Toshiba Tecra A3 Specifications

TOSHIBA
Tecra A3
Model Name Description
A3-S611 Intel Pentium® M Processor 730 [1.60GHz, 2MB L2 cache, 533MHz FSB], 15.0" diagonal
standard TFT active-matrix LCD display at 1024x768 native resolution, 40GB (4200 RPM),
DVD-CDRW, 256MB, 6-cell, Integrated Intel Pro/Wireless Network Connection 2200BG
(802.11b/g), Serial/Parallel/Fast Infrared, Microsoft Windows XP Professional, 1-year standard
limited warranty
A3-S631 Intel Pentium® M Processor 730 [1.60GHz, 2MB L2 cache, 533MHz FSB], 15.0" diagonal
standard TFT active-matrix LCD display at 1024x768 native resolution, 40GB (4200 RPM),
DVD-CDRW, 256MB, 6-cell, Integrated Intel Pro/Wireless Network Connection 2200BG
(802.11b/g), Serial/Parallel/Fast Infrared, Microsoft Windows XP Professional, 3-year standard
limited warranty
System Characteristics
Operating System
•
Microsoft® Windows® XP Professional
Intel® Centrino™ Mobile Technology featuring:
2
Processor :
•
Intel Pentium® M Processor 730 [1.60GHz, 2MB L2 cache,
533MHz FSB]
Chipset
•
Mobile Intel 915GM Express Chipset
Integrated Wi-Fi™ compliant wireless LAN
•
Intel PRO/Wireless 2200BG (802.11b/g),
3
Memory
•
256MB (Min)/2048MB (Max), 256MB memory with 1 available
memory slot for 256MB, 512MB, or 1024MB PC2700 DDR333
SDRAM 2.5V SODIMM memory modules;
•
Both slots may be occupied on models configured with 512MB.
Mass Storage
4
Hard Drive
•
40GB (4200 RPM); Enhanced IDE (ATA-5) hard disk drive;
9.5mm height; user removable
Optical Disk Drive:
•
Fixed Bay CD-RW/DVD drive:
Maximum Speed:
CD-ROM (24x:read), CD-R (24x:write), CD-RW
(24x:write), DVD-ROM (8x:read)
Compatibility:
CD-ROM (read), CD-R (read/write), CD-RW (read/re-
write), DVD-ROM (read), DVD-R (read), DVD-RW (read),
DVD+R (read), DVD-RAM (read)
5
Display
•
15.0" diagonal standard TFT active-matrix LCD display at
1024x768 native resolution
•
Brightness Control
Graphics
•
Intel Graphics Media Accelerator 900; up to 128MB of graphics
memory is taken from the main memory via UMA (Unified
6
Memory Architecture)
Input Devices
•
Keyboard
85 key US keyboard, 2.7mm key stroke, 6mm keyboard
o
height, 19.05mm key pitch
Hot Key Functions (FN); please see electronic User's Guide
o
for more information
Windows Key Function
o
Application Key Function
o
•
Pointing Device:
Toshiba dual pointing device
o
TouchPad™ Enable/Disable (FN+F9 or by help of software)
o
•
Others:
Toshiba Console Button (Toshiba Assist)
o
Presentation Button
o
Expandability
•
2 main memory slots. Both slots may be occupied.
•
1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
1
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
Tecra A3 BTS Rev. 1-01 2005-01-19 BSF CB 1.00
Communications
•
Integrated V.92 modem
•
Marvell 88E8036 onboard network interface chip for 10/100
Base-TX Ethernet
•
Integrated Intel Pro/Wireless Network Connection 2200BG
8
(802.11b/g)
Ports
•
Serial Port
•
Parallel port
•
RGB (monitor) port
•
Fast Infrared (4Mbps) port
•
3 Universal Serial Bus (USB) ports (v2.0)
•
TV-out (S-Video)
•
RJ-11 modem port
•
RJ-45 LAN port
•
i.LINK(tm) IEEE-1394
•
External Microphone jack (monaural)
•
Headphone jack (stereo)
•
240 pin docking connector
Physical Description
•
Dimensions (WxDxH Front/H Rear): 13.3" (338.0mm) x 11.0"
(279.7mm) x 1.27'' (29.7mm)[F]/1.46'' (37.2mm)[R] without feet
•
9
Weight : Starting at 6.00 lbs. (2722 g) depending upon
configuration
•
Indicators: Power, DC-In, Primary HDD Access, Optical Disk
Drive Access, CapsLock, Arrow Mode, Numeric Mode, Main
Battery Charging Status, System Sleep/Suspend Status,
Wireless Communication
•
Case material: Polycarbonate ABS
Sound
•
Realtek ALC250 Software Sound
•
16-bit stereo; Built-in stereo speakers,
•
External microphone port (monaural)
•
3D Sound Support, Direct 3D Sound; DirectSound, Direct Music,
MIDI (playback) Support
•
Sound Volume Control Dial
Power Supply
•
75W (15V x 5A) Auto sensing external AC Adapter, 100-240V /
50-60Hz frequency (Universal) input.
•
Dimensions (WxDxH): 5.35'' (136.0mm) x 2.09'' (53.0mm) x
1.18'' (30.0mm)
•
Weight: starting at 0.88 lb. (400 g)
10
Battery
•
6-cell (10.8V x 4300mAh) rechargeable, removable Lithium Ion
(Li-Ion) battery pack
•
Weight: starting at 0.75 lb. (340 g)
•
Dimensions (WxDxH): 8.15'' (207.0mm) x 0.91'' (23.0mm) x
2.13'' (54.0mm)
•
Battery Life: Up to 3 hours 46 minutes (measured by
MobileMark™) (6-cell battery)
•
Recharge Time: Main Battery – approximately 4.0 hours
(system off)/approximately 12.0 hours (system on)
Part Number UPC Code
PTA30U-014004 032017316829
PTA30U-014005 032017316850
7
11
