XS9
DONGLE
| MANUAL
Built-in 2.4GHz WiFi functionality
Firmly connect via the XS9 interface to the steering wheel
Enable the steering wheel to access telemetry data for PS4/5
Make the steering wheel and Fanatec DD Pro work together on PS4/5
Compatible exclusively with Fanatec DD Pro(PS Mode)
To make the steering wheel wireless-enabled
To access the built-in PS dashboard on the steering wheel
Advertisement
Table of Contents
Summary of Contents for LEOXZ XS9
- Page 1 DONGLE | MANUAL Built-in 2.4GHz WiFi functionality Firmly connect via the XS9 interface to the steering wheel Enable the steering wheel to access telemetry data for PS4/5 Make the steering wheel and Fanatec DD Pro work together on PS4/5 Compatible exclusively with Fanatec DD Pro(PS Mode)
- Page 2 • Before inserting the XS9 Dongle into the steering wheel, please make sure to disconnect the power supply to the steering wheel. This means removing the steering wheel from its base, connecting the XS9 Dongle, and then reinserting the steering wheel onto the base shaft.
-
Page 3: What's Included
What's included • XS9 Dongle Compatible wheelbase • Fanatec DD Pro C ompatible steering wheel • XF1 Pro • XF1 Sport-USB C ompatible PS4/5 games • Gran Turismo 7 • More games will be supported through firmware updates... - Page 4 Note: When the steering wheel is connected to the XS9 Dongle, all power to the steering wheel is supplied through the Leoxz Fanatec QR via the DD Pro. Therefore, it is necessary to keep the steering wheel connected to the DD Pro in order for all functions to work properly.
-
Page 5: Installation
Installation The XS9 Dongle can be easily connected by inserting it into the XS9 interface on the steering wheel. It's important to note that when inserting the XS9 Dongle, you should align the notch direction of the interface correctly. Forcing the insertion can result in permanent damage to the components. -
Page 6: Available Features
Available Features RPM Leds XF1 Pro Share Option Joy+Push D-Pad+Push Tuning Button Setting Button Note: The buttons that are labeled are available, while the unlabeled buttons, all axes paddles, and flag indicator lights are not available. L2, L3, R2, R3 functions are mapped to the buttons and thumb encoders, allowing you to choose the input method based on your preference. Joy supports only simple input for up, down, left, and right directions and cannot input analog values. - Page 7 Available Features RPM Leds XF1 Sport-USB JOY UP D-Pad UP JOY LEFT D-Pad RIGHT Share Option JOY RIGHT D-Pad LEFT D-Pad Push JOY Push JOY Down D-Pad Down Tuning Button Setting Button Note: The buttons that are labeled are available, while the unlabeled buttons, all axes paddles, and flag indicator lights are not available. L2, R2 functions are mapped to the buttons and thumb encoders, allowing you to choose the input method based on your preference.
-
Page 8: Wifi Connect
WiFi Connect By pressing the Setting button, you can navigate through different menus. You can input the WiFi name and password using the 7-way switch located on the right side. The steering wheel will automatically connect to the network. Please ensure that both the PS4/5 and the steering wheel are connected to the same local area network (LAN). - Page 9 Update When the XS9 Dongle is connected to WiFi with internet access, long-press the update button. The status led will remain steady, indicating it has entered the update state. The XS9 Dongle will automatically download the latest firmware from the Leoxz remote server via WiFi for the update.
- Page 10 Copyright © 2023 Leoxz® All Rights Reserved...
