EDGE TUB USER MANUAL
CONTROL PANEL
CHILLER
The main unit which chills/heats, circulates, and filters the water.
CHILLER DRAIN
The drain with cap at the middle bottom on the rear of the chiller. This is meant
to be opened to allow the machine to drain water out when the Chiller is being
moved or packaged.
PROTECTIVE CAPS
The protective caps that thread on the Chiller Inlet and Outlet ports.
CHILLER HOSES
The flexible hoses are used to flow water from the Edge Tub to the Chiller.
• Hose Connection Fittings
The fittings on the end of each hose. They connect the Chiller Hoses to the
Chiller Inlet/Outlet and Tub Valve Fittings.
• Hose O-Rings
The o-rings in the hose connections. These are vital for water-tight and air-
tight connections with the Chiller Hoses and Tub or Chiller.
CHILLER INLET (RED)
The connection on the chiller, which incoming water enters through. This is
marked with a red ring.

PARTS REFERENCES

CHILLER FRONT CHILLER BACK
CHILLER OUTLET (GREEN)
The connection on the chiller, which outgoing water leaves through. This is
marked with a green ring.
System
CONTROL PANEL Cool Heat
Defrost T1 43 F
On .
Mode 5
Default
40.0 F
Set
17.5
L
SW
The visual readout including Tub Temperature, Set Point, and the Control
Buttons (detailed in Control Panel section).
DOUBLE ACTION AIR PUMP
The air pump to inflate and deflate the Edge Tub.
EXTERNAL WATER STRAINER
The assembly of parts that is used to prevent any debris from entering the
Chiller. It connects to the Chiller Inlet (red) and is made up of the Water Strainer
Cover, Strainer O-Ring, and Inner Water Strainer.
• Inner Water Strainer
The cylindrical mesh element that attaches to the Chiller Inlet (red).
• Strainer O-Ring
The o-ring at the base of the External Water Strainer connection (red) on
the Chiller.
• Water Strainer Cover
The metal cover that will screw on the Chiller Inlet (red) over the Inner
Water Strainer.
PAGE - 03
UPPER WATER FILTER HOUSING
CHILLER OUTLET
LOWER WATER FILTER HOUSING
CHILLER INLET
CHILLER DRAIN
