RTA X-PLUS C Series Instruction Manual

Stepping motor drives
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
X-PLUS C – X-PLUS S
STEPPING MOTOR DRIVES
INSTRUCTION MANUAL
R.T.A. s.r.l.
R.T.A.
DEUTSCHLAND GmbH
R.T.A. IBERICA
MOTION CONTROL SYSTEMS S.L.
MOTION CONTROL SYSTEMS
SERIES
R.T.A. s.r.l. – XPCSME03 – 12/20
Via E. Mattei – Frazione DIVISA
27020 MARCIGNAGO (PV)
Tel. +39.0382.929.855 - Fax +39.0382.929.150
Internet: http://www.rta.it - e-mail: info@rta.it
Bublitzer Straße, 34
40599 DÜSSELDORF (Germany)
Tel. +49.211.749.668.60-Fax +49.211.749.668.66
Internet: http://www.rta-deutschland.de
e-mail: info@rta-deutschland.de
C/Generalitat 22, 1° 3°
08850 GAVA – BARCELONA (Spain)
Tel. +34.936.388.805-Fax +34.936.334.595
Internet: http://www.rta-iberica.es
e-mail: info@rta-iberica.es

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X-PLUS C Series and is the answer not in the manual?

Questions and answers

Summary of Contents for RTA X-PLUS C Series

  • Page 1 STEPPING MOTOR DRIVES INSTRUCTION MANUAL Via E. Mattei – Frazione DIVISA 27020 MARCIGNAGO (PV) R.T.A. s.r.l. Tel. +39.0382.929.855 - Fax +39.0382.929.150 Internet: http://www.rta.it - e-mail: info@rta.it Bublitzer Straße, 34 40599 DÜSSELDORF (Germany) R.T.A. Tel. +49.211.749.668.60-Fax +49.211.749.668.66 DEUTSCHLAND GmbH Internet: http://www.rta-deutschland.de e-mail: info@rta-deutschland.de...

  • Page 2: Table Of Contents

    INDEX NOTICES, MANUAL STRUCTURE AND TERMINOLOGY ........3 HAZARDS AND PRECAUTIONS ................4 GENERAL CHARACTERISTICS AND IDENTIFICATION ........6 INPUT AND OUTPUT LOGIC SIGNALS ..............7 POWER INPUTS AND OUTPUTS ................9 SETTING AND SIGNALLING.................. 11 DRIVE EXTERNAL CONNECTIONS ..............15 INSTALLATION AND ENVIRONMENT ..............

  • Page 3: Notices, Manual Structure And Terminology

    1 - NOTICES, MANUAL STRUCTURE AND TERMINOLOGY 1.1 - This manual covers the following items: • X-PLUS C and X-PLUS S series stepping motor drives in all their standard versions. • Standard characteristics of special versions of X-PLUS C and X-PLUS S series stepping motor drives (see chapter 1.2).

  • Page 4: Hazards And Precautions

    1.5 - INFORMATION This manual is conceived in a way to offer to the personnel involved in project and safety verification of a machine all information concerning characteristics, working conditions, application limits hazards and cautions about X-PLUS C and X-PLUS S series stepping motor drives. The knowledge of this information is essential for a correct project of machines, apparatus and systems in which the drives are used;...
  • Page 5 2.4 - CAUTION! All products considered in this manual are sub-assemblies without a direct function, foreseen to be integrated in a more complex machine. Only a professional assembler, expert in the field of motor drives and in their related problems, can install and put in service this component. It is exclusive responsibility of the designer of the complete machine or installation in which this component is used to take care of the safety and reliability of his project.

  • Page 6: General Characteristics And Identification

    3 - GENERAL CHARACTERISTICS AND IDENTIFICATION 3.1 - DIMENSIONS 116.8 (4.6) X-PLUS C X-PLUS S Ø 4.5 (0.18) Ø 4.5 (0.18) Dir. C. Off series X-PLUS SHIELD SHIELD Ø 4.5 (0.18) Ø 4.5 0.18) 23 (0.90) 94.7 (3.73) 46 (1.81) 46 (1.81) 129.8 (5.11) Fig.

