Bedienungsanleitung
General information
Offgridtec GmbH
Im Gewerbepark 11
84307 Eggenfelden
WEEE-Reg.-Nr. DE37551136
Contact information
Tel: +49(0)8721 91994-00
Email: info@offgridtec.com
Web: www.offgridtec.com
CEO: Christian & Martin Krannich
Account Sparkasse Rottal-Inn
Account: 10188985
BLZ: 74351430
IBAN: DE69743514300010188985
BIC: BYLADEM1EGF (Eggenfelden)
Seat and district court
HRB: 9179 Registergericht Landshut
Tax number: 141/134/30045
Ust-IdNr: DE287111500
Place of jurisdiction: Mühldorf am Inn

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LifePO4 Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for Offgridtec LifePO4 Pro

  • Page 1 Bedienungsanleitung General information Contact information Account Sparkasse Rottal-Inn Seat and district court Offgridtec GmbH Tel: +49(0)8721 91994-00 Account: 10188985 HRB: 9179 Registergericht Landshut Im Gewerbepark 11 Email: info@offgridtec.com BLZ: 74351430 Tax number: 141/134/30045 84307 Eggenfelden Web: www.offgridtec.com IBAN: DE69743514300010188985 Ust-IdNr: DE287111500 WEEE-Reg.-Nr.
  • Page 2: Table Of Contents

    Inhaltsverzeichnis 1. SICHERHEITSRICHTLINIEN UND SICHERHEITSMAßNAHMEN 2. PRODUKTBESCHREIBUNG 3. BATTERIE SPEZIFIKATION 4. FUNKTION DES BMS (BATTERIE-MANAGEMENT-SYSTEM): NBETRIEBNAHME AGERUNG ARALLEL EIHENSCHALTUNG ICHTIGE INWEISE 5. TROUBLESHOOTING 6. ANHANG BMS - B – 12V ATTERY ANAGEMENT YSTEM BMS - B – 24V ATTERY...
  • Page 3: Sicherheitsrichtlinien Und Sicherheitsmaßnahmen

    Offgridtec LifePO4 Pro 12,8V und 25,6V 1. Sicherheitsrichtlinien und Sicherheitsmaßnahmen 1.1. Allgemeine Regeln: Bitte beachten Sie diese Anweisungen und bewahren Sie sie zum späteren Nachschlagen in  Nähe der Lithium-Ionen-Batterie auf. Arbeiten an der LiFePo4-Batterie sollten nur durch einen Fachmann durchgeführt werden.
  • Page 4: Produktbeschreibung

    2. Produktbeschreibung Längere Zykluslebensdauer: Bietet eine bis zu 20-mal längere Zyklenlebensdauer und eine  fünfmal längere Lebensdauer als Blei-Säure-Batterien, was dazu beiträgt, die Austauschkosten zu minimieren und die Gesamtkosten für den Eigentümer zu senken. Geringeres Gewicht: Etwa 40 % des Gewichts einer vergleichbaren Bleisäurebatterie. Ein ...
  • Page 5: Batterie Spezifikation

    Offgridtec LifePO4 Pro 12,8V und 25,6V 3. Batterie Spezifikation Model 12V 100A 12V 200Ah 24V 100Ah Artikelnummer 2-01-017315 2-01-017320 2-01-017365 Nennspannung 12,8V 25,6V Kapazität 100Ah 200Ah 100Ah Energiemenge 1280Wh 2560Wh Ladespannung 14.4V (14.6Vmax.) 28.8V (29.2V Max.) Entladeschlussspannung 10.8V Empfohlener Ladestrom Max.
  • Page 6: Funktion Des Bms (Batterie-Management-System)

    4. Funktion des BMS (Batterie-Management-System): Schutz der Zellen vor einer Unterspannung  Schutz der Zellen vor einer Überspannung  Schutz der Zellen vor einer Überlast  Kurzschlussschutz  Schutz der Zellen vor zu tiefen oder zu hohen Temperaturen ...
  • Page 7 Offgridtec LifePO4 Pro 12,8V und 25,6V Tipps zum Aufladen Über die Ladespannung Basierend auf den Eigenschaften von Lithium-Eisen-Phosphat (LiFeP04) -Akkus, wird die Spannung während des Ladevorgangs höher angezeigt. Die Akkuspannung pendelt sich ca. 15min nach dem Ladevorgang auf die tatsächliche Spannung ein.
  • Page 8: Lagerung

    State of Charge (SOC) Da es feine Unterschiede zwischen den Spannungen der einzelnen Batterien gibt, dienen die folgenden Parameter nur als Anhaltspunkte. 15 Minuten nach dem Trennen vom Ladegerät und der Belastung muss die Spannung im Ruhezustand (bei Nullstrom) geprüft werden.
  • Page 9: Parallel- Und Reihenschaltung

