Summary of Contents for SUKKAHMART RapidRoof
- Page 1 RapidRoof Assembly Instructions The ultimate Sukkah Protector Easy to assemble Simple to open and close Fits all free standing sukkahs Compact storage Kosher L'Mehadrin...
-
Page 2: Very Important
Until such time that you have stabilised the roof, do not leave the roof structure standing and compacted. Ensure that it is open until it is stabilised. Failure to do so may lead to the RapidRoof toppling over, which could cause serious injury. - Page 3 RapidRoof - Medium 2x3m? Components Horizontal Roof Poles Pole (x8) about 2m long. 2. Pole (x4) about 2m long. 3. Pole (x4) about 2m long. 4. Legs (x2) It already comes pre-assembled as in picture on right. Medium has 3 uprights, Large has 4 uprights (pictured) Extra large has 5 uprights.
- Page 4 A. Components cont. 7. Extension poles (x4) – about 50cm in length Only used if you want to make the roof higher. Not required for SukkahMart sukkas. 8. Corner Joiner (x4) – about 30cm in length 9. Middle Joiner (x4)– about 30cm in length 10.
- Page 5 Assembly Instructions STEP 1: Layout parts 1 - 4 on the ground in a triangle-like formation as per the diagram below. Arial View STEP 2: Insert Poles 1 into poles 10 and 1 1...
- Page 6 STEP 3: Attach all the Part 6s to the 10's and 1 1's. Fasten them with the short screws provided. Ensure this hole is facing the inside of the roof STEP 4: Now insert all the poles into the joiners and tighten them with the screws provided. Make sure the concertina grid is on the inside of the roof.
- Page 7 STEP 4: Attach the top 8 velcro strips to the frame as per the diagram below. velcro strip Inside of canvas velcro strip...
- Page 8 STEP 5: Lift the frame up. NB: It is recommended to use 3 people for this stage. NB: As soon as the frame is standing, open it up immediately. If left closed, it will topple over. STEP 6: Stretch out the material, attach the remaining velcros to the frame and hook the bottom hooks onto the legs of the frame.
- Page 9 STEP 7: Stabilising the RapidRoof NB: The roof must be stabilised using one of the methods below. Failure to do so could lead to the roof toppling over, which may result in injury. Method 1: Affix 2 upright bars to a wall, using the brackets provided.
- Page 10 Opening and Closing the RapidRoof Structure To open the RapidRoof structure 1. Lift the concertina cross-beams until the black pin clicks into the upright pole’s hole. (You may need to twist the upright pole to line up with the pin).
