Toshiba Tecra A9-S9016X Specifications

Tecra A9 Detailed Product Specification
Model Name Description
A9 S9016X Genuine Windows® XP Professional, Intel® Core™ 2 Duo Processor T7500, 2048MB
DDR2, 160GB 5400rpm (SATA), DVD-SuperMulti, 15.4" WSXGA+ Display, NVIDIA
Quadro NVS 130M with 256MB VRAM, Intel® PRO/Wireless 4965AGN (802.11a/b/g/n),
Bluetooth v2.0 + EDR, Bridge Media Adapter, 3-year standard limited warranty
C1 2
Operating System
• Genuine Windows® XP Professional
Processor and Chipset
Intel® Centrino® Pro processor technology featuring:
• Processor
o Intel® Core™ 2 Duo Processor T7500
2.2GHz, 4MB L2, 800MHz FSB with 64-bit
• Chipset
o Mobile Intel® PM965 Express Chipset
• Wireless LAN
o Intel® Wireless WiFi Link 4965AGN (802.11a/g/n)
• Wired LAN
o Intel® Pro 82566MM 10/100/1000 Ethernet
6
Memory
• Configured with 2048MB (1024MB x 2) PC2-5300 DDR2 SDRAM
• 2 memory slots
• 2048MB (Min)/4096MB (Max), with 512MB, 1024MB or 2048MB PC2-
4200 or PC2-5300 DDR2 memory modules
7
Hard Disk Drive
• 160GB (5400 RPM) Serial ATA hard disk drive; 9.5mm height
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (10x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (4x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (4x)), DVD+RW (8x), DVD-
RAM (5x)
9
Display
• 15.4" diagonal widescreen TFT LCD display at 1680x1050 native
resolution (WSXGA+)
10
Graphics
• NVIDIA Quadro NVS 130M with 256MB of dedicated graphics memory
Sound
• Built-in stereo speakers
• Sound Volume Control Dial
• Built-in microphone
Input Devices
• 86 key US keyboard
• Toshiba Accupoint® II and TouchPad™ dual pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
o Toshiba Assist button
o Presentation Button
Communications
• Modem 11
• Intel® Pro 82566MM 10/100/1000 Ethernet
• Integrated Wi-Fi® compliant wireless:
o Intel® Wireless WiFi Link 4965AGN (802.11a/g/n)
• Bluetooth® version 2.0 plus Enhanced Data Rate (EDR)
• Expandability
• One PCMCIA – Type II/Type I Card Slot
• Bridge Media Adapter
1
3
4
C1
5
8
12
13
© Copyright 2006 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
TECRA A9 S9016X Rev. 1.16 2007-09-11 KR T20070710 CB1.10
This product specification is variable and subject to change prior to product launch.
o Secure Digital, Memory Stick™, Memory Stick PRO™, Multi
Media Card, xD Picture Card [shared slots]
o Secure Digital slot supports SDIO
• Ports
• Video
o RGB (monitor) output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK™ IEEE-1394
o Modem - RJ11
o LAN - RJ45
o USB v2.0 – 3 ports
o Serial port
o Docking connector
• Supported on Toshiba Express Port Replicator
o RGB (monitor) output port
o DVI-D output port
o USB v2.0 – 4 ports
o Ethernet port
o AC adapter and security lock supported
Physical Description
• Dimensions (WxDxH Front/H Rear): 14.4" x 10.6" x 1.18"/1.53" without
feet
• Weight: Starting at 6.35 lbs. depending upon configuration
• LCD Cover Color: Titanium Silver
Power
• 75W (15V x 5A) 100-240V AC Adapter.
• Dimensions (WxDxH): 5.0" x 2.01" x 1.20"
• Weight: starting at 0.78 lbs
15
Battery
• (5100mAh) Lithium Ion battery pack
• Dimensions (WxDxH): 8.15" x 0.79" x 1.77"
• Weight: starting at 0.74 lbs
• Battery Life (measured by MobileMark™)
o Included 6-cell battery: 4 hours, 17 minutes
Toshiba EasyGuard®
• Protect & Fix
o Shock Absorbing Design
HDD Shock Absorber
LCD Panel Shock Absorber
LCD Inverter Shock Absorber
Chassis Shock Protector
o Hard Disk Drive Protection
3D Accelerometer
HDD Dome Shock Protector
HDD Shock Absorber
o Spill-Resistant Keyboard
o TOSHIBA PC Diagnostic Tool
o Key Component Access
• Secure
o Multiple-Level Password Utilities
o Fingerprint Reader (includes software for password and identity
management)
o UPEK Protector Suite™ QL
o Infineon TPM Software Professional Package
o Trusted Platform Module v1.2
o TOSHIBA Secure Digital Token Utility
o Reinforced Security Cable Lock Slot
Part Number UPC
PTS53U-01P00S 032017949676
16
17
18
19
14
Page 1 of 5
