Summary of Contents for Jefferson Dynamo JEFSTACHG230
- Page 1 Dynamo STARTER CHARGER JEFSTACHG230 User Manual v.1.1...
- Page 2 USER MANUAL v1.1 JEFSTACHG230 230A STARTER CHARGER • 230V ~ 50Hz www.jeffersontools.com...
-
Page 3: Table Of Contents
Important: Please read all these instructions before operating this product and save these instructions. This manual has been compiled by Jefferson Tools and is an integrated part of the product with which it's enclosed and should be kept with it for the future reference. -
Page 4: Introduction
USER MANUAL v1.1 JEFSTACHG230 230A STARTER CHARGER • 230V ~ 50Hz INTRODUCTION • 230A single phase battery / starter charger with sturdy plastic and steel housing and carry handle • 12/24V battery voltage • Well ventilated to help maintain low temperatures during operation •... -
Page 5: Safety Warnings
Never use this equipment or modify it in any way that has not been specifically recommended by the manufacturer. Contact Jefferson Tools for all information relating to the repair and maintenance of this equipment. Contact a qualified electrician for advice on any issues relating to electrical safety in your working environment. -
Page 6: Equipment Safety Guidelines
• Ensure the equipment is in good order and condition before use. Do not use the equipment if it is damaged. Contact your Jefferson Dealer for advice on repair and replacement parts. Do not use any non-approved approved parts for maintenance or repair. -
Page 7: Electrical Safety
The risk of electric shock can be minimised by the correct use of the appropriate electrical safety devices. If a fuse blows, ensure it is replaced with an identical fuse type and rating (please refer to the equipment specification plate). Contact Jefferson Tools for advice and information on genuine parts. -
Page 8: Operation Guide
USER MANUAL v1.1 JEFSTACHG230 230A STARTER CHARGER • 230V ~ 50Hz OPERATION GUIDE Preparing the Battery 1. If it is necessary to remove the battery from the vehicle to charge, always remove grounded terminal from battery first. Make sure all accessories in the vehicle are off, so removal will not cause an arc. - Page 9 USER MANUAL v1.1 JEFSTACHG230 230A STARTER CHARGER • 230V ~ 50Hz Charging A Battery That Is Installed In A Vehicle WARNING: Marine (boat) batteries should be removed and charged on shore. To charge it on board requires equipment specially designed for marine use. Figure 3.
-
Page 10: Maintenance
Keep the outer casing clean by wiping with a soft cloth. Ensure that the battery charger does not come into contact with liquid. • Do not attempt to open the equipment housing. There are no user-serviceable parts inside. Contact Jefferson Tools for information concern- ing use, applications, parts and servicing. -
Page 11: Environmental Protection
USER MANUAL v1.1 JEFSTACHG230 230A STARTER CHARGER • 230V ~ 50Hz ENVIRONMENTAL PROTECTION Recycle any packaging and unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely unserviceable, reaches the end of its working life and requires disposal, drain off any fluids (if applicable) into approved containers and dispose of the product and the fluids according to local regulations. -
Page 12: Parts List & Diagram
USER MANUAL v1.1 JEFSTACHG230 230A STARTER CHARGER • 230V ~ 50Hz PARTS DIAGRAM PARTS LIST - MAIN ASSEMBLY Description Front Panel (Metal) 1-2 (Charge Rate Switch) Air Vents / Grilles 12V Connection Terminal Control Panel Rear Panel (Metal) Front Housing (Plastic) 13A UK Plug Output Current Meter (Ammeter) Rectifier Bridge... -
Page 13: Ec Declaration Of Conformity
JEFSTACHG230 230A STARTER CHARGER • 230V ~ 50Hz EC Declaration of Conformity We, Jefferson Professional Tools & Equipment, as the authorised European Community representative of the manufacturer, declare that the following equipment conforms to the requirements of the following Directives:... -
Page 14: Limited Warranty Statement
Jefferson will assume both the parts and labour expense of correcting defects during the stated warranty periods below. All warranty periods start from the date of purchase from an authorised Jefferson dealer. If proof of purchase is unavailable from the end user, then the date of purchase will be deemed to be 3 months after the initial sale to the distributor. - Page 15 • A Warranty Returns form will be sent to you for completion and return by post or fax, together with details of your nearest authorised Jefferson repair centre. On receipt of this form Jefferson will arrange to collect the equipment from you at the earliest convenience.
-
Page 16: Www.jeffersontools.com
Before attempting to use this product please read all the safety precautions and operating instructions outlined in this manual to reduce the risk of fire, electric shock or personal injury. Jefferson Tools, Herons Way, Chester Business Park, Chester, United Kingdom, CH4 9QR Tel.
