- Page 1 Technical User Guide DOL 104 4-20 mA Humidity sensor dol-sensors a/s – Agro Food Park 15 – DK-8200 Aarhus N – T: +45 7217 5888 – F: +45 7217 5959 – www.dol-sensors.com...
- Page 2 Technical User Guide 1 Product description DOL 104 is a high-precision sensor for measuring relative humidity. It is intended for use in livestock houses but is also well suited for a number of industrial applications. The sensor features one analogue output with full protection against short-circuits and wiring failures.
- Page 3 0.16 mA / % RH Output signal 20 s at 0.5 m/s air speed Time constant V DC 11 – 30 Supply voltage Max. current See figure regarding load resistance and supply voltage Load Max. output current www.dol-sensors.com DOL 104 4-20 mA...
- Page 4 Measurement, shipment Shipment weight ex. connec- 5.1 Load resistance and supply voltage 5.2 Dimensions Dimensions in mm. 107.5 dol-sensors a/s – Agro Food Park 15 – DK-8200 Aarhus N – T: +45 7217 5888 – F: +45 7217 5959 – www.dol-sensors.com...
