Instruction manual
TUMBLE DRYER
GB
English
IDVL 75B R
www.indesit.com
This symbol reminds you to read this
instruction manual.
!
Keep this manual at hand for immediate reference whenever
necessary. Always store this manual close to the tumble dryer and
remember to pass it on to any new owners when selling or tran-
sferring the appliance, so they may familiarise with the warnings
and suggestions herein contained.
!
Read these instructions carefully: the following pages contain
important information on installation and useful suggestions for
operating the appliance.
1
Contents
Installation, 2
Warnings, 4
Laundry, 13
Troubleshooting, 14
Assistance, 15
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Indesit IDVL 75B R
Summary of Contents for Indesit IDVL 75B R
-
Page 1: Table Of Contents
Care and maintenance, 6 Description of the tumble dryer, 7 How to carry out a drying cycle, 9 Programmes and options, 10 Laundry, 13 IDVL 75B R Troubleshooting, 14 Assistance, 15 www.indesit.com This symbol reminds you to read this instruction manual. -
Page 2: Installation
Installation Where to install the tumble dryer dryer is used very often. The hose adaptor must be fitted correctly, in order to prevent damp air from coming back into If the dryer is installed below a worktop, the room. ensure there are 10 mm between the upper panel Window ventilation hole of the dryer and any... - Page 3 rear surface placed against a wall. Electrical connections Before plugging the appliance into the so- cket, check the following: Make sure your hands are dry. The socket must have an earth connection. The socket must be able to withstand the machine’s maximum power output as indica- ted on the rating plate (see Description of the tumble dryer).
-
Page 4: Warnings
Warnings warm items inside. This appliance has been designed and built according to international safety standards. These warnings are given for • Clean the filter after each use (see safety reasons and must be followed carefully. Maintenance). General safety • Do not allow lint to collect around the dryer. •This appliance can be used by children •... - Page 5 Brand manufacturer of the fabric softener product. INDESIT Model • Do not tumble dry undergarments that contain metal reinforcements eg. bras IDVL 75 BR.9 UK IDVL 75 BRS.9 UK IDVL 75 BRK.9 UK with metal reinforcing wires.
-
Page 6: Care And Maintenance
Care and maintenance Disconnecting the power supply Do not use solvents or abrasives. Have the dryer checked regularly by authorised technical ! Disconnect the dryer when not in use or personnel in order to ensure that the electrical and mechani- during cleaning and maintenance operations. -
Page 7: Description Of The Tumble Dryer
Description of the tumble dryer Front side Rear side Control panel Drum Air inlet Rating Plate Serial number and model Caution, high number Filter Connection for temperature ventilation hose Control panel Options On/Off buttons and Start/Pause button button indicator lights and indicator light Programme Clean filter... - Page 8 ON/OFF/Reset button Pressing the button normally will cause the machine to switch on or off. If the button is pressed for 3 seconds while the dryer is in function, the machine will switch off and the running cycle will reset. Programme selection knob Allows for setting the programme: turn until the indicator points towards the desired programme (see Starting and selecting a programme).
-
Page 9: How To Carry Out A Drying Cycle
How to carry out a drying cycle Starting and selecting a programme 1. Plug the dryer into the power supply socket. 2. Select the programme according to the type of laundry (see Laundry). 3. Open the door, ensure that the filter is clean and securely placed. 4. -
Page 10: Programmes And Options
Programmes and options Programme chart Max. load Cycle Programme Compatible options (kg) duration* Energy Saver Delay timer - Post Care 1 Eco Cotton 2 Eco Synthetics Delay timer - Post Care Cottons 3 Standard Cotton** Delay timer - Light Drying - Post Care 120' 4 Cotton Extra Dry Delay timer - Post Care... - Page 11 Wool This programme is specific for items that withstand tumble drying and are labelled with the symbol. It is suitable for loads of up to 1 kg (about 3 jerseys). We recommend turning the garments inside out before drying them. Garments dried with this programme are usually ready to be worn, although the edges of heavier garments may be slightly damp.
- Page 12 Options The options allow for customising the selected programme according to one’s own needs. Delay timer The start of some programmes (see Programmes and options) may be delayed up to 9 hours. Press the button repeatedly to enter the desired delay time. Before setting a delayed start, make sure that the filter is clean.The drum will rotate occasionally before the drying programme starts to prevent the formation of creases.
-
Page 13: Laundry
Laundry Sorting laundry Drying times • Check the symbols on the care labels of the various Drying times are approximate and may vary depending on garments to verify whether the garments can be safely the following: tumble dried. • Sort laundry according to the type of fabric. •... -
Page 14: Troubleshooting
Troubleshooting If you feel that the dryer is not working properly, consult the following troubleshooting suggestions before contacting the Technical Assistance Centre (see Assistance). The dryer does not start. • The plug has not been inserted far enough into the socket to make contact. •... -
Page 15: Assistance
Assistance Spare parts Before contacting the Technical Assistance Centre: • Follow the troubleshooting guide to check whether This dryer is a complex machine. Attempting to repair it problems can be solved personally (see Troubleshooting). personally or having an unqualified person may put the •... - Page 16 For local repair engineers - 03448 111 606 ROI - 0818 313 413 UK standard local rate applies ROI local Irish rate applies For Parts and Accessories visit: parts.indesit.co.uk/shop Please remember to register your appliance at www.indesitservice.co.uk to activate your 10 year parts guarantee.
