current Models ....................... 1 1.1.3— 125-Amp Model vs 100-Amp Model ......................2 1.1.4— Safety Features ............................2 1.2—...
  • Page 6 Contacting Power Innovations ........................... 16 List of Figures Figure 1—Power Flow ..............................2 Figure 2—Chameleon 100 Being Lowered Using the Webbing Sling and Forklift ............5 Figure 3—Rear View ............................... 6 Figure 4 —Terminal Block within the Junction Box ......................7 Figure 5—Key External Features (front) .........................
  • Page 7: 1-Introduction

    Revision 10/1/18 MNL108-1.1 1—Introduction Congratulations on your purchase! Power Innovations strongly believes in the durability and quality of its products. The company hopes this product will serve you well for a long time. 1.1—Product Overview The Chameleon™ 100 is a product family of 19-inch rack mounted transformers that provide power distribution and monitoring in a data center environment.
  • Page 8: 3-125-Amp Model Vs 100-Amp Model

    Revision 10/1/18 MNL108-1.0 1.1.3—125-Amp Model vs 100-Amp Model The Chameleon™ 100 currently comes in three variations: the Chameleon100-125J21A1A (125A), which requires a j-box, and the Chameleon100-100P21A00 or Chameleon100-100P21A1A (100A), each of which uses an input plug (see Section 4—Product Specifications). 1 OUTPUT 480 VAC WYE Chameleon™...
  • Page 9: Conventions Used In This Manual

    Revision 10/1/18 MNL108-1.1 1.3—Conventions Used in This Manual To make this manual easier to read, several formatting conventions have been adopted. 1.3.1—Breaker Positions Because some breakers share names with its subsystems or operation modes, breakers and their positions will be identified using all caps. Additionally, the words ON and OFF are always capitalized to stress which position is correct.
  • Page 10: Safety Warnings And Cautions

    Revision 10/1/18 MNL108-1.0 Note Offers practical advice that may be helpful but can be disregarded. Manual Help Provides references to other manual sections or drawings that accompany this manual. Additional Manuals Provides references to other manuals that may also be provided with this system. 1.4—Safety Warnings and Cautions This section provides important information that you will need to remember in order to safely operate your system.
  • Page 11: 2-Unpacking And Installation

    The Chameleon™ 100 is designed to be installed in a rack system with front to rear ventilation. The power input is designed to be accessed from below a Figure 2—Chameleon 100 Being Lowered Using the raised floor and input through either a junction box or a Webbing Sling and Forklift connector on a cable, depending on the options requested.
  • Page 12: Installing The Unit

    Revision 10/1/18 MNL108-1.0 2.3—Installing the Unit 2.3.1—Input/Output Overviews Input and output connections are located on the rear of the Chameleon™. The single-phase output receptacles located on the back of system are split into three sections of seven that correspond with the three phases of 240 V.
  • Page 13: Figure 4 -Terminal Block Within The Junction Box

    Revision 10/1/18 MNL108-1.1 2.3.2.1—125A Model Installation Option A – Installing with the junction box attached to the Chameleon™ 100 1. If required, cut holes in the gland plate of the junction box for the Chameleon™ 100 connections and facility connections. 2.
  • Page 14: Adding/Removing An Output Device

    Revision 10/1/18 MNL108-1.0 c. Connect the yellow wire to L3. d. Connect the white wire to N. e. Connect the grounding cables to G. 2.3.2.2—100A Model Installation 1. Using a scissor lift or other appropriate equipment to support the main Chameleon™ 100 enclosure, slide the input cable through the cabinet to its location under the raised floor beneath the rack.
  • Page 15: 3-Operation

    Revision 10/1/18 MNL108-1.1 3—Operation 3.1—System Breakers The Chameleon™ 100 is equipped with 21 20-amp breakers (S1-S21) split into three groups of seven that correspond with the three phases of the system. Additionally, each breaker corresponds with the output receptacle of the same number on the back of the system, e.g.
  • Page 16: Operating Temperature

    Revision 10/1/18 MNL108-1.0 3.2—Operating Temperature Always operate the Chameleon within the correct temperature range, as specified in Section 4—Product Specifications. 3.2.1—Temperature Monitoring The Chameleon™ 100 has two thermostats that monitor the transformer temperature and provide over temperature warning when the temperature of the transformer reaches 120 °C. This warning is given through the power meter.
  • Page 17: 2-Power Meter Reset Switch

    Revision 10/1/18 MNL108-1.1 Figure 6—Over Temperature Alert -DI1 Status • Communications The system is configured with the Acuvim AXM-WEB-PUSH Ethernet TCP communications expansion module. This module is accessed via the RJ45 connecter on the rear of the Chameleon™ 100. It can be connected to a central control panel to monitor power quality, voltage, current, and all the other parameters available from the Acuvim II Series Power Meter or its expansion modules.
  • Page 18: Maintenance

    Revision 10/1/18 MNL108-1.0 3.4—Maintenance The Chameleon is designed for maintenance-free operation and requires very little attention from users. Caution There are no user-serviceable parts inside. DO NOT remove the cover or attempt to service the Chameleon. Unauthorized service will void the warranty laid forth in this manual. 3.4.1—No User Serviceable Components There are no user servable components in the main Chameleon™...
  • Page 19: 4-Product Specifications

    Revision 10/1/18 MNL108-1.1 4—Product Specifications Table 3—Product Specifications General Chameleon100-125J21A1A Chameleon100- Chameleon100- (125A) 100P21A00 (100A) 100P21A1A (100A) Output Capacity (VA) 104,000 83,000 83,000 Capacity (Watts) 104,000 83,000 83,000 Non-Continuous Service Capacity (Watts) 83,000 66,500 66,500 Continuous Service Nominal Voltage (3 phase) 480 VAC None 480 VAC...
  • Page 20: Limited Warranty

    Revision 10/1/18 MNL108-1.0 Limited Warranty Power Innovations International, Inc. (hereinafter “Power Innovations”), warrants this product to be free from defects in material and workmanship for a period of five years from the date of purchase. The warranty also includes 60-month coverage on parts only.
  • Page 21: Customer Support

    Revision 10/1/18 MNL108-1.1 Warranty Claims Customer Support Questions concerning the operation, repair or maintenance of this equipment should be directed to the Service Department of Power Innovations International. When making such an inquiry, provide the Service Department with the model number, serial number, and approximate date of receipt of the equipment. Making a Claim Within a reasonable time, but in no case to exceed thirty days, after discovery of a defect, the purchaser shall contact Power Innovations at 801-785-4123.
  • Page 22: Contacting Power Innovations

    Revision 10/1/18 MNL108-1.0 Contacting Power Innovations If there are any questions or comments about this product, please feel free to contact us. Power Innovations International, Inc. 801) 785-4123 Fax: (801) 785-6999 Email: support@power-innovations.com Copyright © 2019 Power Innovations International, Inc. American Fork, UT, USA All rights reserved.
