BCE45LV2 & BCE60LV2 –
OPERATION AND SAFETY USER
MANUAL
USER MANUAL
CONTROLLED DOCUMENT No.: 00234UIRS0123V1
IMPORTANT SAFETY INSTRUCTIONS
Before using this product, please read this user manual, if you do not understand any of the
instructions within, please do not use the product and consult your retailers or the manufacturer.
Failure to follow these instructions may result in damage to the product, property and/or cause
personal injury to the user or bystanders.
SAFETY, OPERATION & MAINTENANCE INSTRUCTIONS FOR:
KEEP THIS BOOKLET FOR FUTURE REFERENCE
ELITE
BCE45LV2 & BCE60LV2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HSC ELITE BCE45LV2
Summary of Contents for HSC ELITE BCE45LV2
- Page 1 ELITE BCE45LV2 & BCE60LV2 – OPERATION AND SAFETY USER MANUAL USER MANUAL CONTROLLED DOCUMENT No.: 00234UIRS0123V1 IMPORTANT SAFETY INSTRUCTIONS Before using this product, please read this user manual, if you do not understand any of the instructions within, please do not use the product and consult your retailers or the manufacturer. Failure to follow these instructions may result in damage to the product, property and/or cause personal injury to the user or bystanders.
-
Page 2: Table Of Contents
Table of Contents Inspect your new product Page 3 Page 3 Product Key Component Identification Page 4 General Safety Information Caution Page 4 Page 5 Installation and Set-up Page 5 Control Panel & Wiring Diagram Maintenance, testing and troubleshooting Page 6 Page 6 Storage &... -
Page 3: Inspect Your New Product
Inspect your new product Thank you for purchasing the Elite BCE45LV2 & BCE60LV2 manufactured to the highest standards drawing upon over 20 years’ experience supplying the UK hire and construction industry, this product will, if used in accordance with these operating instructions, labels affixed to the product and properly maintained, provide you with many years of reliable service. -
Page 4: General Safety Information
General Safety Information Do not position the cooler up against the wall and position near any other structure that may restrict the air flow around the unit. Ensure a 1-meter gap is observed around the unit when in use. Always ensure there is sufficient air flow around all sides of the unit. When not in use always remove the unit from the power supply. -
Page 5: Installation And Set-Up
Installation and Set-up Assembly instruction and any other consideration for the safe set-up of the product. Remove packaging used to secure product in transit including any materials to protect the cooling pads Attach castors to the bottom of the unit. For the BCE45LV2 the castors attach directly onto the base moulding. -
Page 6: Maintenance, Testing And Troubleshooting
Maintenance, testing and troubleshooting To maximise the performance of the Elite Evaporative cooler it is suggested to drain the water completely at • the end of each day. This will ensure the prolonged life of the cooling pads and help prevention of mineral deposits inside the unit. -
Page 7: Specification Data Table
Specification Data Table Model Elite BCE45LV2 Elite BCE60LV2 Power Supply (V) 230VAC 50Hz 230VAC 50Hz Power – Motor (W) Power – Pump (W) 4500 4700 Air Volume (m³/h) Cooling Effect (°C) 4-12 4-12 Cooling Area (m²) 30-50 30-60 Size (mm) WxDxH... -
Page 8: Recycling
ENVIRONMENTAL PROTECTION: Please recycle any unwanted materials as opposed to disposing them as general waste. It is recommended the original packaging is retained and used to store the product when not in use for prolonged periods of time. If this is not applicable ensure the materials are sorted and recycled in accordance with local regulations.
