DH75 & DH100 Display Board Replacement Instructions

You Will Need:

A Phillips head screwdriver
1.
2. Your new display board replacement kit includes:
:
Before starting, shut off the unit and unplug the dehumidifier power cord. Failure to follow the warnings
and instructions may result in electric shock and/or serious injury.
–
Using your Phillips head screwdriver, locate and unscrew the screw at the top of the filter door by a quarter turn,
counterclockwise. Remove the door (Figure 1). Slide the filter out (Figure 2).
Figure 1
–
Using the included T15 Torx wrench, locate
and unscrew the four screws holding the display board in
place (Figure 3).
Figure 3
Approximate time to replace the board: 5 minutes
•
A T15 Torx Wrench
• Display Board & Bezel

• Instructions

Figure 2
–
Once the board is loose, carefully
unplug the two wire inserts (Figure 4). Set aside the
old display board.
Figure 4
Scan to Watch Video
