SolarGoesGreen SGG-S24-FLPL Instructions

SolarGoesGreen SGG-S24-FLPL
READ AND FOLLOW ALL INSTRUCTIONS BEFORE OPERATING YOUR SOLAR LIGH T.

DESCRIPTION

The SGG-S24-FLPL is designed as a stand-alone flag pole light which automatically illuminates at dusk. It is completely solar
powered and must be installed in position where the solar panel will receive the maximum sun per day. It's energy-saving,
auto switches on/off, and has an appealing design.
The unit has twin spotlights with 12 super bright LEDs and two Li-ion rechargeable batteries which are easily replaced. The
SGG-S24-FLPL can easily be installed on poles as narrow as 3".

PARTS

Solar panel with integrated battery box
2 each-12 Super Bright LED lamps
2 each - Pole mounts

INSTALLATION

I. Solar Flagpole Light
INSTALLATION OF THE SOLAR PANEL
•
Choose a place to locate the unit where there is abundant and unobstructed sunshine during the day. Any cover or
shade on the solar panel will affect its performance to charge the batteries resulting in a shorter run time of the lights
during the night (Fig. 1 ). IDEAL LOCATION OF THE SOLAR PANEL WILL BE FACING SOUTH AT A 45 DEGREE ANGLE TO THE
HORIZON.
• Take off the adjustable arm part of LED lamp. Remove and save the machine fine threaded screw for future
use. (Fig.9)
• Attach lamp to pole black PVC mount base by using coarse threaded screw provided.
• Mount Solar Panel to pole mount base using provided butterfly nut ( Fig.10). Adjust lamp initial aiming
direction before fixing it.
• Attach the pole light unit to flagpole by using stainless steel clamps. There are different sizes of clamps
suitable for different size of flagpole. (Fig.11)
• After installation, connect spotlight wire with solar panel wire and switch the unit on the solar panel. The
light will automatically be operational when the panel detects that it's dark enough.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
