- Page 1 SR-1600 Plus MBS (Manual Bypass Switch) User’s Manual Telecom / Datacom PURE SINE WAVE INVERTER...
- Page 3 Any part of this document may not be reproduced in any form for any purpose without the prior written permission of COTEK Electronic IND. CO. For the conditions of the permission to use this manual for publication, contact COTEK Electronic IND. CO., LTD. In all related COTEK product activities, Neither COTEK Electronic IND.
-
Page 5: Table Of Contents
Table of Content 1. SAFETY INSTRUCTIONS 1-1. General Safety Precautions 1-2. Other Safety Notes 2. MECHANICAL DRAWINGS (19” 2U) 3. INTRODUCTION AND INSTALLATION 3-1. Introduction 3-2. Installation 4. WARRANTY... -
Page 6: Safety Instructions
1. Safety Instructions 1. Safety Instructions 1-1. General Safety Precautions Warning! Before using the Inverter, read the safety instructions. Do not expose the inverter to rain, snow, spray or dust. To reduce the risk of fire hazard, do not cover or obstruct the ventilation openings and do not install the inverter in a zero-clearance compartment. -
Page 7: Other Safety Notes
1. Safety Instructions 1-2. Other Safety Notes Upon receipt, examine the carton box for damage. Notify the carrier immediately, before opening, if damage is evident. Do not operate near water or in excessive humidity. The DC side connections should be firm and tight. ... - Page 8 1. Safety Instructions Specification Model No. Electrical Item SR-3U63 MBS Nominal Voltage 230VAC Voltage Range 150~265VAC ± 3% AC Input (Full power rating) Nominal Current 50A(63AMAX) Frequency 50 / 60 Hz AC Output Rating Power 50A(63A MAX) NORMAL to TRANSFER 0 second TRANSFER to BY-PASS 0 second...
-
Page 9: Mechanical Drawings (19" 2U)
3. Introduction 2. Mechanical Drawings (19” 2U) Unit: mm [inch] Figure 1. SR-1600 Plus MBS mechanical drawing... -
Page 10: Introduction And Installation
2. Mechanical Drawings 3. Introduction and Installation 3-1. Introduction Description Function 1. Turn the switch : Normal Transfer By-pass Normal By-pass 2. DC Source Power off 3. Remove the module 1. Plug in all the module 2. DC source Power on, then wait LED indicators become : Green Orange... - Page 11 3. Introduction Description Function SR-1600 PLUS AC-OUTPUT PE SR AC-OUTPUT N(11) SR-1600 PLUS AC-OUTPUT NEUTRAL L(9) SR-1600 PLUS AC-OUTPUT LINE GROUND LOAD CONNECTION N(6) NEUTRAL L(8) LINE SR-1600 PLUS AC-INPUT PE SR AC-INPUT N(4) SR-1600 PLUS AC-INPUT NEUTRAL L(2) SR-1600 PLUS AC-INPUT LINE GRID GROUND GRID N(3)
- Page 12 2. Mechanical Drawings 3-1-2 AC Cabling Interface Wire Color Wire AWG Line (L) Black SR AC-OUTPUT Neutral (N) White Line (L) Black LOAD CONNECTION Neutral (N) White Breaker suggestion 200-240Vac：50A/Shelf/8AWG Line (L) Black SR AC-INPUT Neutral (N) White Line (L) Black GRID Neutral (N)
-
Page 13: Installation
3. Introduction 3-2. Installation Turn the switch : Normal Transfer... - Page 14 3. Introduction Turn the switch : Transfer By-pass DC Source Power off...
- Page 15 3. Introduction Remove the module Plug in all the module...
- Page 16 3. Introduction DC source Power on, then wait LED indicators become : Green Orange Turn the switch By-pass Transfer, then wait & LED Indicator lights Green...
-
Page 17: Warranty
COTEK local distributor. This warranty will be considered void if the unit has been misused, altered, or accidentally damaged. COTEK is not liable for anything that occurs as a result of the user’s fault. - Page 18 No.33, Sec. 2, Renhe Rd., Daxi Dist., Taoyuan City 33548, Taiwan Phone：+886-3-3891999 FAX：+886-3-3802333 http：// www.cotek.com.tw 2023.10...
