Kohler WELLINGTON WATERGUARD K-3415 Installation Instructions Manual

1. BEFORE YOU BEGIN
HOW TO USE THESE INSTRUCTIONS
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
INSTALLER HAZARD NOTIFICATION
WARNING: Risk of injury or product damage.
Handle vitreous china products very carefully.
Vitreous china can break and chip if you overtighten
bolts and nuts.
NOTE: Follow all local plumbing codes.
PRODUCT REQUIREMENTS
S
Since all toilets do not have the same supply
rough-in, you may have to change the location of
the supply stop to install this toilet.
S
Closet flange must be 12" on-center from wall.
S
Seat post holes are on 5-1/2" centers.
S
This toilet is designed to flush using 3.5 gallons
when the tank refill time is adjusted to between 50
and 55 seconds. Tank refill time is measured from
the moment the flapper ball reseats to the time
water stops flowing through the refill tube. Slightly
longer refill time may be necessary to compensate
for permanent or temporary low water pressure. To
adjust the refill time, see "To Adjust Refill Time",
on Page 5.
MATERIALS REQUIRED
S
Closet flange
S
Toilet gasket (wax seal)
S
Toilet T-bolts (2) 5/16" diameter
S
Toilet setting compound (optional)
S
Toilet supply shut-off valve, 3/8" required
AA
106017-2- (A)
WELLINGTON WATERGUARD
R
VITREOUS CHINA
SIPHON VORTEX TOILET
All information in these instructions is based on the latest
product information available at the time of publication.
Kohler Co. reserves the right to make changes in product
characteristics, packaging, or availability at any time
without notice.
These instructions contain important care, cleaning, and
warranty information – please leave for the consumer.
PRODUCT PROPERTIES
S
Distance from the rim to the water surface is 6".
S
2-1/4" passageway.
S
For roughing-in and overall dimensions, see
Fig. #2.
S
Fixture dimensions are nominal and conform to
tolerances by ANSI standards (A112.19.2).
ORDERING INFORMATION
Wellington Waterguardr Toilet
When specified:
3/8" supply . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor bolts (pr.) . . . . . . . . . . . . . . . . . . . . . . . . . .
NOTE: For service parts ordering information, see
separate Service Parts document enclosed with the
product.
TOOLS REQUIRED
S
10" adjustable wrench
S
12" pipe wrench
S
Screwdriver
S
Tape Measure
S
Tubing cutter
S
Level
S
Putty knife
S
Hacksaw/metal file (for shortening T-bolts)
NOTE: Site preparation may require additional tools.
R
. . . . . . . . . . . . . . K-3415
K-7638
21401
E1998 Kohler Co.
