Amber Wireless AMB2300-EV Connection Diagram

Advertisement

Quick Links

AMB2300-EV
Quick start for the Evaluation board of the AMB2300 – BlueNiceComIV
In Addition to the AMB2300 Manual
Connection Diagram
Microphon
Speaker
Input
Output
OP3, OP4, OP5
Audio
default pulled
(SCLK,SFS,SRD,STD)
down,
Digital Signal before
set jumper to
Audio Codec
pull up
PG6, PG7
set jumper for LED
connection
AMBER wireless GmbH
Albin-Köbis-Straße 18 • D-51147 Köln • Tel.: +49 (0) 2203-699195-0 • Fax: +49 (0) 2203-459883
Hawstraße 2a • D-54290 Trier • Tel.: +49 (0) 651-99355-0 • Fax: +49 (0) 651-99355-69
www.amber-wireless.de • info@amber-wireless.de
All manuals and user guides at all-guides.com
JP1 Pin1
See table 1 for pin
assignment
BNCIV
Current
Measure
Jumper
Pads for SMA
Jack
(Alternate
Antenna
Connector)
Voltage Regulator Output
Power to BNCIV and Audio Codec
Ground
Reset
Button
UART
(RX, TX, RTS, CTS)
TTL-Pegel on the left
side
RS232 Driver on the right
side
RS232
Power supply
5V-9V DC
implemented
voltage
regulator
