HYDRAULIC WHEEL DOLLY
SET OF TWO
Model 94682
Assembly and Operating Instructions
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at http://www.harborfreight.com
Copyright
2006 by Harbor Freight Tools
. All rights reserved. No portion of this manual
©
®
or any artwork contained herein may be reproduced in any shape or form without the express
written consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353.
Advertisement
Table of Contents
Related Manuals for Central Hydraulics 94682
Summary of Contents for Central Hydraulics 94682
- Page 1 Brought to You by www.snapwhole.com HYDRAULIC WHEEL DOLLY SET OF TWO Model 94682 Assembly and Operating Instructions ® 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our Web site at http://www.harborfreight.com Copyright 2006 by Harbor Freight Tools . All rights reserved. No portion of this manual © ® or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. For technical questions and replacement parts, please call 1-800-444-3353.
- Page 2 CHECK FOR DAMAGED PARTS. Before using this product, carefully check that it will operate properly and perform its intended function. Check for damaged parts and any other condi- tions that may affect the operation of this product. Replace or repair damaged or worn parts immediately. REPLACEMENT PARTS AND ACCESSORIES. When servicing, use only identical replace- ment parts. MAINTAIN THIS PRODUCT WITH CARE. Keep this product clean and dry for better perfor- mance. USE THE RIGHT PRODUCT FOR THE RIGHT JOB. There are certain applications for which this product was designed. Do not use small equipment, tools or attachments to do the work of larger industrial equipment, tools or attachments. Do not use this product for a purpose for which it was not intended. SKU 94682 For technical questions, please call 1-800-444-3353. Page 2...
- Page 3 NOTE: Turn to the Parts list and Assembly diagram on page 7 for help identifying the parts mentioned below. There are two Rod Assemblies (3) for each Wheel Dolly. One needs to be attached to the Outer Body & Axle Assembly (13), the other one should be attached to the Inner Body & Axle Assembly (8). Insert the Roller Raceway (5) into the Roller (6), then press the Rod Assembly (3) into the Outer Body Assembly (13). Use the Washer (10), the Lock Washer (11) and secure it in place using a wrench. Attach the other Rod Assembly (3) to the Inner Body & Axle Assembly using the same hardware and process. WARNING: Make sure all the hardware is tight before you use the Wheel Dolly. Also test each Wheel Dolly before using it. SKU 94682 For technical questions, please call 1-800-444-3353. Page 3...
- Page 4 Pedal (17) unless the Release Valve is turned completely clockwise (see Figure 2). To lower the tire, turn the Release Valve (26) counter-counterclockwise. The weight of the tire will spread the Roller (6) apart, allowing you to pull the Wheel Dolly away from the tire. WARNING: Do not turn the Release Valve (26) completely clockwise; doing so will remove it allowing oil to spill out. SKU 94682 For technical questions, please call 1-800-444-3353. Page 4...
- Page 5 Release Valve (26) Pedal Lock Oil Fill Plug (27) (14) Pedal Lock Assembly (14) Figure 5 INSPECTION, MAINTENANCE, AND CLEANING Before each use, inspect the general condition of the Wheel Dolly. Check for cracking, bend- ing, wheel damage, and any other condition that may affect safe operation. If a problem occurs with the Dolly, immediately discontinue its use; never use a damaged Wheel Dolly. To clean, wipe with a damp cloth. You may use a mild detergent. PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER NOR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNI- CIANS AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. SKU 94682 For technical questions, please call 1-800-444-3353. Page 5...
- Page 6 Brought to You by www.snapwhole.com PARTS LIST AND ASSEMBLY DIAGRAM Part Description Lock Nut Caster Rod Assembly Bolt Roller Raceway (nylon) Roller (aluminum) Screw Inner Body & Axle Assembly Washer Lock Washer Lock Pin Outer Body & Axle Assembly Pedal Lock Assembly Complete Hydraulic Jack NOTE: Some parts are listed and shown for (includes parts 18-55) Hex bolt illustration purposes only and are not available Foot Pedal individually as replacement parts. SKU 94682 For technical questions, please call 1-800-444-3353. Page 6...
- Page 7 Screw Cylinder Spring Ball Circlip Pump Body Circlip O -ring Bushing Release valve Seal Ring 27 Oil Plug Screw Nylon Ring Connecting Base Pump Cylinder Ball Dust Cover Ball Cap Spring Spring Spring Cover Screw O -ring O-ring Nylon Ring Screw Piston Plastic Cap Seal Ring Seal Kit (extra kit not included) SKU 94682 For technical questions, please call 1-800-444-3353. Page 7...
