Summary of Contents for Syncro View K67000M1
- Page 1 Syncro View Serial LCD Repeater Panel (K67000M1, K67000F1, K67750M1, K67750F1 K67001M1, K67001F1, K67751M1, K67751F1) Operation and Maintenance Manual Man-1092 Issue 06 June 2013 www.acornfiresecurity.com...
-
Page 2: Table Of Contents
8. Processor and watchdog reset switches ............... 8 9. Connecting to the Syncro panel ................. 9 10. Connections to Syncro View ................... 10 11. Adding a Syncro View to the Syncro panel ............... 11 Page 2 of 12 Product Manuals/Man-1092_Syncro_View_06... -
Page 3: Introduction
The Syncro View repeater panel will be overridden and can not take control of the panel to which it is connected if the main control panel is at access level 2. -
Page 4: Mounting
www.acornfiresecurity.com 2.2 Mounting Surface mounting units should be mounted on a dry, flat surface, at eye height to the display and in a level position such that the enclosure is not distorted. Screws or bolts of a minimum of 4mm diameter must be used to mount the enclosure in all three mounting positions. -
Page 5: Technical Specification
www.acornfiresecurity.com 3. Technical specification Table 1 - Electrical specifications Construction 18SWG Mild steel - IP30 rated Cable entry 20mm knockouts 5 in top, 5 in rear and 1 in the side Finish BS 00-A-05 light grey, fine texture. Weight 5Kg maximum Mains supply (Mains powered 230V AC +10% - 15% (20 Watts maximum) models only) -
Page 6: Syncro View Fascia
4. Syncro View fascia K67001 and K67750 models with enable controls keyswitch K67000 and K67751 models without enable controls keyswitch. Page 6 of 12 Product Manuals/Man-1092_Syncro_View_06 www.acornfiresecurity.com... -
Page 7: Connecting To The Circuit Board
www.acornfiresecurity.com 5. Connecting to the circuit board All connections for field wiring are to a single row of terminals along the bottom of the circuit board. Shielded fire alarm cable such as FP200 and metal cable glands must be used for all connections to the unit. -
Page 8: Processor And Watchdog Reset Switches
8. Processor and watchdog reset switches The Syncro VIEW is controlled by a microprocessor, which will re-start itself and continue to run if it stops for any reason due to severe electrical interference such as an electrical storm. To ensure that the unit is not being subjected to continual, undue interference which may effect its proper operation, a watchdog (W/DOG) LED indicator is latched on and a fault condition signalled to the control panel. -
Page 9: Connecting To The Syncro Panel
www.acornfiresecurity.com 9. Connecting to the Syncro panel Page 9 of 12 Product Manuals/Man-1092_Syncro_View_06 www.acornfiresecurity.com... -
Page 10: Connections To Syncro View
From Syncro panel AUX 24V - terminal To next Syncro View repeater 0V terminal From Syncro panel COMMS + terminal To next Syncro View repeater COMM 1 - terminal From Syncro panel COMMS - terminal To next Syncro View repeater COMM 1 + terminal... -
Page 11: Adding A Syncro View To The Syncro Panel
11. Adding a Syncro View to the Syncro panel The Syncro View repeater must be added to the system by configuring the Syncro panel using the Loop Explorer configuration utility. Click on the site name in the left hand window pane to show the option to add panels or repeaters to the system. - Page 12 Once the configuration file has been loaded into the panel the panel will now expect to see a Syncro View at the address allocated to it and will show a fault condition if the Syncro View is not fitted or is removed.
