Toshiba Satellite M55-S1352 Specifications

TOSHIBA
1
Satellite
Model Name Description
M55-S1352 Microsoft® Windows® XP Home, Intel® Celeron® M Processor 370, 512MB, 60GB, DVD-
ROM/CD-RW drive, 14.0" WXGA Trubrite™ TFT, Intel GMA900, 802.11b/g, 1-year limited
warranty
System Characteristics
3
Operating System
•
Microsoft® Windows® XP Home
4
Processor and Chipset :
•
Intel Celeron® M Processor 370 [1.50GHz, 1MB L2, 400MHz
FSB]
•
Mobile Intel 915GML Express Chipset
5
Memory
•
Configured with 512MB DDR SDRAM (both memory slots may
be occupied)
•
512MB (Min)/1536MB (Max), 512MB on-board memory (under
keyboard, service removable) with 1 available memory slot for
256MB, 512MB, or 1024MB PC2700 DDR 333MHz SDRAM
2.5V SODIMM memory modules
Mass Storage
6
Hard Drive
•
60GB (5400RPM); Enhanced IDE (ATA-6) hard disk drive;
9.5mm height; user removable
Optical Disk Drive
•
Fixed Bay DVD-ROM/CD-RW drive:
Maximum Speed:
CD-ROM(24x:read), CD-R(24x:write), CD-RW(24x:write),
DVD-ROM(8x:read), DVD-R(read only), DVD-RW(read
only), DVD-RAM(read only)
7
Display
•
14.0" diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1280x768 native resolution (WXGA)
•
Maximum Brightness 205 cd/m
•
Viewing Angle
Horizontal – (90 degrees)
o
Vertical – (50 degrees)
o
•
Brightness Control – FN + F6/F7
8
Graphics
•
Intel Graphics Media Accelerator 900; up to 128MB of graphics
memory is taken from the main memory via UMA (Unified
Memory Architecture)
Sound
•
Realtek ALC250 Software Sound
•
16-bit stereo
•
Built-in stereo speakers
•
3D Sound Support, Direct 3D Sound; DirectSound, Direct Music,
MIDI (playback) Support
•
Sound Volume Control Dial
•
Toshiba Audio Enhancements supporting SRS TruSurround XT,
9
SRS WOW
Input Devices
•
Keyboard
85 key US keyboard, 2.7mm key stroke, 6mm keyboard
o
height, 19.05mm key pitch
Hot Key Functions (FN); please see electronic User's Guide
o
for more information
Windows Key Function
o
Application Key Function
o
•
Pointing Device:
TouchPad™ pointing device
o
TouchPad™ Enable/Disable (FN+F9 or by help of software)
o
Expandability
•
2 main memory slots (Both Slots may be occupied.)
One slot under keyboard, service removable
o
One slot available, end user accessible
o
•
1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
2
2
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
Satellite M55-S1352 Rev. 1.00 6/6/2005 9:55 AM DMD T20050418CB1.00
Communications
•
Integrated V.92 modem
•
Marvell® 10/100 Base-TX Ethernet
•
Atheros® 802.11b/g wireless-LAN supporting Atheros SuperG™
11
technology
Ports
•
RGB (monitor) port
•
TV-out (S-Video)
•
4 Universal Serial Bus (USB) ports (v2.0)
•
External Microphone jack
•
Headphone jack
•
RJ-45 LAN port
•
RJ-11 modem port
Physical Description
•
Dimensions (WxDxH Front/H Rear): 13.50'' (343mm) x 9.53''
(242mm) x 1.17'' (29.8mm)[F]/1.50'' (38.0mm)[R] without feet
•
12
Weight : Starting 2.26kg (4.98 lbs) to 2.47kg (5.30 lbs)
depending upon configuration
•
Indicators: Power, DC-IN, Primary HDD access, CD/DVD-ROM
Access, Arrow Mode, Numeric Mode, Scroll Lock, Main Battery
Charging Status, System Sleep/Suspend Status, Wireless
Communication
•
Case material: Polycarbonate ABS
Power Supply
•
75W (15V x 5A) Auto sensing external AC Adapter, 100-240V /
50-60Hz frequency (Universal) input.
•
Weight: starting at 0.88 lbs (400g)
•
Dimensions (WxDxH): 5.35'' (136mm) x 2.09'' (53mm) x 1.18''
(30mm)
13
Battery
•
6-cell (4300 mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
•
Weight: starting at 0.75 lbs (340g)
•
Dimensions (WxDxH): 8.15" (207mm) x 0.91" (23mm) x 2.13"
(54mm)
•
Recharge Time
Main Battery Off/On – approximately 3.0 hrs/approximately
o
4.0 to 12.0 hrs
Security
•
Physical Security
Slot for cable lock;
o
Items protected by a screw: Memory, Hard Disk Drive
o
Items protected by a latch: Main Battery Pack
o
•
Software Security
Passwords: User Power-on password, Supervisor Password,
o
Setup Security, HDD Security
Software: Screen Blank (by Hotkey), Screen Saver (by
o
software).
BIOS
•
ACPI (V1.0b), PNP (V1.0a), VESA (V3.0), DPMS (V2.0), DDC
(V2.0), SM BIOS (V2.34), PCI BIOS (V2.2) support
14
Software
Toshiba Software and Utilities
•
Toshiba ConfigFree™
•
Toshiba Custom Utilities
•
Electronic User's Guide
Third-party Software
•
Microsoft® Works
•
Microsoft® Office OneNote™
•
Software Decoder: Intervideo® (WinDVD™ 5)
Part Number UPC Code
PSM50U-02R011 032017367616
10
Page 1 of 4
