Orava NE-31 Instruction Manual

Compressor nebulizer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Compressor nebulizer
NE-31
EN
Instruction manual
0598
22.03.2023 rev.1.0
NE-31

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NE-31 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Orava NE-31

  • Page 1 Compressor nebulizer NE-31 Instruction manual 0598 22.03.2023 rev.1.0 NE-31...

  • Page 2: General Safety Instructions And Warnings

    ORAVA electrical appliances are manufactured according to current state-of- the-art knowledge and recognized safety and technical rules. Nevertheless, incorrect and unprofessional use or use contrary to the intended purpose may result in the risk of injury or endangering the life of the user or a third person, or damage to equipment and other material values.
  • Page 3 • Use the appliance only for the purpose for which it is intended and in the manner specified by the manufacturer. • The appliance is intended for home and similar indoor use, with no special focus. • It is not a professional device for commercial use. •...
  • Page 4 1.3 Electrical safety • Before connecting the appliance to the power supply for the first time, make sure that the voltage on the appliance label corresponds to that of the household electrical outlet. • The electrical appliance is designed for mains supply 230 V ~. The electrical safety of the appliance is guaranteed only if it is properly connected to the electricity grid.
  • Page 5 1.4 Safety of persons • This appliance is intended for use by persons without an electrotechnical qualification (layperson) according to the instructions specified by the manufacturer. • Device operation includes activities such as switching on and off, user manipulation and setting of operating parameters, visual or auditory inspection of the equipment, and user cleaning and maintenance.
  • Page 6 1.5 Cleaning, maintenance and repairs • Observe the normal user cleaning and maintenance of the appliance in the recommended way. Do not use solvents or harsh cleaners for cleaning. Pollution and visible stains from finger contact, respectively. The hands can be cleaned using detergent detergents specially designed to clean household appliances.

  • Page 7: Special Safety Warnings

    Special safety warnings • The electrical equipment is designed and manufactured in such a way as to enable safe operation and use by persons without professional qualifications. Despite all measures taken by the manufacturer for safe use, operation and use carry with it certain residual risks and possible dangers associated with them.
  • Page 8 • Before connecting the device to the mains socket, make sure that the nominal voltage indicated on the nameplate matches the voltage in your socket. • Before using the device, clean it as described in the section „Cleaning and disinfection of accessories“. •...
  • Page 9 • The device is not intended to be used by persons with reduced physical, sensory or mental capabilities. Persons with insufficient experience or knowledge may only use if their person responsible for their safety will familiarize them with the use in advance and teach them to use it under supervision.
  • Page 10 • Certain important safety precautions should always be followed when using any electrical device, including the following: - Use only original accessories and parts; - Never submerge the device in water, because the device is not protected against the ingress of water; - Never touch the device when your hands are wet or damp;...
  • Page 11 Accessories cleaning and disinfection After each treatment: • The atomizer set can be cleaned by washing in liquid soap and water and then disinfected by boiling in water (max. 10 minutes) or in an autoclave (max. 121°C for 10 minutes). It is recommended to disinfect the mask and the angle mouthpiece using cold disinfectant liquids.
  • Page 12 Parts desciriptions Device 1 Body of the device 2 Air intake 3 Power switch (O/I) 4 Power cord 5 Air outlet 6 Filter holder...
  • Page 13 Accessories 7 Sprayer 8 Mouthpiece 9 Pressure hose 10 Mask for adults 11 Mask for children 12 Replacement filters How the spray chamber works flow diverter The stream of compressed air from aerosol aerosol the compressor is redirected through the nozzle, where in the head of the decompression chamber, it mixes with the nozzle drug and is directed upwards.

  • Page 14: Assembly And Operation

    Assembly and operation Preparation • Unpack the device and remove all packaging material from it and remove any protective films. • Before first use, check both the device and accessories for visible damage or defects, such as cracks in the plastic cover that could expose electrical components.
  • Page 15 7 If you are using a face mask, fold the mouthpiece (8) and place the mask (10/11) directly on the nebulizer (7). Warning! Inhalation with a mouthpiece is the most suitable form of therapy. The use of a mask for inhalation is recommended only if it is not possible to use a mouthpiece (e.g.

  • Page 16: After Use

    AFTER USE Notice! If you end the treatment earlier, the residual water or medicinal substance from the nebulizer reservoir (7) empty after each use. Otherwise, water deposits or an unusual odor may occur. 1 Let the device cool down for at least 10 minutes. 2 Disconnect the power cord from the electrical socket and pour out any residual liquid from the atomizer (7) and wipe the drops of liquid on the surface.
  • Page 17 Replacing the atomizer The nebulizer (7) should be replaced after a long period of inactivity or if it is clogged with dried drug residues, dust, etc. With normal use, the nebulizer should last fully functional for at least 6 months. Filter replacement The filter needs to be replaced approximately every 30 hours of use, or when it appears to be dirty and clogged.
  • Page 18 • Leave the parts in the vinegar solution for 30 minutes. • Wash the individual parts with water and dry them thoroughly with a soft, dry cloth. • When the parts are completely dry, store them in a suitable dry and closed container.
  • Page 19 Troubleshooting and disposal of unnecessary equipment Problems/Questions Possible causes/solutions/answers The nebulizer does not generate any 1. Too much or too little amount of vapor or only a small amount of it is medicinal substance in the nebulizer. generated Minimum: 2 ml, Maximum: 6 ml.
  • Page 20 Problems/Questions Possible causes/solutions/answers What should be taken care of in infants 1. To ensure effective inhalation, the and children? mask should cover the mouth and nose of infants. 2. For children, the mask should also cover mouth and nose. Spraying on sleeping persons is not very effective, because a sufficient amount of the medi- cinal substance cannot reach the lungs.

  • Page 21: Technical Specifications

    Technical specifications Power supply: 220 - 240 V~ 50/60 Hz Rated power: 45 W Classification: Type BF Operating pressure range: 12 - 14.5 PSi Flow range: 8 -10 LPM Particle size: 3.0 µm Inhalation power: 0.2 ml/min. Noise level: 60 dB (A) Atomizer volume: 6 ml Dimensions (W x D x H):...
  • Page 22 This device meets the requirements of the European directive 0598 93/42/EEC. The date of manufacture is marked on the nameplate of the device. Manufacturer: FOSHAN HONGFENG Co., Ltd. No.4-2,Leqiang Road,Leping Town,Sanshui District,Foshan City,Guan- gdong Province,P.R.China Authorized representative for the EU: MedNet EC-REP Gmbh Borkstrasse 10 48163 Munster, Germany The batch number is marked on the device packaging.

  • Page 23: Disposal Of Used Electrical And Electronic Equipment

    Importer: ORAVA retail 1, a.s. ORAVA distribution CZ, s.r.o. Seberíniho 2 Ostravská 494 821 03 Bratislava 739 25 Sviadnov Slovenská republika Česká republika INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING Dispose of used packaging material at a municipal waste disposal site.
