Summary of Contents for Light O Rama SASQUATCH MEGATREE
- Page 1 Assembly instructions...
- Page 2 Sasquatch MegaTree Assembly Instructions Tools Need 3/4” 17mm 1/2” 3/1 6 " Allen key 7/16” U.S. Patent Pending...
- Page 3 Sasquatch Base Assembly Sasquatch Modular Pole x 4 2’ 2’ 5’ 6” 3/4” Insert each pole into the base with the holes facing to the side 1/2-13 x 1 1/4 1 1/4” 4 threaded holes in base.
- Page 4 Sasquatch Modular Main Pole Assembly Modular Pole Sasquatch Modular Inner Coupler x 3 Pole x 4 6 threaded 5/16”-18 holes Tapered holes on both sides x 12 5/16”-18 X 3/4” 3/16” Allen key Safety stop bolt 1/2” Bolt with washer x 3 5/16”-18 X 1”...
- Page 5 Sasquatch Toppers 32 Hole Sasquatch Topper 4 small holes allow for guy wire Center sleeve slides anchoring. (optional) on 2”x2” square pole.
- Page 6 Sasquatch Topper Assembly Threaded holes x 7 4” Center Winch eyelet x 1 3/16" Allen key M10 bolt Star topper mount x 1 5/16”-18 bolt M10 nut x 1 17mm 5/16”-18 nut x 1 Carabiners x 32 / x 48 / x 64 1/2”...
- Page 7 Rotate up when assembled Feed winch line through rectangular hole in the topper. Slide Pulley cap over top of pole and feed winch line over the top.
- Page 8 Attach the winch clip to the winch eyelet on the topper. *Shown without star topper or carabiners to simplify illustration. 3/4” 1 1/4” 1/2-13 x 1 1/4 1 1/4” Once tilted up, attach the last leg.
- Page 9 Sasquatch Hoop Assembly 8’ 3/16" Allen key 6pcs 2 bolts per piece 5/16”-18 x 3/4 x 12 bolts 2 threaded 5/16”-18 holes 2 threaded 5/16”-18 holes Square Tube Option Round Tube Option...
- Page 10 Hoop Mounting Option A Stand Alone Base Hoop Mount Set Sku: SMTSAM Disconnect 1 hoop seam to allow the hoop to wrap around the center pole and place on top of the base feet. On each of the four base feet, attach a base hoop mount. Attach the hoop to the base hoop mount.
