Summary of Contents for MHZ nova-02
- Page 1 Installation instructions Edition 10.2020 nova_02 tube awning...
- Page 2 nova_02 tube awning installation instructions Table of contents Page Safety Instructions for the Installation 3 to 7 Installation Instructions 9 to 17 Adjustment instructions for Sun Top drives Adjustment instructions for OREA RTS radio-controlled drives Adjustment instructions for Sunea io radio-controlled drives Subject to technical changes, Edition 10.2020...
- Page 3 nova_02 tube awning installation instructions Important safety instructions for the installation Reading the installation and operating instructions 1.3. Goods acceptance The operating instructions must be read prior to The delivery must be inspected immediately upon receipt for installation. Any failure to do so absolves the manufacturer any damage sustained in transit.
- Page 4 1.11. Partially assembled awnings Where awnings are partially assembled at the factory, e.g. linked systems with no fabric, the spring-loaded parts MHZ Hachtel GmbH & Co. KG (see marking on the product) are secured against inadvertent Sindelfinger Straße 21 opening. The securing device must not be removed until the D-70771 Leinfelden-Echterdingen blind has been completely installed.
- Page 5 nova_02 tube awning installation instructions Important safety instructions for the installation 1.13. Unsupervised operation 1.16. Handover All operating instructions as well as the installation When working in the extension area of the awning, the and adjustment instructions issued by the motor, switch and automatic controller must be turned off.
- Page 6 nova_02 tube awning installation instructions Important safety instructions for the installation 1.17. Bracket arrangement and extraction forces Be sure to take note of all key installation information! All brackets supplied with the product must be used and they must be fitted using all fixing points. Pay attention to the extraction forces (see p.
- Page 7 nova_02 tube awning installation instructions Important safety instructions for the installation EXTRACTION FORCES AND BRACKET SETS for wind resistance class 1 Extraction forces in Newton (N) per fastening screw So that the wind resistance class specified by us is valid, the fasteners must be matched to the existing substructure by the fitter. Where orders are received without specification of the installation substructure, you will receive mounting brackets for mounting on concrete C 20/25.
-
Page 9: Installation Instructions
8. Drop bar with end caps 9. Valance with binding 10. Crank handle Check delivery at once for any MHZ awnings require in the main no Operating note: damage caused in transit. An awning is a sunshade, not a shield maintenance. -
Page 10: Attaching The Brackets
nova_02 tube awning installation instruction Technical data Unit width: from 190 cm to 600 cm coupled from 601 cm to 1200 cm Projection: 150 / 200 / 250 / 300 cm Arm bracket: pitch adjustable from 5° bis 28° Type of installation: wall / ceiling / rafter from unit width of 451 cm: Central support bracket * Pitch 1. -
Page 11: Ceiling Installation
nova_02 tube awning installation instructions 1.2. Ceiling installation The fittings must be suitable for the existing installation substructure! A support bracket is installed in the centre of units with a width of 451 cm and above. 4 Fixing points 1.3. Roof rafter installation (accessory) Using sliding block, hexagon head screw M10x25, U-washer (12) and box spanner SW17, fix support... - Page 12 nova_02 tube awning installation instructions 2. Installing the gear eyelet extension Before mounting the awning in the brackets, the extension for the connecting rod eyelet must be installed. Place the extension (20) in the bevel gear support and secure with the locking bolt (21). Step 2 Step 1 3.
- Page 13 nova_02 tube awning installation instructions 4b. Aligning the awning arms by their axis If the arms tilt out towards the wall when the awning is retracted (axial setting), proceed as follows: Extend the awning approx. 10 cm. To be able to centre the awning fabric in the drop bar, SW 2 loosen the threaded pin on the left and right of the piping clip (25) (SW2).
- Page 14 nova_02 tube awning installation instructions 6. Valance Remove the round piping from the drop bar. Insert the round piping (30) into the valance (9). Always push the valance into the groove on the drop bar (8) from the right. Push the end cap (31) onto the drop bar and secure with 3.5x19 countersunk screws (32) and a size 2 Phillips screwdriver.
- Page 15 nova_02 tube awning installation instructions 9. Gear adjustment The gear's end setting is set at the factory. If you do, nevertheless, want to change the end setting, proceed as follows: Extend awning until the free-wheel clutch activates (clear 'click' sound). Then retract awning c. 1 to 2 cm. Twist the retaining ring (34) on the connecting rod eyelet (35) until the cylindrical pin (36) for removing the connecting rod eyelet is visible.
- Page 16 nova_02 tube awning installation instructions 10. Protective sleeve installation for Hirschmann coupling (accessories) Protective sleeve for Hirschmann coupling (accessories) The protective sleeve (38) for a Hirschmann coupling can be screwed to the wall or ceiling. It should be installed with the open side facing down. This ensures that any incoming water or rain can drain away.
- Page 17 nova_02 tube awning installation instructions 11. Coupling Caution: Only remove the arms' securing tapes after the fabric tube's coupling. Here is a lot of tension on the joint arms - Risk of injury! Install the awning section with the drive in the same way as a single unit.
- Page 19 nova_02 tube awning installation instructions Adjustment instructions for Elero SunTop drives A. Note for the electrical installer This awning must not be connected with the power live. Take fuse out beforehand! There is a risk of the electronic end position setting being deleted. Resetting this is possible only with the special Elero setting cable (prod.
- Page 20 nova_02 tube awning installation instructions Adjustment instructions for OREA RTS drives from Somfy NB: The awning's end positions are set at the factory. No alteration is necessary unless you want to reset the bottom end position. Electrical connection The OREA RTS must be connected according The system is to be protected with an upstream FI circuit breaker in green/yellow to the terminal assignments.
- Page 21 El control no debe instalarse muy cerca de superficies metálicas. Los emisores locales fuertes (p. ej., inalámbricos auriculares inalámbricos) cuya frecuencia de emisión es idéntica a la del control pueden afectar su Frecuencia de radio: 868,25 MHz funcionamiento. El alcance de emisión en el transmisor unidireccional (1W) es de 15 metros sin muro de hormigón.
- Page 24 BENELUX MHZ Hachtel S.à.r.l. . 27, rue de Steinfort . L-8366 Hagen Téléphone +352 311421 . Telefax +352 312328 . www.mhz.lu ATES - Groupe MHZ . 1 B, rue Pégase, CS 20163 . F-67960 Entzheim Téléphone 03.88.10.16.20 Télécopie 03.88.10.16.46 . www.ates-mhz.com...
