Toshiba Satellite A65-S1362 Specifications

TOSHIBA
Satellite® A65 Series
Feature Model(s):
Satellite A65-S1362
Celeron D 325/15.0"XGA/256MB/30GB/DVD-CDRW/Mdm/LAN/WinXP Home

Product Highlights

Performance
•
Intel® Celeron® D processor 325
•
256MB of Main Memory
Great Features
•
30GB** hard disk drive
•
DVD-ROM/CDRW multi-function drive
•
15.0" TFT active-matrix display
Get On-Line
•
Integrated V.92/56K modem
•
Integrated 10/100 Ethernet LAN
System Characteristics
Operating System
•
Microsoft® Windows® XP Home pre-installed
CPU/Chipset information
•
Intel® Celeron D processor 325
2.53GHz*, 256KB L2 Cache, 533MHz Front Side Bus
o
•
ATI® MOBILITY™ RADEON™ 7000 IGP chipset
Memory
•
256MB (1 DIMM) fixed memory slot with 1 available upgradeable
slot; expandable to 1280MB
Data/Address Bus Width: 64bit/32bit
o
•
Optional available expansion memory modules:
256MB/512/1028MB, SODIMM: Memory compatible with PC2100
DDR266 and PC2700 DDR333
Mass Storage – HDD/Optical Drive
•
Primary Hard Disk Drive: 30GB** hard disk drive, Enhanced IDE
(ATA-6) interface, 4200rpm drive rotation; 9.5mm height, 0.2lbs,
Service Removable
•
DVD-ROM/CDRW Multi-function Drive: 12.7mm Enhanced IDE
(ATAPI) Interface, Service removable:
Maximum Read speed: CD-ROM (24X), CD-R (24X), CD-RW
(12X), DVD-ROM (8X), DVD-R (4X), DVD-RW (4X), DVD-RAM (2X)
Maximum Write speed: CD-R (16X), CD-RW (4X)
•
Compatibility: CD-R(read/write), CD-RW(read/re-write), DVD-
R(read only), DVD-RW(read only), DVD-RAM(read only), CD-ROM,
DVD-ROM
Graphics/Video
•
15.0" TFT active-matrix display***; internal LCD display supports up
to 16M colors at 1024 x 768 resolution
•
ATI® MOBILITY™ RADEON™ 7000 IGP graphics controller with
64MB shared video memory
•
DirectX7 supported by hardware and DirectX9 supported by
software
•
Supported external CRT resolution/color/maximum external refresh
rate (depending on CRT):
640 x 480; 16bit/32bit colors
800 x 600; 16bit/32bit colors/60/75/85/100Hz
1024 x 768; 16bit/32bit colors/60/75/85/100Hz
1280 x 1024; 16bit/32bit colors/60/75/85/100Hz
1600 x 1200; 16bit/32bit colors/60/75/85/100Hz
1920 x 1440; 16bit/32bit colors/60/75/85Hz
2048 x 1536; 16bit/32bit colors/60Hz
Input Devices
•
Keyboard: Full sized 85 keys with 12 function keys, 2.7mm key
stroke, 6mm height; Dedicated Windows® keys support; HotKey
function; TouchPad pointing device
Expandability
•
1 Memory slot available
•
1 PC Card slot support 1 Type II PC Card
Communications
•
Integrated V.92/56K modem; Data and fax support
Due to FCC limitations, speeds of 53kbps are the maximum permissible transmission rates
during download. Actual data transmission speeds will vary depending on line conditions.
•
Integrated 10/100 Ethernet LAN
Ports
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
©2004 Toshiba America Information Systems, Inc. All rights reserved
.Satellite_A65-S1362_v1.01
•
•
•
•
•
Physical Description
•
•
Sound
•
•
•
Power Supply
•
•
•
•
•
•
•
•
•
Security
•
Bios
•
Additional Software
•
•
•
•
•
•
•
•
•
•
•
•
•
TOSHIBA Software
•
•
Created on 12/15/2004 1:19 PM Rev. 1.01
RGB (monitor) port
3 Universal Serial Bus ports (USB)
TV-Out Port (S-Video)
RJ-45 LAN Port
RJ-11 modem port
Dimensions (LxWxH): 13.5" x 11.1" x 2.13" (max height with feet)
Weight: 7.7lbs****
Realtek ALC250 (on board) Codec Chip; Software Sound
Built-in stereo speakers; Direct 3D Sound (supported by sound
driver), DirectSound (supported by hardware acceleration) and
DirectMusic (supported by hardware acceleration); MIDI Support;
Sound Volume (by Dial); Full Duplex Support
Ports: External Microphone port (monaural), headphone port
(stereo)
AC Adapter: 120W external AC Adapter, 100-240V / 50-60Hz
frequency (Universal) input voltage, 19V x 6.3A Output.
Dimensions (LxWxH): 5.91" x 2.56" x 1.42"
Weight: starting at 1.43lbs****
Battery Pack: 12-cell, rechargeable, removable Lithium Ion (Li-Ion)
battery, 14.8V x 6450mAh
Dimensions (LxWxH): 10.78" x 2.82" x 0.85"
Weight: starting at 1.46lbs****
Battery Saver (in Windows XP): Stand by, HDD Auto Off, Display
Auto Off, Hibernation
Battery life (main battery): Please see battery life section *****
Recharge time (main off/on): Approx 4/14 hrs. (off/on)
Battery life may vary depending on applications, power management settings and features
utilized. Recharge time varies depending on usage. Battery may not charge while
computer is consuming full power. After a period of time, the battery will lose its ability to
perform at maximum capacity and will need to be replaced. This is normal for all batteries.
To purchase a new battery pack or see information on accessories shipping with your
computer, visit the Toshiba website at http://www.accessories.toshiba.com
Slot for computer lock, memory (1 screw), HDD (1 screw) and Built-
in Modem/LAN (1 screw), User Power-on Password, Screen Blank
(by Hotkey), Screen Saver (by software)
ACPI, PnP, VESA, DDC, SM BIOS, PCI BIOS support
Microsoft® Works®
Microsoft® Office® OneNote™ 2003
Software Decoder: InterVideo® (Win-DVD™ 4) -w/SRS
TruSurround XT® Technology (SRS® TruSurround XT®
Technology features: TruSurround, SRS Dialog Clarity
Enhancement, & TruBass)
Sonic® Solutions Drive Letter Access (DLA)
Sonic® Solutions RecordNow!™ Basic
AT&T® Worldnet® Service – 1 Month FREE
Intuit® Quicken® New User Edition 2004
Norton® AntiVirus™ 2004 – w/3-Month Subscription
AOL® (3 –Month offer)
AOL OFFER DETAILS: Availability may be limited, especially during peak times. TO
AVOID BEING CHARGED A MONTHLY MEMBERSHIP FEE, SIMPLY CANCEL BEFORE
THE THREE-MONTH PROMOTIONAL PERIOD ENDS. Premium services carry
surcharges and communication surcharges may apply, including AK, even during
promotional period. Members may incur telephone charges on their phone bill, depending
on their location and calling plan, even during promotional period. Available to new AOL
members in the United States, age 18 or older; a major credit card or checking account is
required.
Adobe® Acrobat Reader
QuickTime™ Player
RealOne™ Player 8 Basic
Microsoft® Internet Explorer
Napster® music software
TOSHIBA Notebook Maximizer
TOSHIBA Speech System
Part Numbers
PSA60U-086015
