Page 1 User Manual...
Page 2 This manual is designed for LIL RIPPA bike models only. Please read and understand all parts of this entire manual before operating the e-bike for the first time.
Page 3: Table Of Contents
Table Of the Contents Safe Operating Tips Accessories Diagram Technical Specification Assembly LCD Display 9-11 Battery Tips 12-13 Regular Inspection Troubleshooting 15-16 Warranty 17-18 Warning...
Page 4: Safe Operating Tips
Safe Operating Tips Always wear an approved helmet while riding your e-bike and • follow the helmet instructions for fit, use and care of your helmet • Please make sure you know all local traffic laws. It’s the rider’s responsibility to strictly obey them Check your e-bike for proper fit and installation, normal operation, •...
Page 5 Safe Operating Tips Never carry anything which obstructs your view or could affect • control of the bike • Never drive the e-bike with one hand or ride aggressively as it can cause or lead to dangerous riding situation • The charger should only be cleaned with a dry cloth.
Page 6: Accessories Diagram
Accessories Diagram...
Page 7: Technical Specification
Technical Specification Items Details Items Details LIL RIPPA Bike Model Motor High Torque Brushless Hub Voltage Power 500W Battery Frame High Carbon Steel 13Ah Capacity Material Net Weight Battery Type 28KG Lithium Battery Max load Charging time 150KG 5-6 hours...
Page 8: Assembly
Assembly List of loose parts & contents Contained in the bike box • Semi - Assembled Bike Front Tyre • • Handlebar • Fender (Front & Rear) Parts Box including: • Battery Charger Battery Keys(2) Front Wheel Quick Release Basic Tools Step 1 Bike Standing Display status diagram •...
Page 9 Assembly Step 3 Install Front Wheel on Fork Mount the wheel to the fork, • carefully guiding the brake pads onto the rotor. The axle should fit into the fork snugly • Insert the quick release lever to the hub, please notice the direction of the spring •...
Page 10: Lcd Display
Display Rotate the throttle to move the bike at the desired speed. It has five different gears. Pushing the +/- buttons the gears change from 1-2-3-4-5. To slow down, push the brake lever and turn the throttle handle anticlockwise. Turn the key to turn off . 1.power-on and power-off Long press the key to turn on,long press the key...
Page 11 Display 2.Key Operation After power on, short press the key to increase the gear Short press the key to decrease the gear. Fault code E-001 motor failure E-002 Throttle failure E-003 Controller failure E-004 Brake failure E-005 Controller undervoltage The display does not receive the controller E-006 signal E-007...
Page 12 Display Ø Setting Light 1-3(brightest) Mileage unit 0 for km; 1 for mile Voltage 24V, 36V, 48V 1-60 minutes, Dormancy 0 for no sleep UP：3.5.9 gears Gears Down：with/without 0 gear Wheel Size Min：0.1 inch 1-99 Magnets setting 0-50(unlimited)Km/h based Speed Limit on km mode 0 for Pedat start disabled Pedal start engaged/...
Page 13: Battery Tips
Battery Tips Lock / Unlock the battery Turn the key counterclockwise to unlock the battery. Clockwise to lock the battery. Remove the battery After unlocking the battery, tilt it to the left and push forward to remove the battery. To return the battery, insert back into the frame housing until it clicks into place.
Page 14 Battery Tips Charging safety (Continued) • Do not immerse the battery in water • Please charge in a safe environment • Charge the battery at an ambient temperature of 0-35°C • Do not charge more than 12 hours to avoid affecting battery life •...
Page 15: Regular Inspection
Regular Inspection Routine safety inspection Tyre: pressure value, tyre wear level (do not inflate past max psi) • • Brake system: brake free stroke, brake fluid leaks, brake pads and brake disc wear, brake power-off switch Horn: circuit solder joints and insulation •...
Page 16: Troubleshooting
Troubleshooting Symptoms Potential causes Common method • Check whether the • Short circuit of fuse fuse needs to be No power indication replaced • Poor contact between the when power on power plug and the battery • Check if the connector is loose •...
Page 17 Troubleshooting Symptoms Potential causes Common method Poor contact between • • Check if the plug is charger plug and lithium Lithium battery loose battery socket does not charge • Replace the charger The charger is damaged • • Tighten the screws of Loose screws in various parts •...
Page 18: Warranty
Warranty Parts Time Warranty Hall original burnt out, quality Motor 1 year dysfunction Unable to charge and Battery 1 year discharge, the detection capacity is less than 60% Controller 1 year Disfunction Dysfunction, unable to open, or Display 1 year garbled characters Speed sensor 1 year...
Page 19 11.Failure of components/parts/accessories due to the used of foreign products that are not Ampd Brothers approved items. 12.Persons who are not the Original Purchaser as listed on the Receipt 13.Claims outside the Valid Warranty Date from the Date of Receipt 14.Any Packaging required to pack items Securely for Return Repairs...
Page 20: Warning
Warning No riding your bike while charging! • No touching any substance that leaks from the battery ! • • No children and animals are allowed to touch the battery! Battery contains dangerous substances inside strictly forbidden to • open! Use only the charger provided.
Page 21 ampdbros.com...