  • Page 7: Input And Output Logic Signals

    4 - INPUT AND OUTPUT LOGIC SIGNALS All input and output logic signals are optically insulated among them and from internal power circuits. Positive and negative terminals are separately accessible. For all logic signals in the following we indicate the corresponding numbers of connector C2. An input signal is considered ON when a voltage is applied (Fig.
  • Page 8 Step & Direction input structure scheme FAULT output structure DRIVE Vmax = 45 Volt 5 < Vin < 24 Volt Imax = 50 mA DRIVE ≤ Vsat 0.8 Volt (@ 20 mA) R1 = 1.0 KOHM I=5mA NOTE: Insert a protection diode in parallel with the load in case of inductive load.

  • Page 9: Power Inputs And Outputs

    5 - POWER INPUTS AND OUTPUTS In this chapter drive power input and output and the necessary power supply for drive working are described. 5.1 - Drive power outputs are the four connections to stepping motor. Drive power inputs can be connected to the main or to an insulation transformer.
  • Page 10 5.4 - Table 2 and Table 3 show power inputs and outputs characteristics: TABLE 2 AC input X-PLUS C4 / X-PLUS S4 X-PLUS C2 / X-PLUS S2 110 - 230 110 - 230 (VOLT) Tolerance V Max input current (AMP) 440 - 920 440 - 920 Max input power...

  • Page 11: Setting And Signalling

    6 - SETTING AND SIGNALLING 6.1- INFORMATION X-PLUS C and X-PLUS S series drives are general purpose products which can be used to drive many different motor models in different kind of applications. For this reason they have a six positions DIP- SWITCH suitable to adapt drive characteristics to the specific motor and/or application.
  • Page 12 6.3- INFORMATION Table 4 shows the position of dips 1 and 2 (DP1) and the related motor nominal current. NOMINAL CURRENT SETTING X-Plus C4 / S4 X-Plus C2 / S2 DIP 1 DIP 2 Table 4 6.4- INFORMATION Tables 5a and Table 5b show damping mode settings depending on different model: - FOR X-PLUS C2 / C4 and X-PLUS S2 / S4: CURRENT PROFILE MANAGEMENT DIP 3...
  • Page 13 6.5- INFORMATION Table 6a and Table 6b operation mode setting: - FOR X-PLUS C2 / C4 and X-PLUS S2 / S4: RESOLUTION DIP 4 DIP 5 DIP 6 STEP/REV 4.000 2.000 1.000 ► 3.200 1.600 Table 6a - FOR X-PLUS C2.1 / C4.1 and X-PLUS S2.1 / S4.1: RESOLUTION STEP/REV DIP 5...
  • Page 14 6.6- The following list shows the meaning of the alert LEDs. = supply voltage is in the correct operating range. LED HV (green) : OFF = drive is not supplied or supply voltage is out of the correct range (in the second case also LED FAU is ON).

  • Page 15: Drive External Connections

    7 - DRIVE EXTERNAL CONNECTIONS 7.1- CAUTION! Dimensioning power for filter, switching and protection system and possible transformer. The basis to calculate this power is the total power required from drive and motor. It is the sum of the following terms: - Mechanical power delivered to load: mainly depending on application characteristics like friction, inertia, efficiency of mechanical transmission etc.
  • Page 16 MAIN (230 o 110 V ) Surge Protection Device STEPPING Fault MOTOR - Step AWG: Dir. min 28 Max 20 RESIDUAL C. Off Stranded conductor CURRENT DEVICE Aux 2 Aux 1 FUSES Torque section 7.2 ⋅ 5-7 lb in ⋅ 0.6-0.8 N m AWG: min 17 - Max 14 MOTOR...

  • Page 17: Installation And Environment

    8 - INSTALLATION AND ENVIRONMENT All products considered in this manual have the following common characteristics: 8.1 - Protection degree IP20: it is user responsibility to provide an adequate protection enclosure suitable to meet the standards regarding the specific application in which the products are used. 8.2 - CAUTION! Installation and work environment.

