Preface Manual Information Purpose This manual details the features, configuration details, and specifications for the SPT-LXYTOXY serial protocol translator. Audience This manual is written for technicians and operators responsible for installation, setup, maintenance, and/or operation of the product, and is useful to operations personnel for purposes of daily operation and reference. -
Page 9: Writing Conventions
Preface Writing Conventions To enhance your understanding, the authors of this manual have adhered to the following text conventions: Table P-2. Writing Conventions Term or Description Convention Bold Indicates dialog boxes, property sheets, fields, buttons, check boxes, list boxes, combo boxes, menus, submenus, windows, lists, and selection names Italics Indicates email addresses, the names of books or publications,... -
Page 10: Unpacking/Shipping Information
Preface Unpacking/Shipping Information Unpacking a Product This product was carefully inspected, tested, and calibrated before shipment to ensure years of stable and trouble-free service. 1. Check equipment for any visible damage that may have occurred during transit. 2. Confirm that you have received all items listed on the packing list. 3. -
Page 11: Compliance And Safety Standards
Preface Compliance and Safety Standards Appendix A: “Safety Precautions, Certifications, and Compliances” contains product compliance and safety standards. Restriction on Hazardous Substances (RoHS) Compliance Directive 2002/95/EC—commonly known as the European Union (EU) Restriction on Hazardous Substances (RoHS)—sets limits on the use of certain substances found in electrical and electronic equipment. -
Page 12: Safety
Preface In accordance with this EU Directive, companies selling electric or electronic devices in the EU will affix labels indicating that such products must be prop- erly recycled. (See our website for more information on dates and deadlines for compliance.) Contact your local sales representative for information on return- ing these products for recycling. - Page 13 Preface SPT-LXYTOXY Installation and Configuration Manual...
-
Page 14: Chapter 1: Introduction
Chapter 1 Introduction Overview The SPT serial protocol translator is a compact adapter that translates between Harris protocol and protocols used by other manufacturers or equipment. The SPT can be used to integrate otherwise incompatible devices in a system, and it may be used to expand a system beyond the normal limitations imposed by hardware or system design. -
Page 15: Applications Involving The Spt-Lxytoxy
Chapter 1: Introduction Applications Involving the SPT-LXYTOXY The SPT-LXYTOXY can be used to allow remote control of a Harris router using X-Y control panels. In this application, the SPT translates from X-Y protocol to the RS-232 required by the modem and then translates from RS-232 back to X-Y on the remote site. -
Page 16: Chapter 2: Installation
Chapter 2 Installation Installing the SPT-LXYTOXY The SPT-LXYTOXY is installed in the control line, as shown in Figure 2-1 Figure 2-2. • The maximum allowable distance for each segment of the X-Y coaxial cable run is 2,000 ft (609 m). •... - Page 17 Chapter 2: Installation Remote Router Control Router control panel(s) RCP-p series or equivalent Modem X-Y on 75 Ω coax S erial Pro tocol Translator RS-232 X-Y on 75 coax Ω Dedicated / leased line SPT-LXYTOXY provides conversion from X-Y bus to RS-232 S erial Pro tocol Translator TER M RS-232...
-
Page 18: Spt-Lxytoxy Cable Wiring Details
Chapter 2: Installation SPT-LXYTOXY Cable Wiring Details Figure 2-2 shows the connector pin assignments on both ends of the connection (the cable wiring description is shown between the connectors). Interconnect Cable Computer DB-25 DB-9 SPT-LXYTOXY DB-25 male female female DB-9 male * Transmit data (TXD) 2 2 Received data (RXD) Receive data (RXD) 3... -
Page 19: Power Requirements
Chapter 2: Installation Power Requirements Locations with 110-127 Volt Electrical Systems Locations with 110-127 volt electrical systems should use the PD9200PL6A Note adaptor. If you did not receive the correct adaptor for your electrical sys- tem, please contact your Cus- tomer Service representative. - Page 20 Chapter 2: Installation Locations with 220-240 Volt Electrical Systems Locations with 220-240 volt electrical systems should use the PD9300EPL6A adaptor. Figure 2-4. D9300EPL6A Adaptor • Input voltage: 230 VAC, 5 0Hz • Input current: 40 mA max • Output voltage: 9.0 VDC •...
- Page 21 Chapter 2: Installation SPT-LXYTOXY Installation and Configuration Manual...
-
Page 22: Chapter 3: Configuration And Assembly
Chapter 3 Configuration and Assembly Configuring the SPT-LXYTOXY The SPT-LXYTOXY is shipped from the factory preconfigured for use. In most Note cases, it will not be necessary to reconfigure the SPT. The parameters listed in Table 3-1, however, are user-configurable. In the unlikely event that you need to change settings, see Table 3-1. -
Page 23: Dip Switch And Jumper Locations
Chapter 3: Configuration and Assembly DIP Switch and Jumper Locations Configuration is accomplished via DIP switch and jumper settings, as shown in Figure 3-1 Figure 3-2. Figure 3-1. DIP Switch and Jumper Locations SPT-LXYTOXY Installation and Configuration Manual... - Page 24 Chapter 3: Configuration and Assembly Figure 3-2. DIP Switch Settings SPT-LXYTOXY Installation and Configuration Manual...
