Superlux HMD660 Quick Start Manual

HMD660
PROFESSIONAL HEADSET WITH
INCORPORATED DYNAMIC MIC

Description

The HMD660 series of stereo headsets are designed for
the professionals that demand high quality monitoring
plus communication.
Their precision acoustic design, integrating drivers, ear
padding, and headband, combined with a professional
dynamic microphone for a balanced tone with high dy-
namic range make these headsets perfect for both listen-
ing and talking. They are ideal for live broadcasts, DJ's,
desktop video conferences, on-line gaming and multime-
dia applications.

Features

• Excellent details, clear midrange and extended highs.
• Professional headset derived from the HD660 studio
headphone.
• Integrated professional dynamic microphone PRA20
with cardioid polar pattern gives high gain before
feedback.
HMD660: 3-meter (9.8') coil spring cord, open end.
HMD660X: 3-meter (9.8') coil spring cord, screw-on 3.5 mm (1/8")
stereo headphone plug with a 3.5 mm (1/8") to 6.3 mm (1/4")
adapter and an XLR mic plug.
HMD660E: 3-meter (9.8') coil spring cord, screw-on 3.5 mm (1/8")
stereo headphone plug with a 3.5 mm (1/8") to 6.3 mm (1/4")
adapter and a 3.5 mm (1/8") stereo mic plug wired as mono.
HMD660 MICROPHONE
S11

Included

Windscreen
www.superlux.com.tw

Specifications

Headphones
Transducer principle
Sensitivity
Frequency Response 10 – 30,000 Hz
Max. Input Power
Rated Impedance
Caliper Pressure
Weight (w/o cable)
Microphone
Transducer principle
Polar Pattern
Frequency response
Sensitivity
Max. SPL
Rated Impedance
Carrying case
Dynamic, Closed-back
96 dB SPL (1 mW)
100 mW
150 Ω
(Copper-coated aluminium wire)
approx. 6 N
250 g (8.81 oz)
Dynamic
Cardioid
150 – 10,000 Hz
-55 ± 2 dB
136 dB SPL (THD ≤ 1% 1 kHz)
250 Ω
EN
