Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright
2022 by Harbor Freight Tools
©
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
. All rights reserved.
®
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
23a
59467
Advertisement
Table of Contents
Summary of Contents for Maddox E1A1
- Page 1 Owner’s Manual & Safety Instructions Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference.
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION 1. Study, understand, and follow all instructions 25. Observe work area conditions. Keep before operating the device. work area clean and well lit. 2. Do not exceed rated capacity. 26. Use the right tool for the job. Do not attempt to force a small tool or attachment to do the 3. -
Page 3: Specifications
Specifications Maximum Opening 8″ Maximum Spring Wire Diameter 3/4" Minimum Spring Wire Diameter 7/16" Maximum Spring Coil Diameter 8-1/4" Minimum Spring Coil Diameter 3-3/4" Lead Screw Torque 30 ft-lb maximum Compressor Type MacPherson Struts Only Load Capacity 2000 lb Setup - Before Use Components Threaded Tube (7) - Page 4 Operating Instructions If removing MacPherson struts from vehicle before use, put the struts in a MacPherson strut vise prior to using the Strut Spring Compressor. If not removing MacPherson struts from vehicle, vehicle must be securely supported prior to using the Strut Spring Compressor. Only use hand tools with the Strut Spring Compressor.
-
Page 5: Maintenance
Maintenance Read the ENTIRE IMPORTANT SAFETY 2. An annual Strut Spring Compressor INFORMATION section at the beginning inspection is recommended. Only qualified of this document including all text service technicians should inspect this under subheadings therein before tool. If the tool is used extensively, more set up or use of this product. -
Page 6: Please Read The Following Carefully
PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS DOCUMENT AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. -
Page 7: Parts List And Diagram
Parts List and Diagram Part Description Part Description Pillar (Left) Tube (Top) Pillar (Right) Spring Bolt Safety Pin Washer Ring Spring Hex Bolt Half Tube Hex Screw Tube w/ Bolt Threads Pin for Tube Tube w/o Bolt Threads Item 59467 For technical questions, please call 1-888-866-5797. -
Page 8: Limited 90-Day Warranty
Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
