TOSHIBA
Satellite P30 Series
Model Name
Description
Satellite P30-S701TD
Intel® Celeron® D Processor 340 [2.93GHz, 256KB L2, 533MHz FSB]; 256MB PC2700 DDR333
SDRAM 2.5V SODIMM Memory, 40GB(4200rpm), CD-RW/DVD-ROM, 17.0" diagonal widescreen
TruBrite™ active matrix LCD display at1440 x 900 native resolution, Integrated ATI RADEON® XPRESS
200M GPU, CD/Shortcut buttons, Integrated Atheros 802.11b/g Wireless-LAN supporting Atheros
SuperG™ technology, Built-in harman/kardon® stereo speakers, Microsoft Windows XP Professional, 1
year standard limited warranty
System Characteristics
Operating System
Microsoft® Windows® XP Professional
2
Processor
Choice of Processors:
Intel® Celeron® D Processor 340 [2.93GHz, 256KB L2, 533MHz
FSB];
Intel Pentium® 4 Processor 550J supporting HT Technology
[3.40GHz, 1MB L2, 800MHz FSB]; or
Intel Pentium 4 Processor 560J supporting HT Technology
[3.60GHz, 1MB L2, 800MHz FSB];
Chipset
ATI RADEON® XPRESS 200M
3
Memory
256MB (Min)/2048MB (Max) PC2700 DDR333 SDRAM 2.5V
SODIMM Memory; configurable from 256MB to 2048MB. Both
slots may be occupied.
Mass Storage
4
Hard Disk Drive
Choice of Hard Disk Drives: 40GB (4200 RPM), 60 (4200 RPM),
80GB (4200 RPM), or 100GB (4200 RPM). Enhanced IDE (ATA-
5) hard disk drive; 9.5mm height; user removable
Optical Disk Drive:
Choice of:
Fixed Bay CD-RW/DVD drive:
5.25" EIDE, 12.7mm height.
Maximum Speed:
CD-ROM(24x:read), CD-R(24x:write), CD-RW(10x:write),
DVD-ROM(8x:read),
Compatibility:
CD-ROM(read), CD-R(read/write), CD-RW(read/write),
DVD-ROM(read)
Fixed Bay DVD Super Multi Drive (Single Layer);
5.25" EIDE, 12.7mm height.
Maximum Speed Capability:
CD-ROM (24x read), CD-R (16x write), CD-RW (8x write),
DVD-ROM (8x read), DVD-R (8x write), DVD-RW (4x
write), DVD+R (8x write), DVD+RW (4x write), DVD-RAM
(3x write)
Compatibility
CD-ROM(read), CD-R(read/write), CD-RW(read/write),
DVD-ROM(read), DVD-R(read/write), DVD-
RW(read/write), DVD+R(read/write),
DVD+RW(read/write), DVD-RAM(read/write)
Fixed Bay DVD Super Multi Drive (Double Layer);
5.25" EIDE, 12.7mm height.
Maximum Speed Capability:
CD-ROM (24x read), DVD-ROM (8x read), CD-R (24x
write) CD-RW (10x write) DVD-R (8x write) DVD-RW (4x
write), DVD+R (8x write), DVD+R (Double Layer) (2.4x
write) DVD+RW (4x write) DVD-RAM (3x write)
Compatibility
CD-ROM(read), CD-R(read/write), CD-RW(read/write),
DVD-ROM(read), DVD-R(read/write), DVD-
RW(read/write), DVD+R(read/write),
DVD+RW(read/write), DVD-RAM(read/write)
5
Display
Choice of:
17.0" diagonal widescreen TruBrite™ active matrix LCD display at
1440x900 native resolution;
17.0" diagonal widescreen active matrix LCD display at
1680x1050 native resolution
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
1
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
Satellite P30-Series BTO Revision 1-02 2005-03-30 PT CB V1.0
Brightness Control [keyboard: Fn+F6 (decrease brightness) or
Fn+F7 (increase brightness)]
Graphics Controllers
Choice of Graphics Controllers:
Integrated ATI RADEON® XPRESS 200M; up to 128MB of
graphics memory is taken from the main memory via UMA
(Unified Memory Architecture)
ATI MOBILITY™ RADEON® X600 with dedicated 128MB DDR
6
SDRAM;
or,
ATI MOBILITY™ RADEON® X600 with dedicated 64MB DDR
SDRAM
Input Devices
Keyboard: Full sized 85 keys with 12 function keys, 2.7mm key
stroke, 6mm height; Dedicated Microsoft Windows & Application
keys support; HotKey function
Pointing Device: TouchPad™
Hot Key Functions (FN); please see electronic User's Guide for
more information
Buttons: CD Control Functions (Skip to Previous Track, Play,
Stop, and Skip to Next Track)
Expandability
2 Expansion memory slots (including Main Memory). Both slots
may be occupied.
1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
Bridge Media Adaptor (Secure Digital®, Memory Stick™, Memory
Stick Pro™, SmartMedia™, Multi Media Card, xD-Picture [shared
slots])
Communications
Integrated V.92 modem
Realtek 10/100Base-TX Ethernet
Choice of Integrated Wireless-LAN:
Integrated Atheros 802.11b/g Wireless-LAN supporting Atheros
9
SuperG™ technology
Integrated Atheros 802.11a/b/g Wireless-LAN supporting Atheros
SuperAG™ technology
Ports
RGB (monitor) port
TV-Out port (S-Video)
3 Universal Serial Bus (USB) port (v2.0)
External Microphone jack
Headphone jack
RJ-45 LAN port
RJ-11 modem port
i.LINK™ IEEE® 1394
Physical Description
Dimensions (WxDxH Front/H Rear): 16.54'' (420.0mm) x 11.54''
(293.0mm) x 1.67'' (42.5mm)[F]/2.17'' (55.0mm)[R]
10
Weight
: Starting at 9.79 lbs. (4440 g) depending upon
configuration
LED Indicators: DC-In, Power, Primary Battery, Hard Drive,
CD/DVD ROM, Wireless indicator, Caps Lock, Arrow Lock,
Numeric Lock, Main Battery Charging Status, Sleep Suspend
Mode, SD Card, Multiple Digital Media Card Slot.
Sound
Realtek ALC250; 16-bit stereo supported audio format
Built-in harman/kardon® stereo speakers,
3D Sound support, Direct3D Sound support; DirectSound support,
MIDI (playback) support, Direct Music support
Sound Volume Control Dial
Part Number
PSP33U-0JF00E
7
8
; or,
