- Page 1 RC031 4K Educational Auto Tracking Box Camera User Manual English (V2.0)
- Page 2 Copyright All contents of this manual, whose copyright belongs to our corporation, cannot be cloned, copied or translated without the permission of our corporation. Notice Product specifications and information which were referred to in this document are for reference only. We may change, delete, or update any content at any time and without prior notice.
-
Page 3: Table Of Contents
RC031 4K Educational Auto Tracking Box Camera User Manual Catalogue 1 Safety Precautions ....................1 Packing List ......................1 About Product ..................... 1 3.1 Features ........................1 3.2 Specifications ......................2 3.3 Interface and Indicator .................... 3 3.4 Dimension ......................... 4 Installation ...................... - Page 4 RC031 4K Educational Auto Tracking Box Camera User Manual 6.9 USB Mode Settings ....................13 6.10 Record Settings ....................13 6.11 Device Information ....................13 Installation Guide....................13 Image Tracking Configuration ................. 16 8.1 Network Function ....................16 8.1.1 Access Web Interface ..................16 8.2 Configuration Process ....................
-
Page 5: Safety Precautions
RC031 4K Educational Auto Tracking Box Camera User Manual Safety Precautions Packing List During the installation and use of the Name Quantity equipment, all electrical safety regulations Camera of the country and region of use must be Power Adapter strictly observed. -
Page 6: Specifications
RC031 4K Educational Auto Tracking Box Camera User Manual Low Light Backlight Support The application of 2D and 3D noise Compensation reduction algorithm greatly reduces the EPTZ Support image noise. Even under the condition of Digital Zoom ultra-low illumination, it still keeps the... -
Page 7: Interface And Indicator
RC031 4K Educational Auto Tracking Box Camera User Manual 1920x1080, 1280x720, General Specifications 1024x576, 960x540, Input Voltage DC 12V/PoE (802.3af) Third Stream 720x576, 720x408, Input Current 0.5A (Max.) Resolution 640x480, 640x360, Operating 0°C~40°C 480x272, 320x240, Temperature 320x180 Storage -40°C~60°C 1920x1080, 1280x720,... -
Page 8: Dimension
RC031 4K Educational Auto Tracking Box Camera User Manual 3.4 Dimension Installation self-tapping pastern stuff screw Mounting Bracket 1/4"-20UNC 1/4''-20UNC Fixed Camera Note The installation diagram is for reference only. The brackets and screws are not standard. For installation accessories, please refer to the... -
Page 9: Gui Settings
RC031 4K Educational Auto Tracking Box Camera User Manual ExpCompMode: On, Off (Effective only in Full GUI Settings Auto, Smart mode). ExpComp: -7 ~ 7 (Effective only in 5.1 MENU ExpCompMode to On). MENU Gain Limit: 0 ~ 15 (Effective only in Full Auto, Exposure Bright mode). -
Page 10: Image
RC031 4K Educational Auto Tracking Box Camera User Manual Color Temp: 2500K ~ 8000K (Effective only in 5.5 FOCUS VAR mode). Move the main menu cursor to [FOCUS], and RG Tuning: -10 ~ 10 (Effective only in Auto, click [ ] key enter the noise reduction page, One Push, VAR mode). -
Page 11: Information
RC031 4K Educational Auto Tracking Box Camera User Manual 5.9 RESTORE DEFAULT SETTING Language English Move the main menu cursor to [RESTORE Protocol VISCA DEFAULT], and click [ ] key enter the Visca Addr restore default page, as shown in the EPTZ following figure. -
Page 12: Control Camera
RC031 4K Educational Auto Tracking Box Camera User Manual 6.2 Control Camera 2) Focus Focus In and Focus Out buttons allow for fine All pages include two menu bars: manual focus adjustment if camera has any Real time monitoring: displaying video image problems auto focusing on the difficult object. -
Page 13: Video Settings
RC031 4K Educational Auto Tracking Box Camera User Manual 6.3 Video Settings 4) Resolution First stream support 1920x1080, 1280x720, Video Settings 1024x576, 960x540, 640x480, 640x360; Video Format 50Hz Second stream support 3840x2160, 1920x1080, Encode Level mainprofile 1280x720, 1024x576, 720x576 (50Hz), 720x480... -
Page 14: Image Settings
RC031 4K Educational Auto Tracking Box Camera User Manual 8) Bit Rate Control 7) Mirror Code stream control way: Turn On/Off the Mirror function. CBR (Constant Bit Rate): Video coder will be 8) Enable Subtitle coding according to preset speed. -
Page 15: System Settings
RC031 4K Educational Auto Tracking Box Camera User Manual 6.6 System Settings Port Port HTTP Port HTTP Port Initialize RTMP(S) RTMP(S) RTSP Port RTSP Port RTSP RTSP TCP Port TCP Port 5678 5678 Reboot Reboot ONVIF ONVIF UDP Port UDP Port... - Page 16 RC031 4K Educational Auto Tracking Box Camera User Manual C. TCP Port Active Connection Port Port Set the TCP Port of the camera, Address 192.168.100.138 RTMP(S) default port: 5678. Port 1234 RTSP RTSP ONVIF ONVIF D. UDP Port Submit Cancel...