    Offgridtec LifePO4 Pro 12,8V und 25,6V Parallel- und Reihenschaltung Anschluss-Tipps Prüfen Sie die Batterien wie unten beschrieben, bevor Sie sie in Reihe oder parallelschalten: Schließen Sie NUR Batterien mit derselben Kapazität (Ah) an. Schließen Sie NUR Batterien der gleichen Marke an.
  • Page 10 Reihenschaltung von LiFePO4 Akkus Entladeschluss- Anzahl Akkus Systemspannung Ladeschlussspannung 12v / 24v Spannung 2 Stk / 1Stk 28.8V 21.6V 4 Stk / 2Stk 57.6V 43.2V Eine Reihenschaltung ist aufgrund der fehlenden Ausgleichsleitungen nicht zu empfehlen und wodurch es zu einer unsynchronen Ent-/Ladung kommen kann. Wenn Sie es dennoch vorhaben, müssen die Spannungen manuell überprüft werden.
  • Page 11: Wichtige Hinweise

    Offgridtec LifePO4 Pro 12,8V und 25,6V Aktivieren der Batterie nach dem Abschalten Wenn das BMS die Batterie zum Schutz abgeschaltet hat, müssen Sie die Last der Batterie abschalten und die Batterie für 30 Minuten nicht laden oder entladen. Dann erholt sich der Akku automatisch auf die normale Spannung und kann nach vollständiger Aufladung verwendet werden.
  • Page 12: Troubleshooting

    5. Troubleshooting Akku kann nicht entladen werden Prüfen Sie, ob die Batterie fest angeschlossen ist. Prüfen Sie, ob die Plus- und Minuspole der Batterie richtig angeschlossen sind. Prüfen Sie, ob die Batteriespannung größer als 12V bzw. 24V ist. Wenn sie weniger als 12V bzw.
  • Page 13: Anhang

    Offgridtec LifePO4 Pro 12,8V und 25,6V 6. Anhang BMS - Battery Management System – 12V Schutz Abschaltungsgrund Wiederherstellung a. Ladestop 15土5S < 1.0C Temperatur Abschaltung oder b. Entladen> 2A 1.0-1.5C Verzögerung 3-10S oder c. < +50°C und >0°C Laden 1 5 -3.0C Verzögerung 1-3S...
  • Page 14: Bms - Battery Management System - 24V

    BMS - Battery Management System – 24V Schutz Abschaltungsgrund Wiederherstellung a. Ladestop 15土5S < 1.0C Temperatur Abschaltung oder b. Entladen> 2A 1.0-1.5C Verzögerung 3-10S oder c. < +50°C und >0°C Laden 1 5 -3.0C Verzögerung 1-3S oder d. Ladestrom< 0. 5 C >3.0C...
  • Page 15: Haftungsausschluss

    Unsachgemäße Ausführung der Installation/Konfiguration kann zu Sachschäden und damit zur Gefährdung von Personen führen. Der Hersteller kann weder die Erfüllung der Bedingungen noch die Methoden bei Installation, Betrieb, Verwendung und Wartung des Systems überwachen. Offgridtec übernimmt daher keinerlei Verantwortung oder Haftung für Verluste, Schäden oder Kosten, die durch unsachgemäße Installation/Konfiguration, unsachgemäßen Betrieb und falsche Verwendung und...
  • Page 16: Impressum

    Impressum Offgridtec GmbH Im Gewerbepark 11 84307 Eggenfelden WEEE-Reg.-Nr. DE37551136 +49(0)8721 91994-00 info@offgridtec.com www.offgridtec.com CEO: Christian & Martin Krannich Sparkasse Rottal-Inn Konto: 10188985 BLZ: 74351430 IBAN: DE69743514300010188985 BIC: BYLADEM1EGF (Eggenfelden) Sitz und Registergericht: HRB: 9179 Registergericht Landshut Steuernummer: 141/134/30045 Ust-IdNr: DE287111500 Gerichtsstand: Mühldorf am Inn...
  • Page 17 Offgridtec LifePO4 Pro 12,8V und 25,6V User Manual — 16 —...
  • Page 18: Safety Guidelines And Security Measures

    Ensure the LiFePO4-Pro is connected correctly (observe polarity!)   Check the LiFePO4 Pro for external damage upon receipt. If any damage is present, do not put the battery into operation and contact your dealer. DANGER OF EXPLOSION AND FIRE The connections of the lithium battery are always live.
  • Page 19: Characteristics

    Offgridtec LifePO4 Pro 12,8V und 25,6V 2. Characteristics Longer cycle life: Provides up to 20 times longer cycle life and five times longer life than lead-  acid batteries, which helps minimize replacement costs and reduce overall costs. Lower weight: Approximately 40% of the weight of a comparable lead-acid battery. A "drop-in"...
  • Page 20: Battery Specifications

