AES 4G Router v2 Manual

AES 4G Router v2
* ALWAYS TEST THE UNIT ON SITE
A CLOSER LOOK AT THE 4G ACCESS POINT
PCB boot status LEDs
GSM 4G Antenna
Connection strength LEDs
LAN 2B
SIM
CAUTION: Ensure input orientation matches
with the diagram above.
Additional setup steps are required if using a different SIM that the Vodafone SIM
that is provided with the unit. Please scan this QR code or search on our website
for the 'How To Change APN Guide'.
- Access Point Enclosure
BEFORE INSTALLATION TO AVOID RESTOCKING FEES *
50V
RVT
16V
LAN port activity LEDs
VT
101
LAN 1 LAN 2A
LAN 2A - Connect LAN cable to intercom PCB.
*IF USING A MODULAR 4G KIT THIS MAY COME PRE-WIRED*
LAN1 – Only required if APN needs changed to
match the SIM being used.
Hardwire LAN 2B connector
to intercom PCB. Optional
use instead of LAN 2A port.
- ATTENTION! -
SIM ORIENTATION
ALWAYS ensure that the system is
switched OFF
removing the SIM card and also ensure
that the orientation is correct before
24v DC OUT.
(optional)
powering the router back on.
PCB BOOT STATUS LEDS
When the PCB has successfully booted
24v DC IN.
White = 0v (Negative)
up you should have activity on all 3 LEDs:
Black = 24v (Positive)
RED: Constant ON =
GREEN: Steady Flash =
BLUE: Steady Flash =
DATA TRANSFER LEDS
The 2 LEDs behind LAN 1 Port will flash
you have connection activity.
SIGNAL STRENGTH LEDS
The 3 LEDs behind LAN 1 Port will illuminate WHITE.
- Flashing = 3G signal
- Solid On = 4G signal
LIGHTNING PRONE AREAS
MUST USE SURGE PROTECTION
Praetorian Guard
FOR POWER SUPPLY & RJ45!
NEW Gen of our Wi-Fi/4G Intercom Range.
- With an all NEW APP!
- Program PROX & Keypad codes from our app
- Callers can leave messages when unanswered
- Notify when gate is triggered
- Motion Sensor with auto record & notify
- HD Camera
STILL HAVING TROUBLE?
Find all of our support options such as Web Chat,
Full Manuals, Customer Helpline and more on
our website:
WWW.AESGLOBALUS.COM
any time you are adding or
PCB Powered ON | Constant OFF = PCB Powered OFF
Connected to Network| Constant OFF =
Standby Mode | Constant OFF = Booting / OFF
GREEN when
SIM
Not Connected
LAN 1
LAN 1