-
Page 17: Ai Settings
RC031 4K Educational Auto Tracking Box Camera User Manual 6.8 AI Settings 4) record time enable Turn On/Off record time. AI Settings 5) record time start Resolution enhancement(*) Off * Set the start and end time of recording. Is an experience feature... - Page 18 RC031 4K Educational Auto Tracking Box Camera User Manual from the blackboard wall is calculated with Installation method: It is best to install with a the following formula: boom to ensure the distance between the The distance between the teacher machine teacher's computer and the blackboard.
- Page 19 RC031 4K Educational Auto Tracking Box Camera User Manual Student UHD Color Box Camera Where W is the width of the wall where the (Focus: f=2.8mm, FOV: 95°) blackboard is located or the width of the first Installation height: 2.2M~2.4M row of students' shots.
-
Page 20: Image Tracking Configuration
RC031 4K Educational Auto Tracking Box Camera User Manual Image Tracking Configuration 8.1 Network Function This description mainly introduces the close-up camera network, and the panoramic camera network description does not introduce it. 8.1.1 Access Web Interface View Camera IP... -
Page 21: Teacher Configuration
RC031 4K Educational Auto Tracking Box Camera User Manual The setting process of teacher/student 8.3.2 Set Preset Position camera is as follows: Set panoramic position, set podium position, available [ⓦ] [ⓨ] [ⓥ] [ⓧ] [Zoom in] [Zoom out] to adjust the position of the close-up lens;... -
Page 22: Set Shielding/Tracking Area
RC031 4K Educational Auto Tracking Box Camera User Manual of the tracking area should be reserved under 8.3.3 Set Shielding/Tracking Area the shielding area, and shielding areas cannot Tracking Area Setting be set on the left and right borders of the... -
Page 23: Advanced Parameter Configuration
RC031 4K Educational Auto Tracking Box Camera User Manual Tilt offset: Optional range: -200~+200 working modes; check "┋" to take effect. (steps), 0.069°/step; negative numbers are calibrated down, positive numbers are calibrated up, default: 0. Target Action Target Lost Action: Set [Feature Camera]... -
Page 24: Start Track
RC031 4K Educational Auto Tracking Box Camera User Manual 8.3.6 Start Track After completing the parameter configuration, click [Apply] to ensure that the configuration parameters take effect, and then click [Start Track] to enter the automatic tracking mode. Param Backup... -
Page 25: Set Shielding Area
RC031 4K Educational Auto Tracking Box Camera User Manual calibrated down, positive numbers are 8.4.3 Set Shielding Area calibrated up, default: 0. Shielding area setting: check [Show], check Input height and length: the installation the "┋" to set the number of the shielding... - Page 26 RC031 4K Educational Auto Tracking Box Camera User Manual response time: The shortest time to respond Face Detection: After turning on [Face to the tracking after the student is detected to Detection], the camera will use face detection stand up, the default value: 1.0s.
-
Page 27: Start Track
RC031 4K Educational Auto Tracking Box Camera User Manual Export: When you stop tracking, click [Export] and student camera, blackboard machine and to back up the tracking parameters, click the director host. [Open], and you can see the file path. -
Page 28: Director Strategy
RC031 4K Educational Auto Tracking Box Camera User Manual when there is an action on the blackboard, the 8.5.3 Director Strategy switching code of the blackboard is sent, and Director Strategy: External Director and when there is no action on the blackboard, it Interior Director. -
Page 29: Faq
RC031 4K Educational Auto Tracking Box Camera User Manual 3: There is some problems with the serial 8.6 FAQ port connected between the pano camera and Q: After setting the parameters, click "Apply", feature camera, so please return to the factory and the application failed for repair. - Page 30 RC031 4K Educational Auto Tracking Box Camera User Manual Do not operating in unstable lighting Unable to access camera through Browser conditions, otherwise image will be 1) Using PC to access the network to test flickering. whether the network access can work ...
- Page 31 ROCWARE CORPORATION Address: 3F, No.2, Honghui Industrial Park, Xin'an Street, Bao'an District, Shenzhen, China. Website: www.rocware.com...
