INSTALLATION & OPERATION MANUAL
Gas Countertop Griddle
Models:
Manually Controlled:BFMG-24, BFMG-36,BFMG-48, BFMG-60
(24"Griddle)
(36"Griddle)
(48"Griddle)
(60"Griddle)
Blue Flame
223 W. Rosecrans Ave.
Gardena CA 90248 USA
Tel : 1.866.677.8500 / 1.310.808.0102
Fax : 1.310.808.0242 / 1.310.808.0262
WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR
MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE
INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR SERVICING THIS EQUIPMENT.
1
Advertisement
Summary of Contents for Blue Flame BFMG-24
- Page 1 INSTALLATION & OPERATION MANUAL Gas Countertop Griddle Models: Manually Controlled:BFMG-24, BFMG-36,BFMG-48, BFMG-60 (24”Griddle) (36”Griddle) (48”Griddle) (60”Griddle) Blue Flame 223 W. Rosecrans Ave. Gardena CA 90248 USA Tel : 1.866.677.8500 / 1.310.808.0102 Fax : 1.310.808.0242 / 1.310.808.0262 WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH.
- Page 2 For Service on Your Gas Griddle: Please call the Blue Flame Service Department and ask for contact information for your local service company. This manual contains important safety instructions which must be strictly followed when using this equipment. Please retain this manual for future reference.
-
Page 3: Table Of Contents
Index ATTENTION OWNERS AND OPERATORS....................3 UNPACKING & INSTALLATION....................... WARNINGS & SAFEGUARDS FOR OPERATION ...................6 OPERATING INSTRUCTIONS......................... CLEANING INSTRUCTIONS ........................9 TROUBLESHOOTING ..........................10 LIMITED WARRANTY..........................11... -
Page 4: Attention Owners And Operators
Attention Owners and Operators Equipment is designed to provide safe and productive processing, cooking and warming of food products as long as the equipment is used in accordance with the instructions in this manual and is properly maintained. Unless the operator is adequately trained and supervised there is a possibility of serious injury. Owners of this equipment bear the responsibility to make certain that this equipment is used properly and safely, and to strictly follow all of the instructions contained in this manual and the requirements of local, state or federal law. - Page 5 TO AVOID SERIOUS PERSONAL INJURY AND PROPERTY DAMAGE: · ALWAYS install equipment in a work area with adequate light and space. · ONLY operate on a solid, level, nonskid surface that is nonflammable and away from sinks and water hazards. ·...
-
Page 6: Unpacking & Installation
Unpacking & Installation INSTALLATION Read this manual thoroughly before installation and operation. DO NOT proceed with installation and operation if you have any questions or do not understand anything in this manual. Contact your local representative first. 2. Select a location for the Griddle that has a level, solid, nonskid surface that is nonflammable and away from water hazards or sinks, and is in a well-lighted work area away from children and visitors. - Page 7 TO AVOID SERIOUS PERSONAL INJURY AND PROPERTY DAMAGE: For your safety, do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliances. Keep the area free and clear of combustible. (See ANSI Z83. 14B, 1991). Improper installation, adjustment, alteration, service or maintenance of this equipment can cause property damage, personal injury, or death and voids warranty.
-
Page 8: Operating Instructions
Operating Instructions Operating the Griddle - Pilot Lighting Instructions for MANUALLY CONTROLLED Griddles Before operating Griddle, it should be checked to see that it is sitting level. Adjust the feet to level the Griddle. Be sure the catch tray has been properly placed. The pilot light on the appliance have been set at the factory. - Page 9 Operating Instructions Igniting the Burner To ignite the burner, turn knob to the “ON” position. Then back off to the desired flame level. The range of adjustment is virtually infinite between “ON” and “OFF”. The space between the legs at the bottom admits combustion air. DO NOT BLOCK THIS SPACE. All burners are lit from constantly burning pilots.
- Page 10 · DO NOT use any abrasive or flammable cleaning fluids. · DO NOT hose down, immerse or pressure wash any part of the Griddle, excluding the catch tray. · NEVER use a scrubber pad (on all exterior surfaces, except the griddle plate), steel wool or abrasive material, or cleaners containing chlorine, iodine and ammonia or bromine chemicals as these will deteriorate the stainless steel and shorten the life of the unit.
-
Page 11: Troubleshooting
Troubleshooting ISSUE CAUSE SOLUTION Griddle not lighting Main gas line is closed Open valve Pilot light is not lit Ignite pilot light Cause unknown Call for service Flame is too high or too low Adjust flame with control knob Adjustment knob is turned up or down Pilot light not staying lit Flame is too low... - Page 12 Conversion Kit Instructions Gas Countertop Griddle These conversion instructions are for conversion of the GAS GRIDDLE. The instructions provide in this kit are for the conversion of Natural Gas to L.P. gas and refer to the conversion of the unit and kit provided. An authorized licensed technician must be called to perform the complete conversion of the unit.
- Page 13 L.P. Position of insert. Regulator is now converted to L.P. Continue with installation.
- Page 15 When service is needed, contact a BLUE FLAME Authorized Service Agency, or your dealer. To avoid confusion, always refer to the model number,...
-
Page 16: Limited Warranty
Periodic maintenance is not covered. This warranty is not in force until such time as a properly completed and signed installation/warranty registration or an online registration form has been received by BLUE FLAME within 30 days from the date of installation.
