MK Plastics PRVS Installation, Operation And Maintenance Manual

INSTALLATION, OPERATION AND MAINTENANCE MANUAL
Introduction
This bulletin contains the proper installation, operation and
maintenance procedures for the standard PRVS High
Pressure/Low Volume Centrifugal Fiberglass Blower to
ensure safe and trouble-free blower operation. This bulletin
complements good general practices; however it is the
responsibility of the purchaser
personnel experienced in the installation, operation and
maintenance of air moving equipment.
The M.K. Plastics catalog on the PRVS blower provides
additional information describing the equipment, blower
performance, available accessories and specifications. It is
available via our website at www.mkplastics.com.
For additional safety information, refer to AMCA publication
410: Recommended Safety Practices for Users and
Installers of Industrial and Commercial Fans.
For information on special blower application requirements,
please contact the M.K. Plastics corporate office at
+1-514-871-9999, US Toll Free: 1-888-278-9988 or via our
website at www.mkplastics.com.
Figure 1
PRVS Centrifugal Fiberglass Blower
WARNING
This unit has rotating parts. Safety precautions should
be exercised at all
operation, and maintenance.
ALWAYS disconnect power prior to working on blower.
Electrical Disconnects
Every motor-driven blower or fan should have an
independent disconnect switch to isolate the unit from the
M.K. Plastics Corp. Montréal, Québec, Canada
to provide qualified
times during installation,
+1-514-871-9999
PRVS
Centrifugal Fiberglass Blower
electrical supply. The disconnect switch should be near the
blower and must be capable of being locked by
maintenance personnel
Maintenance personnel must be provided complete control
of the power source.
Moving Parts
All moving parts must have guards to protect personnel. All
PRVS blowers are supplied with vented FRP belt and shaft
guards. Never start a blower without having all safety
guards installed. Check regularly for damaged or missing
guards and do not operate any blower with guards
removed.
Sound
Blowers can generate sound that could be hazardous to
exposed personnel. Appropriate ear protection should be
used by maintenance personnel.
Air Pressure and Suction
Blowers present a hazard from the suction created at the
blower inlet. This suction can draw materials into the
blower where they become high velocity projectiles at the
outlet. Inlets and outlets that are not ducted should be
screened to prevent entry and discharge of solid objects.
PRVS blowers can be supplied with inlet and/or outlet PVC
or stainless steel screens.
View Ports
View Ports to the duct system should never be opened
while the blower is in operation. Serious injury could result
from the effects of air pressure or suction.
Receiving and Inspection
All M.K. Plastics blowers and fans are carefully inspected
before leaving the factory. Compare all components with
the bill of lading or packing list to verify that the proper unit
was received. Check each unit for any damage that may
have occurred in transit:
•
Turn the wheel by hand to ensure it turns freely
and does not bind.
•
Inspect the dampers (if supplied) for free operation
of all moving parts.
•
Record on the Delivery Receipt any visible sign of
damage.
Mishandled units can void the warranty provisions. If units
are damaged in transit, it is the responsibility of the receiver
to make all claims against the carrier. M.K. Plastics will
assist the customer as much as possible; however claims
must be originated at the point of delivery. M.K. Plastics is
not responsible for damages incurred during shipment.
www.mkplastics.com
Bulletin 25-02-February 2017
while servicing the
Page 1 of 12
unit.