    3. Battery Specifications Model 12V 100A 12V 200Ah 24V 100Ah Article number 2-01-017315 2-01-017320 2-01-017365 Nominal voltage 12,8V 25,6V Capacity 100Ah 200Ah 100Ah Energy capacity 1280Wh 2560Wh Charging voltage 14.4V (14.6Vmax.) 28.8V (29.2V Max.) Discharge cut-of f voltage 10.8V...
  • Page 21: Function Of The Bms (Batterie-Management-System)

    Offgridtec LifePO4 Pro 12,8V und 25,6V 4. Function of the BMS (Batterie-Management-System): Protection of the cells against undervoltage  Protection of the cells against overvoltage  Protection of the cells against overloading  Short circuit protection  Protection of the cells against excessively high or low temperatures ...
  • Page 22 Tips for charging Regarding the charging voltage: Based on the characteristics of Lithium Iron Phosphate (LiFePO4) batteries, the voltage may appear higher during the charging process. The battery voltage will stabilize to the actual voltage approximately 15 minutes after the charging process.
  • Page 23: Storage

    Offgridtec LifePO4 Pro 12,8V und 25,6V State of Charge (SOC) Since there are subtle differences between the voltages of individual batteries, the following parameters are for reference only. 15 minutes after disconnecting from the charger and loading, the voltage at rest (at zero current) must be checked.
  • Page 24: And Series Connection

    Parallel- and Series Connection Connection-Tips Before connecting batteries in series or parallel, follow the battery checks described below: a. Connect batteries with the same capacity (Ah) only. b. Connect batteries of the same brand only.. Two necessary steps before connecting: These two steps are necessary to reduce the voltage difference between the batteries, allowing the battery system to perform optimally in series and/or parallel.
  • Page 25 Offgridtec LifePO4 Pro 12,8V und 25,6V Series connection of LiFePO4 batteries Amount of Charging cut-off Discharging cut- System voltage batteries voltage off voltage 12v / 24v 2 units / 1unit 28.8V 21.6V 4 units / 2 units 57.6V 43.2V Series connection is not recommended due to the lack of balancing wires, which can result in asynchronous charging and discharging.
  • Page 26 Avoid any form of damage, such as dropping or attempting modifications.  Ensure the LiFePO4-Pro is connected correctly (observe polarity!)  Check the LiFePO4 Pro for external damage upon receipt. If any damage is present, do not  put the battery into operation and contact your dealer. — 25 —...
  • Page 27: Troubleshooting

    Offgridtec LifePO4 Pro 12,8V und 25,6V 5. Troubleshooting Battery cannot be discharged Check if the battery is securely connected. Verify if the positive and negative terminals of the battery are correctly connected. Check if the battery voltage is greater than 12V or 24V. If it is less than 12V or 24V, charge the battery first.
  • Page 28: Attachement

    6. Attachement BMS - Battery Management System – 12V Protection Shutdown Reason Restoration a. charge stop 15土5S < 1.0C Temperature shutdown oder b. discharge> 2A 1.0-1.5C Delay 3-10S c. < +50°C und >0°C Charge 1 5 -3.0C Delay 1-3S d.
  • Page 29: Bms - Battery Management System - 24V

    Offgridtec LifePO4 Pro 12,8V und 25,6V BMS - Battery Management System – 24V Protection Shutdown Reason Restoration a. charge stop 15土5S < 1.0C Temperature shutdown oder b. discharge> 2A 1.0-1.5C Delay 3-10S c. < +50°C und >0°C Charge 1 5 -3.0C Delay 1-3S d.
  • Page 30: Disclaimer

    Improper execution of installation/configuration can result in property damage and pose a risk to individuals. The manufacturer cannot monitor compliance with the conditions or methods of installation, operation, use, and maintenance of the system. Therefore, Offgridtec assumes no responsibility or liability for losses, damages, or costs arising from improper installation/configuration, improper operation, and incorrect use and maintenance, or any related matters.
  • Page 31: Impressum

    Offgridtec LifePO4 Pro 12,8V und 25,6V Impressum Offgridtec GmbH Im Gewerbepark 11 84307 Eggenfelden WEEE-Reg.-No. DE37551136 +49(0)8721 91994-00 info@offgridtec.com www.offgridtec.com CEO: Christian & Martin Krannich Sparkasse Rottal-Inn Account: 10188985 BLZ: 74351430 IBAN: DE69743514300010188985 BIC: BYLADEM1EGF (Eggenfelden) Seat and district court...

This manual is also suitable for:

2-01-0173152-01-0173202-01-017365
