SOLARE CHARBON (SO2300)
MANUALE DI MONTAGGIO, USO E
MANUTENZIONE
ASSEMBLY, USE AND MAINTENANCE MANUAL
MONTAGE, GEBRAUCHS UND WARTUNGSANLEITUNG
MANUEL DE MONTAGE, D'UTILISATION ET DE
MAINTENANCE
MANUAL DE MONTAJE, USO Y MANTENIMIENTO
-
La colonna doccia solare dal design
completamente nero. La struttura del
serbatoio in acciaio inox, a sezione tonda,
rende questa colonna unica nel suo genere
e garantisce grande uniformità di
assorbimento del calore.
-
The solar shower column with a completely
black design. The structure of the stainless
steel tank, with a round section, makes this
column unique in its kind and guarantees
great uniformity of heat absorption.
-
Die Solarduschsäule mit komplett
schwarzem Design. Die Struktur des
Edelstahltanks mit rundem Querschnitt
macht diese Säule in ihrer Art einzigartig
und garantiert eine große Gleichmäßigkeit
der Wärmeabsorption.
-
La colonne de douche solaire au design
entièrement noir. La structure du réservoir
en acier inoxydable, de section ronde, rend
cette colonne unique en son genre et
garantit une grande uniformité
d'absorption de chaleur.
-
La columna de ducha solar con un diseño
completamente negro. La estructura del
tanque de acero inoxidable, de sección
redonda, hace que esta columna sea única
en su género y garantiza una gran
uniformidad de absorción de calor.
