Summary of Contents for DUSTSILVER D84
- Page 1 Make input more ritualistic APPLICABLE MODELS： D84...
- Page 2 Scan the QR code to enter the official website to download the driver software & electronic version of manual...
- Page 3 Product specication Product name DUSTSILVER D84 Product size 356*137*42.5（mm） Weight ≈ 920（g） Number of keys Battery Capacity 3750mAh Working Voltage DC5V Operating Current ≤ 300mA Connection Modes USB TYPE-C/Bluetooth/2.4G System Support Windows/Mac OS/Android/IOS...
- Page 4 Product pictorial Transparent dust cover The keyboard can be covered when not in use D84 Keyboard (2.4G signal receiver included) USB Type-C data cable Data cable conversion plug Accessory box keycap/switch puller keycaps for MacOS Randomly send switch,Cleaning brush ,...
- Page 5 Switch Pairing & Connection 2.4G sig na l receiver Co nnectio n mo de switching switc h Connection mode switching switch Switching direction: left Switching direction： Middle Switching direction: Right 2 .4 G wireless m ode Bl uetoot h wi re l e ss mod e Wi red mode Connect via the signal receiver Connecting devices via Bluetooth pairing...
-
Page 6: Wired Mode
<Please switch the on/off button to the corresponding mode before connecting> Wired mode W ire d de v i ce na m e ： D 84 K B The Type-C interface of the data cable is connected to the keyboard, and the USB port is connected to the device to be connected. -
Page 7: Bluetooth Mode
B l u eto ot h d e v ice n am e : B l u eto ot h 5 . 0: D 8 4 KB 5 . 0 / B l u eto ot h 3 . 0 : D 84 K B 3. 0 Open the Bluetooth connection interface Long press the key combination of the device and click Connect D84 KB 5.0 Fn +1 /2/ 3 (3 seconds), the corresponding or D84 KB 3.0, the backlight will return to Q / W / E backlight into the flashing state,... - Page 8 <Please switch the on/off button to the corresponding mode before connecting> 2.4G wireless mode 2 . 4 G d ev ice nam e： 2 . 4 G W ire l e s s Ke y board Plug the 2.4G signal receiver into the USB If you use a non-factory signal receiver, port of your computer and the device is you need to perform the following...
- Page 9 Knobs and Indicator Lights Lock function indicator light When switching to uppercase using Capslock key, the left half of the indicator light is always on red; when switching to lowercase, the indicator light returns to normal state. When Win key is locked (Fn + Win), the right half of the indicator light is always on blue; when repeatedly performing the operation, it unlocks and returns to normal state.
- Page 10 Common key combinations Windows Mac OS Fn+Esc Long press for 3 seconds to restore factory Fn+~ Turn on/off the backlight Player Increase screen Fn+F1 Fn+F2 Lower the screen Previous song Fn+F3 Pause/Play Task menu Fn+F4 Next song Search Fn+F5 Volume down Siri Fn+F6 Raise the volume...
- Page 11 Windows Mac OS Calculator Raise the volume Fn+F12 Fn+WIN Lock the windows system menu Fn+W Switch to the Windows system Fn+M Switch to the Mac system Fn+Q Switch the main backlight effect Fn+A Switching the main backlight color Fn+Del Switching main backlight dynamic light effect direction Fn+PrtSc Insert Fn+Pause...
-
Page 12: Power Check
Windows Mac OS Fn+1 Short press to switch to Bluetooth channel 1; long press for 3 seconds to enter pairing mode for Bluetooth channel 1 Fn+2 Short press to switch to Bluetooth channel 2; long press for 3 seconds to enter pairing mode for Bluetooth channel 2 Fn+3 Short press to switch to Bluetooth channel 3;... - Page 13 This product and its packaging have passed RoHS testing and are RoHS compliant Environmentally friendly usage life Environmentally friendly material application We use recyclable materials and optimize the design to further enhance the user experience while protecting the legal rights of users. Packaging weight reduction Lightweighting of instruction manuals Con ta ct us...
