- Page 1 Range Hood Ventilator Instruction Manual SY-HVA-620-SS READ AND SAVE THESE INSTRUCTIONS Copyright © 2021 Castlewood by AMS, All rights reserved.
- Page 2 Following the recommendations contained in this Instruction Manual will ensure this To All Consumers: appliance gives you many years of high efficiency and performance. CONTENTS: RECOMMENDATIONS AND SUGGESTIONS CHARACTERISTICS INSTALLATION & USE MAINTENANCE RECOMMEDATIONS AND SUGGESTIONS INSTALLATION: * The manufacturer will not be held liable for any damages resulting from incorrect or improper installation.
- Page 3 * Proper manitenance of the ventilator will assure efficient performance of this unit. MAINTENANCE: * Disconnect the ventilator from the main power supply before carrying out any maintenance work. * Clean and/or replace baffle filters periodically as needed. * Clean the ventilator unit using a damp cloth and a neutral liquid detergent. * DISPOSAL: Do not dispose of this product as unsorted municipal waste.
- Page 4 CHARACTERISTICS DIMENSIONS: INSTALLATION & USE Before the final installation is made check that all parts are in the box. The unit comes with a face plate/ filter, duct outlet adapter, light bulbs and mounting screws. Check the finish of the ventilation unit for scratches or dents, check the operation of the ventilator.
- Page 5 Caution: To reduce the risk of fire, use metal ductwork. 1. Decide where the ductwork will run between the ventilator unit and the outside. 2. A straight, short duct run will allow the ventilator to perform most efficiently. 3. Long duct runs, elbows, and transitions will reduce the performance of the ventilator. Use as few of them as possible.
- Page 6 Before fixing, the outlet exhaust duct for air evacuation DUCT INSTALLATION: to the outside must be installed. Use an outlet exhaust duct with: minimal length, minimal possible bends (maximum angle of bend 90 ), certified material (according to local building code), if flexible ducting is used it should be metallic and as smooth as possible inside.
- Page 7 MAINTENANCE This ventilator may require two 50W GU10 halogen or two 3W GU10 LED lamps. LAMP CONTROLS: WARNING: Always switch off the electrical supply before carrying out any service on the appliance. To change bulbs: HALOGEN LAMPS OR LED GU10 BULBS: 1.
- Page 8 CASTLEWOOD by AMS, Inc. Ascension Ventilation ONE YEAR LIMITED WARRANTY WARRANTY Castlewood by AMS warrants to the original consumer of this product that it will be free of defects in materials and workmanship for a period of one year from the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OR MERCHANT ABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
