FiberPlex™ Model FP101EM
Mini Industrial Gigabit Media Converter
User Manual
FCC MARKING
This Equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment
is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received; including interference that may cause undesired operation.
CE MARKING
This equipment complies with the requirements relating to electromagnetic compatibility, EN
55032/24 class A for ITE, the essential protection requirement of Council Directive 2014/30/EU
on the approximation of the laws of the Member States relating to electromagnetic compatibility.
Trademark Statement
The term FiberPlex is a trademark of Patton Electronics Company. All other trademarks presented in this
document are the property of their respective owners.
Copyright © 2016, Patton Electronics Company. All rights reserved.
The information in this document is subject to change without notice. Patton Electronics assumes no
liability for errors that may appear in this document.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FiberPlex FP101EM and is the answer not in the manual?

Questions and answers

Summary of Contents for Patton FiberPlex FP101EM

  • Page 1 Member States relating to electromagnetic compatibility. Trademark Statement The term FiberPlex is a trademark of Patton Electronics Company. All other trademarks presented in this document are the property of their respective owners.
  • Page 2: Key Features

    • Extended environmental specification -40°C to 75°C Introduction Patton’s FP101EM converts singlemode or multimode fiber to a copper Ethernet signal. The increased bandwidth and reliability is ideal for applications involving devices such as IP security cameras, VoIP phones, wireless access points, POS kiosks, BACs, PLCs and many other remote networking needs.
  • Page 3: Installation Package

    Installation package This unit can be din-rail mounted or wall-mounted. Din-rail brackets and wall-mount brackets are included. Power connection This unit provides a 3-pin terminal block. The DC voltage range is from 12VDC to 56VDC. Always make sure your input voltage is within this supported voltage range. To connect power: Follow the printed polarity for V+, V- and Ground.
  • Page 4: Dip Switch Function

    Dip switch function This unit is equipped with dip switches, located on the front panel. Adjusting the dip switches will change the default function of this unit. This unit has set to manufacturer default as: SFP speed 1000M and LFP function OFF.
  • Page 5: Specification

    Specification IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3ab 1000Base-T Gigabit Ethernet IEEE Standard IEEE 802.3z 1000Base-X Gigabit Ethernet IEEE 802.3x Flow Control and Back Pressure Back-plane (Switching Fabric): 4Gbps Switch Architecture Ports speed are the same: Converter mode Data Processing Ports speed are not the same: Switch mode (store and forward)
  • Page 6 Power Input 12V-56VDC Power Consumption 1.92W full load without PoE at 48VDC 3 pin contact terminal block for power input Wire range: 0.34mm^2 to 2.5mm^2 Solid wire (AWG):12-24/14-22 Removable Terminal Block Stranded wire (AWG): 12-24/14-22 Torque:5lb-In/0.5Nm/0.56Nm Wire Strip length: 7-8mm Operating Temperature -40°C to +75°C 5% to 95% (Non-condensing)
  • Page 7 Housing Dimension (mm) NOTE: Housing dimension is for the purpose of showing product Length, Width, Height, din-rail, and terminal block’s position and dimension. Please reference the LED Indicator Page for correct port order.
