Digital Matrix Processor Output Level Indicators 4-segment high precision LED and1 compressor signal LED shows the status of output level and compressor on current channel. Output Mute Keys Mute channel by pressing and exit by pressing again. Output Edit Keys Press to enter into relevant channel edit status parameter will show on the edit, Key and LCD.
Page 5
Digital Matrix Processor Press DOWN key two times, enter password memory setting way. OFF mains that password does not memory. It can operate the panel follow-up LOCK Select afterunlocking the passesword at first time. ON mains that password memory. It always needs to unlock the password when open the unit every time. Press DOWN key three times, enter signal source selection: pink noise, white Source Select...
Page 6
Digital Matrix Processor Press OUTPUT EDIT enter the settings as follow Default preferred option is gain, the scale is- 60dB--12dB. GAIN OUT1 +0.0dB Press DOWN key one time, enter PEQ PARAMETER SETTING: ”PEQ” current PEQ: 1 OUT1 number is 9, the scale of “F” is 20Hz-20kHz, “Q” is 0.4-128 “G” is -12dB G:0.0 FREQ:40.2 - +12dB, the style of filter are Peak, Low-shelf, High-shelf, High-cut, Low-cut, Q:3.00 YPTE: PEAK □...
Digital Matrix Processor PC SOFTWARE ONLINE SPECIFICATION Notice: User manual, PC software are on the attached CD, due to the software upgrades time by time, Please do control your DSP processor ONLY by this CD! USB connection steps DSP Processor USB cord PC or laptop USB connection...
Digital Matrix Processor 3, Open PC controlling software, PC software will find USB and connect device, after that the on-Line key change into green at the top right corner and show “Online” , you can operate the Processor by controlling software, Click “Online” button before exit. PC SOFTWARE INTERFACE SPECIFICATIONS THE FIRST: VOLUME CONTROL INTERFACE...
Page 9
Digital Matrix Processor 1, Menu Open and save preset parameter, the whole date upload to the computer File and download to the device. Input and output channels can be set freely to adjust all of the parameters. Link Copy Parameter copy freely between the input and Output channels. Setting password of the panel to ensure the safety of the device.
Page 10
Digital Matrix Processor THE THIRD: COMPRESSOR INTERFACE 1, Show compression status, level indicators and impression status of all channels. 2, Set the whole compression parameters for output channel, the compression range is -60dB– +20dB, rate is 1:1, 1:10, LIMIT, start time is: 0-200ms, recovery time is 0-999ms. THE FOURTH: DELAY INTERFACE 1, Show the delay parameter status of all channels.
Page 11
Digital Matrix Processor THE FIFTH: MATRIX INTERFACE 1, Show connections of the device, users can enter and edit relevant channel by clicking the square , every channel name is revisable. 2, All output channels can choose any input channels. THE SIXTH: INPUT INTERFACE 1, Select “Mag"...
Page 12
Digital Matrix Processor 2, Adjustable Gain, Mute, Q , Frequency, Type of all PEQ, Bypass key is optional, we can choose PEQ style: Balance, High-shelf, Low-shelf, High-cut, Low-cut, Phase 180° , Phase 360°. 3, The Gain, Q, Frequency of PEQ can be adjusted by putter, and can be controlled by pressing the UP, DOWN, LEFT, RIGHT key on the keyboard.
Digital Matrix Processor REAR PANEL CONTROL PORT CONNECTION 1, RS232 connection port: Central control and connect to PC through RS232 port. The 2PIN is: TXD, 3PIN is:RXD, 5PIN is: GND RS232/USB CONVERTER PC or laptop 2, RS485 cascade contro port: Parallel connect several devices by RS485, you can choose different ID to cascade control separately.