  • Page 18: Logic Interfacing Examples

    10 - LOGIC INTERFACING EXAMPLES In this chapter some interfacing techniques are shown. They have to be considered only as examples. The best way to interface the drive with the control system can be chosen only with a complete knowledge of control system and application needs.
  • Page 19 CONTROL X-PLUS C SYSTEM X-PLUS S SERIES DRIVE < V+ < 24 V PNP OUTPUT INPUT Fig. 10 Driving a X-PLUS C and X-PLUS S logic input from a control system with a PNP output. CONTROL SYSTEM X-PLUS C 5 VOLT OUTPUT X-PLUS S SERIES DRIVE OUTPUT...

  • Page 20: Application Notes

    11 - APPLICATION NOTES 11.1- INFORMATION Electromagnetic compatibility (directive 2014/30/CE). X-PLUS C and X-PLUS S series drives are BDM (Basic Drive Module), as defined in the EN 61800-3. Only a professional assembler, expert in the field of motor drives and in their EMC aspects, can install and put in service this component. R.T.A.
  • Page 21 11.1.3- Following these procedures is essential to realize an installation which complies with the requirements of 2014/30/CE directive. The real specific standard compliance have to be proved in the complete installation. In fact the effectiveness of the suggested application notes depends also on machine topology and on the measurement setup.
  • Page 22 Anyhow we recommend to contact RTA in case you need to exceed such limits. PHASE INDUCTANCE SUGGESTED LIMITS (mH) DRIVE TYPE...
  • Page 23 11.4- EQUALIZATION. Equalization changes the phase current profile in the medium speed range. If equalization is excluded, current profile reference approximates sinusoidal shape independently of speed. If equalization is active, current profile reference is switched to a square shape when speed exceeds a certain threshold: as a consequence, with equalization active, the torque output of the motor will be increased in the medium speed range.

  • Page 24: Sto Function (X-Plus S2 / S4 And X-Plus S2.1 / S4.1)

    STO FUNCTION (X-PLUS S2 / S4 and X-PLUS S2.1 / S4.1) 12.1- SYSTEM CONFIGURATION DESCRIPTION Fault - Step Dir. STO1 Emergency Safety Stop button output STO2 Feedback Monitor input SAFETY UNIT SHIELD Fig. 14 – Connection scheme. 12.2- STO FUNCTION Safe-torque-off function reduces injury risks and ensures the safety for those who work near moving parts of equipment.
  • Page 25 12.5- WARNING! RISK ASSESSMENT The drive meets the requirements safety standards above described. However, before activating safety function, make sure to assess the risks associated with the overall equipment to ensure complete safety. 12.6- WARNING! RESIDUAL RISK Even if STO function is active, the following risks remain. Please ensure the installation safety is maintained, even in case the below-indicated situations occur, through a correct risk assessment.
  • Page 26 STO1 and STO2 inputs structure scheme MONITOR output structure Vmax = 45 Volt DRIVE Vin = 24 Volt Imax = 50 mA DRIVE ≤ Vsat 0.8 Volt (at 10 mA) R1 = 3.3 KOHM R1 (1W) R2 = 390 OHM 18 Volt <...
  • Page 27 12.8- ENABLE / DISABLE STO: TIMING INDICATIONS The correct and stable enabling of STO function is effective after a maximum time of 20 ms after STO1 and STO2 switching off. Monitor Output indicates that STO function is active with a maximum delay of 20 ms from STO1 and STO2 input signals switch off (Figure 17).
  • Page 28 12.10- EDM (ERROR DETECTION MONITOR) Error Detection Monitor output is a signal to monitor problems in safe-torque-off circuit or between SAFETY UNIT and STO1 and STO2 inputs. The following Table 10 shows correspondences between STO1 and STO2 inputs and Monitor Output states. STO1 STO2 MONITOR OUT...
  • Page 29 5. In case of short circuit or failure of power device transistor, the motor could make an uncontrolled movement within a range up to 180 degrees in electrical angle (180 degrees in electrical angle=1/50 of a turn) and then remain a stable position. It is necessary to verify that this limited movement does not correspond to some risky conditions.