-
Page 25: Reassembling The Spt Unit
Chapter 3: Configuration and Assembly Reassembling the SPT Unit To avoid damage to the SPT circuitry, the unit must be reassembled as shown in Figure 3-3. Note that one of the four standoffs on the underside of the bottom cover has been removed. Orient the cover so that this area is positioned directly over U1. -
Page 26: Protocol Notes
Chapter 3: Configuration and Assembly Protocol Notes The SPT-LXYTOXY supports all functionality of pass-through protocol. Table 3-2 lists the features supported. Table 3-2. Pass-through Protocol Protocol Description Take Switches a Source to the Destination on the Level(s) requested Status Request Returns the status of a Destination on the Level(s) requested Protect / Unprotect... - Page 27 Chapter 3: Configuration and Assembly SPT-LXYTOXY Installation and Configuration Manual...
-
Page 28: Appendix A: Safety Precautions, Certifications, And Compliances
Appendix A Safety Precautions, Certifications, and Compliances Overview Carefully observe the safety alert symbols below for dangers, warnings, and cautions. They alert installers and operators of possible dangers or important information contained in this manual. Keep in mind, though, that warnings alone do not eliminate hazards, nor are they a substitute for safe operating techniques and proper accident prevention measures. -
Page 29: Safety Terms And Symbols In This Manual
Appendix A: Safety Precautions, Certifications, and Compliances Safety Terms and Symbols in this Manual WARNING Statements identifying conditions or practices that may result in personal injury or loss of life. High voltage is present. CAUTION Statements identifying conditions or practices that can result in damage to the equipment or other property. -
Page 30: Preventing Electrostatic Discharge
Appendix A: Safety Precautions, Certifications, and Compliances Preventing Electrostatic Discharge Observe precautions for handling electrostatic sensitive devices. CAUTION: Electrostatic discharge (ESD) can damage components in the product. To prevent ESD, observe these precautions when directed to do so: 1. Use a Ground Strap. Wear a grounded antistatic wrist strap to discharge the static voltage from your body while installing or removing sensitive components. -
Page 31: Product Damage Precautions
Appendix A: Safety Precautions, Certifications, and Compliances Ground the product This is a Safety Class 1 product and is grounded through the grounding conductor of the power cord. To avoid electrical shock, the grounding conductor must be connected to earth ground. Before making connections to the product’s input or output terminals, ensure the product is properly grounded. - Page 32 Appendix A: Safety Precautions, Certifications, and Compliances Provide Proper Ventilation To prevent product overheating, provide proper ventilation. Do Not Operate With Suspected Failures If you suspect there is damage to this product, have it inspected by qualified service personnel. CAUTION: This unit can have more than one power supply cord. To de-energize the internal circuitry, you have to disconnect all power cords.
-
Page 33: Emc And Safety Standards
Appendix A: Safety Precautions, Certifications, and Compliances EMC and Safety Standards This product has been tested and found to comply with the following IEC, FCC, UL, ICES, and CSA standards, per the provision of the Electromagnetic Compatibility Directive 89/336/EEC of 3 May 1989 as amended by 92/31EEC of 28 April 1992 and 93/68/EEC, Article 5 of 22 July 1993, and the Low Voltage Directive 73/23/EEC of 19 February 1973. -
Page 34: Additional Emc Information
Appendix A: Safety Precautions, Certifications, and Compliances These devices are for professional use only and comply with Part 15 of FCC rules. Operation is subject to the following two conditions: 1. These devices may cause interference to radio and TV receivers in residential areas. -
Page 35: Safety Standards
Appendix A: Safety Precautions, Certifications, and Compliances Safety Standards Table A-2. Harmonized and Reference IEC Safety Standards Harmonized Standard Reference IEC Standard Description EN 60950:1992 with IEC 60950:1991 (Modified) Safety of Information Technology Equipment Am1, Am 2, Am 3, Am4, A11 amendments EN 60950 IEC 60950:1999 (Modified) -
Page 36: Index
Index Keywords Adaptor replacement information 6–7 Reassembly Applications References Cable wiring details Restriction on Hazardous Substances Compliance viii Configuration 9–11 Returning a product DIP switches RoHS. See Restriction on Hazardous Substances locations Compliance settings Safety EMC standards 20–21 injury precautions preventing electrostatic discharge product damage precautions safety precautions... - Page 37 Index SPT-LXYTOXY Installation and Configuration Manual...
