Compatible with the following

Intellidash models:

caranddriverdashcams.com support@caranddrivertech.com

CAD-BUC100

DU2000S, DU1000, DU950S, and DU900 models

without DJL and JJK (Date Codes labeled on the

back of the device)

Hardwire Backup Camera Kit

Installation Guide Guía de instalación

Need help?

Do you have a question about the CAD-BUC100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Car and Driver CAD-BUC100

Page 1 CAD-BUC100 Compatible with the following DU2000S, DU1000, DU950S, and DU900 models Intellidash models: without DJL and JJK (Date Codes labeled on the back of the device) Hardwire Backup Camera Kit Installation Guide Guía de instalación caranddriverdashcams.com support@caranddrivertech.com...
Page 2 ENGLISH Overview Connect to AV IN jack Rear camera power cable Reverse light display-switching wire (Connect to the positive of the reverse light) Adhesive tape Screws Mounting plate HD Rear camera In order to avoid damage to the rear camera, please do not install it by yourself. See a mechanic or other professional for installation.
Page 3 Mounting and routing 1. Connect the L-shaped end of rear camera power cable to the AV IN jack of your INTELLIDASH+/Pro. 2. Route the rear camera’s power cable around the ceiling of your car, or in a gap between the windshield and the interior, etc. Make sure it is placed in a way that does not interfere with driving (See the Fig below).
Page 4 4. Connect the reversing light signal wire to the positive charge of the reverse light. Note: For a negative trigger system, a relay (below) should be added between the signal wire and the positive wire of reversing light to avoid damage to the rear camera.
Page 5 Please follow the figure below to install a relay for the negative trigger system. 5P relay wiring diagram Positive output COM contact (Forced switching line <positive>) The positive of reverse light reverse light Connect Normally Closed Normally Opened 5. Plug the power cable into your car’s DC 12V power outlet. Your INTELLIDASH+/ Pro will automatically power on when your car is powered on.
Page 6: Visión General
ESPAÑOL Visión general Conectar a la toma AV IN Cable de alimentación de la cámara trasera Cable de cambio de pantalla de luz de marcha atrás (Conéctese al positivo de la luz de marcha atrás) Cinta adhesiva Empulgueras Placa de montaje Cámara trasera HD Para evitar daños en la cámara trasera, no la instale usted mismo.
Page 7 Montaje y enrutamiento 1. Conecte el extremo en forma de L del cable de alimentación de la cámara trasera al conector AV IN de su INTELLIDASH+/Pro. 2. Pase el cable de alimentación de la cámara trasera alrededor del techo de su automóvil, o en un espacio entre el parabrisas y el interior, etc.
Page 8 4. Conecte el cable de señal de la luz de marcha atrás a la carga positiva de la luz de marcha atrás. Nota: Para un sistema de disparo negativo, se debe agregar un relé (abajo) entre el cable de señal y el cable positivo de la luz de marcha atrás para evitar daños a la cámara trasera.
Page 9 Siga la figura de la derecha para instalar un relé para el sistema de disparo negativo. Diagrama de cableado del relé 5P Contacto COM de salida positiva (línea de conmutación forzada <positivo>) El negativo de El negativo de El positivo de la luz inversa la luz inversa Conectar...
