Screw Cam Clamp

SCC

SCC-W

Operation Manual

This operation manual explains the basic

operation and handling of the clamps.

Please read this manual carefully before

use and observe the precautions for safe

operation.

SUPER TOOL CO., LTD.

Table of Contents

Need help?

Do you have a question about the SCC and is the answer not in the manual?

Questions and answers

Summary of Contents for Super SCC

Page 1 Screw Cam Clamp SCC-W Operation Manual This operation manual explains the basic This operation manual explains the basic operation and handling of the clamps. operation and handling of the clamps. Please read this manual carefully before Please read this manual carefully before...
Page 3 brand lifting clamps are energy-saving lifting equipment which have been developed for the purpose of transporting steel materials. Proper use Operate lifting clamps after carefully reading and understanding this instruction manual for enhancing efficiency and safety of operation. Prime efficiency and economy Advanced functions, reasonableness and versatile applications of finely and carefully designed lifting clamps ensure...
Page 4 Precautions for safety operation (Pages 1〜10 are comon to all lifting clamp models) Be sure to read this instruction manual carefully before use. Mistaken use of lifting clamp may cause a danger such as dropping of load. Education of “crane safety regulations,” “operation manual for lifting clamp,”...
Page 5: Check Before Operation
1. Handling in general WARNING ● Do not operate until the contents of the operation manual, and caution tag/plate are thoroughly read and understood. ● Do not operate without a legal qualification. ● Be sure to clear of the area of the operation for lifting or turning a load against possible drop off or fall over.
Page 6: Lifting Operation
3. Lifting operation WARNING ● Do not use clamp, lifting at one point. (excluding special or custom ordered products) ● Do not use the clamp in the following ways of lifting: lifting of two or more individual objects at one time. (overlapped loads, padded load etc.
Page 7 ● Stop the lifting operation by crane for a moment when the load is applied to the lifting ring for safety checking. (depth of the load into the clamp opening; status of locking). ● Stop the operation of the crane just before the load reaches the ground, and check the following matters: (Inclination or Instructed falling over of the load and security around the landing area...
Page 8 ■ General warning for use (comon to all lifting clamp models) Be sure to select proper model clamps for use. Pay special attentions to keep the lifting direction (rope angle). Confirm the weight of the load. Do not exceed maximum capacity (designated ton) on clamps.
Page 9 Never lift two or more steel plates or steel members at a time. The load may move to an unexpected direction when lifted off the ground and as such confirm the center of gravity and the clamping posi- tion for safety when raising. Sufficient caution should be taken until the clamp with the load becomes completely balanced.
Page 10: Maintenance And Inspection
■ Maintenance and Inspection 1. Maintenance Daily maintenance is important for efficient and safe operation even under the severe use condition and for such purposes, please comply with the followings. (1) Designate the use standards and control. (2) Keep clamps indoor and do not leave them outdoor. (3) Check the followings to maintain in a good condition.
Page 11 (2) Standards on periodic inspection (A) Establishing dates of periodic inspection. (B) Establishing inspection and maintenance methods. (a) Inspecting period. (b) Person in charge of the inspection. (c) Inspection site. (d) Tools and devices for inspection. (e) Establishment of permissible limit of use. ( f ) Explicit designation of maintenance and repair methods.
Page 12 Lifting angle and rated load of wire rope The maximum rated capacity of wire ropes also diﬀers according to the lifting angle. Therefore, after paying attention to the lifting angle, always use wire ropes with the appropriate diameter. Correlation table between the lifting angle and the applicable load for wire rope (for 2-point lifting) ■ ■ JIS G 3525 6×24 A type W rated load (for 1 single rope) D wire rope diameter Safety factor Ｓ＝6 (Change in % of the lifting capacity rate according to the lifting angle) 100% Maximum allowable load (rated load) for 2 wire ropes (ton) （mm）（ton） 6 0.30 0.60 0.57 0.51 8 0.53 1.07 1.03 0.92 ...
Page 13 Screw Cam Clamp Operation Manual and Inspection Standards...
Page 15: Specifications
The main body is a mold forged product of special alloy steel processed with optimal heat treatment, and thus, strong and durable. ■Specifications Rated Capacity Clamp Range Net Weight Item No. (ton) (mm) (kg) SCC 0.5 0〜28 SCC１ 0〜30 Standard SCC 1.5 0〜32 type SCC 3 0〜50 SCC 6 18.0...
Page 16: Replacement Parts And Assemblies
■ REPLACEMENT PARTS AND ASSEMBLIES Part No. Part Name and Assembly Name Part No./Assembly No. (Set No.) Q'ty(pc) Shackle Shackle SCCH Bolt for Shackle SCCN Cotter Pin ＊Nut for Shackle 1 set SCCT Stop Ring SCCP Hex. Hole Head Bolt SCCV Nylon Nut Screw...
Page 17: How To Use
■ How to use 1.OPERATION METHOD Screw tightens when turned clockwise, and loosens when turned counterclockwise (Right screw). When installing clamps, insert a lifting load completely until it comes in contract with the deepest of the jaw opening of Body and set in a manner that the entire circumferential teeth of inner portion of concen- tric rings touch the surface of the load.
Page 18 2. OPERATION PATTERNS ① When lifting at 2 points, keep the lifting angle within 60°. Within 60° Within 60° Keep the lifting angle within 60°between ropes. ② Always lift at 3 or more points with complicated shaped objects. (For horizontal lift, always lift at 4 points when lifting a steel plate positioned horizontally to a floor level) Within 60°...
Page 19 Main body and Shackle. ⑧ SCC0.5 and SCC-W (wide type) are for vertical lifting only. They cannot be used for horizontal lifting. (SCC0.5 can be used for horizontal lifting by using the long shackle for SCC0.5 (SCH0.5L, sold separately).)
Page 20: Disassembling And Assembling
3.DISASSEMBLING AND ASSEMBLING 1.Disassembling 1.Cam and Screw Chisel or the like ( SCC0.5, SCC0.3W ) Tap the part of Cam shown in Fig. 1 with a hammer or other tool to release Cam from Screw. ( Fig.1) (Note: Once released, Cam and Screw cannot be reused.
Page 21: Daily Inspection
■ CAUTION: ◆ Use within the rated capacity. ◆ Use within the clamp range. ◆ Do not use for any objects other than steel materials. ◆ Do not use for hard (30 HRC or higher) load. ◆ Lifting is not allowed for a load tapering down in upward direction. ◆...
Page 22 ■ INSPECTION STANDARDS FOR SCC / SCC-W Item Inspection method Limit of use Remedy Visually check or use color When found visually. dyes to find cracks. Measure for wear or When the diameter of any one part of deformation of holes of circumference of hole (D1/D2) exceeds the...
Page 23 Item Inspection method Limit of use Remedy Visually check or measure When the degree of wear exceeds 0.5mm. the degree of wear. width of wear Visually check or use color When found visually. dyes to find cracks at the bottom of teeth. crack Replace Visually check for broken...
Page 24 Item Inspection method Limit of use Remedy Measure wear and When the diameter of any one part of deformation at hole. circumference of hole (D1) exceeds the respective size in the table below. When the diameter of each part of circumference of any hole becomes smaller than respective size in the table below.
Page 26 23.9...
