Toshiba Satellite P105-S6022 Specifications

Satellite P105-S6022 / P105-S6062 Detailed Product Specification
Model Name Description
P105-S6022/ Genuine Windows® XP Professional, Intel® Core™ Duo Processor T2050, 1024MB
P105-S6062 DDR2 SDRAM, 100GB HDD (5400RPM), 17" WXGA+ TruBrite™, DVD SuperMulti
Double Layer, 802.11 a/b/g, Intel® Graphics Media Accelerator 950, Express Media
Player
2
Operating System
• Genuine Windows® XP Professional
• Windows Vista™ Capable
• TOSHIBA Express Media Player
o Quick access for CD and DVD watching
3
Processor and Chipset
Intel® Centrino® Mobile Technology featuring:
• Intel® Core™ Duo Processor T2050
o 1.60GHz, 2MB L2, 533MHz FSB
• Mobile Intel® 945GM Express Chipset
• Intel® PRO/Wireless 3945ABG (802.11a/b/g)
4
Memory
• Configured with 1024MB DDR2 SDRAM (both memory slots may
be occupied)
• 256MB(min)/4096MB (max), 2 memory slots using 256MB, 512MB,
1024MB or 2048MB PC4200 DDR2 533MHz, dual-channel
support requires two memory modules of same capacity and
clockspeed
5
Hard Disk Drive
• 100GB (5400 RPM) Serial-ATA (SATA) hard disk drive; 9.5mm
height
6
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x:read),
CD-R (24x:write), CD-RW (10x:write), DVD-ROM
(8x:read), DVD-R (Single Layer, 8x:write), DVD-R
(Double Layer, 2x: write), DVD-RW (4x:write), DVD+R
(Single Layer, 8x:write), DVD+R (Double Layer,
2.4x:write), DVD+RW (4x:write), DVD-RAM (5x:write)
7
Display
• 17.0" diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1440x900 native resolution (WXGA+)
8
Graphics
• Intel® Graphics Media Accelerator 950 with 32MB-128MB
dynamically allocated shared graphics memory
Sound
• Built-in harman/kardon® stereo speakers
• SRS Labs audio enhancements
o SRS TruSurround XT® virtual surround sound
o SRS WOW™ stereo enhancement
• 16-bit stereo software sound
o Intel® High Definition Audio
• Sound Volume Control Dial
Input Devices
• Keyboard
9
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite P105-S6022 /P105-S6062 Rev. 1.10 2006-07-20 DSM T20060118 CB1.60
1
Part Number
PSPA0U-02S01S
o 103 key US keyboard with 10-key
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• TouchPad™ pointing device
• Control Buttons:
o Internet button to launch default browser
o Express Media Player CD/DVD launch button
o CD/DVD control buttons (Skip to Previous/Next Track,
Play, Stop)
Communications
• Toshiba V.92 software modem
• Intel® PRO/100 VE Network Connection - 10/100 Base-TX Ethernet
• Integrated Intel® PRO/Wireless Network Connection 3945ABG
11
(802.11a/b/g)
Expandability
• 2 main memory slots. Both slots may be occupied.
• 1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
• ExpressCard™ slot supporting ExpressCard/34 and
ExpressCard/54
• 5-in-1 Bridge Media Adapter
o Secure Digital, Memory Stick™, Memory Stick PRO™,
Multi Media Card, xD Picture Card [shared slots]
Ports
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK(tm) IEEE-1394
o Universal Serial Bus (USB v2.0) – 4 ports
o RJ-45 LAN port
o RJ-11 modem port
Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 15.5" (394.0mm) x 10.8"
(275.0mm) x 1.41" (35.9mm)[F]/1.64" (41.9mm)[R] without feet
• Weight: Starting at 7.1 lbs (3.2 kg) depending upon configuration
• Indicators: Power, Primary HDD Access, ODD Access, Caps Lock,
Arrow Mode, Numeric Mode, Main battery charging status,
Sleep/Suspend Status, Wireless Communications
• Chassis Description
o Case material: Polycarbonate ABS
o LCD Cover Color: Mist Gray
• Physical Security
o Slot for cable lock
o Items protected by a screw: Memory, Main HDD
• Software Security
o Passwords: User power-on password, supervisor
password
o Hotkey locks: Screen Blank
UPC
032017623231
