Chino D01M User Manual

Signal decoder board

Advertisement

Quick Links

D01M
SIGNAL
DECODER BOARD
USER MANUAL
V1.0.2
2022.10
www.chinowing.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D01M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Chino D01M

  • Page 1 D01M SIGNAL DECODER BOARD USER MANUAL V1.0.2 2022.10 www.chinowing.com...
  • Page 2: Table Of Contents

    错误!未定义书签。 Main module ..................3 Product instruction ............错误!未定义书签。 D01M schematic diagram ..............4 D01M wire instruction diagram ............5 D01G Instruction for use ................6 D01G signal output setting ..............6 D01G output line sequence description ..........8 D01M instruction for use ................9 serial signal input ..........
  • Page 3: Disclaimer

    D01 is mainly designed for the sharing of different application protocol requirements. D01 is divided into D01G and D01M encoding and decoding. D01G is integrates in T30 T31 T40. D01M is used for wireless transmission with V21 series or third party network video transmission.
  • Page 4: D01M Schematic Diagram

    Accessories XT30 power line *1 GH1.25 4pin *4 GH1.25 3pin *1 For serial port and Power for module For CAN data connection device connection (DC:7.4-60V) Product instruction D01M schematic diagram www.chinowing.com...
  • Page 5 Serial port custom protocol for remote control assistant software ⑥RS232 interface:only support signal output For remote control and device communication ⑦Signal indicator Corresponding to each signal, the output is bright, and the input is off ⑧SET key For upgrade operations D01M wiring using diagram www.chinowing.com...
  • Page 6: D01G Signal Output Setting

    After the connection is complete, please refer to the following steps to check the connection status.(This step will have some differences due to different controllers) CAN interface TTL/RS232 interface D01M GND application D01M GND application equipment equipment SBUS interface D01M...
  • Page 7 software to use BSUS or serial port signal according to your needs.If you use a serial port, confirm the type of the link serial port,which provides TTL and RS232 level signal outputs, and also select the corresponding signal output in the assistant software.
  • Page 8: D01G Output Line Sequence Description

    D01G output line sequence description In order to meet the various needs of users, the external output of 3 kinds of signals shares a serial port,T40N,T31N,T30N and other ground control stations,and the aviation socket 6pin distinguishes the line sequence when different signals are output,as follows: 1,2,3pin corresponding line sequence Signal...
  • Page 9: D01M Instruction For Use

    After the D01M is powered on, there is no signal input, and the LED is in the state of running water light. When the signal output is turned on, the corresponding signal LED is always on.
  • Page 10 Custom CAN protocol If you use the CAN protocol output,you need to open the CAN output,as shown below: The baud rate supports 50K-1M , and the transmission frequency can be customized and filled in according to your needs. Add custom data and click”+”after sending , as shown in the figure below: Every time you click “+”,a custom data setting box will popup,and the custom data includes”standard identifier”and “extended...
  • Page 11 the operation protocol can be customized according to the requirements. Data length each frame of data is 8 bits,click the “set button”,as shown below : After opening the settings, a configuration box will popup.Each frame of data is 8 bits,and each bit is divided into two types:linear and nonlinear.Linear data refers to:Joystick,wave wheel,knob.Each linear channel occupies one bit,and the linear physical channel and phase can be mapped arbitrarily.Contains all physical buttons, each 1 bit has 8 bytes,then there are 8...
  • Page 12  take effect. Only when the link is established and D01M is in the normal connection state can  the written data be valid. All linear channel output values are -127 to 127,and the median output is 0.When the data is selected as NONE, the output can be customized to output a...
  • Page 13 When configuring the data channel,it Can only be written and saved normally when the link and D01M are working normally.You can click refresh in the custom CAN protocol data , and the CAN protocol data written to D01M last time will be read after refreshing.As shown below.
  • Page 14 Channel data range -10000 to 10000,you can customize the allocation range,as shown below The frame header and frame trailer of the data frame are also custom settings,and are output in hexadecimal format.Sending frequency:range10-200 default20,precision 5ms; The data format supports two types of “大端” and “小端”,and the check mode supports four types:Sum check,XOR check CRC16 check,and CRC32 check.
  • Page 15: Sbus Output Setting

    Physical channel setting, according to different ground station products,the upper computer automatically recognizes the physical channels such as:T40 20 physical channels, T31 35 physical channels,T30 23 physical channels,all can be customized mapping, and phase inversion. SBUS output setting SBUS output setting,two-way output switch,turn on to output SBUS in”comprehensive settings”-”Output settings,and turn it off to not output.
  • Page 16: D01M Indicator Instruction

    D01M indicator instruction indicator status meaning Always on TTL signal output on TTL signal output off Always on 232signal output on RS232 232signal output off Always on SBUS signal output on(any SBUS type) www.chinowing.com...
  • Page 17: Firmware Upgrade

    2. Press and hold the set button to power on, at this time, all the LED lights of D01M are always on, and then release the set button,the upgrade software will display the port number and firmware information,which means it has entered the upgrade mode.
  • Page 18: Common Question

    Common question 1 : The ground unit can not link with the airborne unit,or the connection is disconnected. There will be interference if two or more devices are turned on at the same time,and the key and frequency band can be modified; 2:Unable to pull streaming video in the video player Please confirm whether the IP address of the receiver computer is in the same network segment as the IP camera.
  • Page 19: Historical Version

    Historical version DATE VERSIO DESCRIPTION AUTHOR 2022.10.10 V1.0 Initial version 2022.10.27 V1.0.2 Release version www.chinowing.com...
