- Page 1 RDFQF READ AND SAVE THESE INSTRUCTIONS Premium Installer: leave this guide with homeowner. Radiation Damper INSTALLATION GUIDE Table of Contents Usage Preparation Installation Service Feature For Fans Warranty Easy installation © 2014 Broan-NuTone LLC...
- Page 2 Broan QTRE080, QTRE080C2S, QTRE080R, QTRE110, QTXE050, QTXE080, QTXE110, SSQTXE110, SSQTXE080, QTR110F, QTRE110F, QTR080F and QTRE080F SEE DETAILS ON UL CLASSIFICATION NuTone QTREN080, QTREN110, QTXEN050, QTXEN080, QTXEN110, Smart-Sense, MARKING ON PRODUCT QTRN110F, QTREN110F, QTRN080F and QTREN080F Preparation Install Hanger Bar Mounting Channels Attach Damper Assembly to Fan 1.
- Page 3 RDFQF Installation Guide Page 3 Installation Install Fan / Radiation Damper In Ceiling Finish Fan Installation MAKE SURE FINISHED CEILING IS FLUSH WITH 5. Follow instructions packed with the fan to connect BOTTOM EDGE OF FAN HOUSING. ductwork and electrical wiring.
- Page 4 Page 4 RDFQF Installation Guide Service Feature For Fans If your ventilation fan needs service, the inner damper can be removed from the outer frame without disturbing the surrounding ceiling material. Remove the grille. Remove (4) screws, then lower the inner damper to access ventilation fan.
